I-Tech UltraView iOP40W User Manual page 11

OP-40WT Series
B.
(1) AC IN
(2) SCART IN
(3) RCA IN
(4) Audio IN
(5) S-Video IN
(6) Audio OUT
(7) Component Video IN ： Connect to Component Video connectors.
(8) VGA IN
(9) DVI-D IN
(10) Antenna IN
Jan 05
4. Using the System
I/O Outlet
(1) (2)
Front
(3)
(4) (6)
(5)
： Connect to power cord.
： Connect to 21pin Scart connector.
： Connect to the composite RCA video connector.
： Connect to the RCA audio connectors.
: Connect to the S-video connector.
: Connect to the RCA audio connectors.
： Connect to the 15pin sub-D connector.
： Connect to the DVI-D connector.
： Connect to the TV antenna connector.
P.9
User Manual
OP Series
(7) (8) (9) (10)
