I-Tech UltraView iOP4000W Specifications

40"
Open Frame TFT LCD Display
L C D S c r e en
Manufacturer
LCD Origin South Korea
LCD Type Samsung grade A industrial TFT LCD Panel
Display Size 40.0 inch diagonal (885.168 x 449.674V)
Resolution 1,366 x 768, WXGA
Display Color 16.7M color
2
Brightness 500 cd/m
Contrast Ratio 800 : 1 (Typical)
Pixel Pitch 0.648 x 0.216 mm
Viewing Angle 85 / 85 / 85 / 85 (L / R / U / D)
OSD Control Brightness, Contrast, Phase & Clock,
Color, H & V position, Auto-tune & Recall
VGA Connector D-Sub 15 pin VGA analog
Video Input S-Video and Composite
TV Channel NTSC, PAL, SECAM
TV Input RF F-connector
LCD MTBF 50,000 hrs
Mounting Flexible front mount
Dimension 980(W) x 630(H) x 90(D) mm
Weight 44.98 kg (Net)
Packing 1021(W) x 851(H) x 330(D) mm
OP-40W / WT
*All brand names, logo registered trademarks are properties of their respective owners.
*All information change without any notice
40"
Full View
OP-40W / WT
Bottom View
I n t e rn a l P o w e r A d a p t e r
AC Input 110V ~ 220V AC Input
Power Safety Approval CE
E n v i r o n m e n t a l
Operating Temperature 0 to 50
Storage Temperature -25 to 60
Humidity 93.8%, non condensing
Shock 10G peak acceleration
( 11mec. duration )
Safety Approval CE, FCC
O r d e r i n g G u i d e
Model Description
OP-40W 40" Open Frame Wide-Ranges LCD Panel w/ Video Input
OP-40WT 40" Open Frame WR w/ Video Input & TV Tuner
40" Open Frame TFT LCD Display
16:9
AP
DP
OP
Side View
o
C
o
C
Rev. 3.0
JAN-2005
