RKP2415 / RKP2417 / RKP2419
Bright / Contrast
1. Brightness
2. Contrast
Phase / Clock
1. Phase
2. Clock
H/V Position
1. H.Position
2. V.Position
Rev. : 1.0
10. LCD Session
To perform brightness adjustment of the input RGB signal
●
Use the Left & Right button to adjust and button
●
To adjust the contrast level of the input signal
●
Use the Left & Right button to adjust and button
●
To adjust input video sampling clock's phase
●
Use the Left & Right button to adjust and button
●
To adjust input video sampling clock
●
Use the Left & Right button to adjust and button
●
To adjust the horizontal size of the frame
●
Use the Left & Right button to adjust and button
●
To adjust the vertical position of the frame
●
Use the Left & Right button to adjust and button
●
P.12
User Manual
to "Brightness"
to "Contrast"
to "Phase"
to "Clock"
to "H.position".
to "V.position".
