I-Tech UltraView iOP1700W Specifications

17"
Open Frame TFT LCD Display
L C D S c r e e n
Manufacturer
LCD Origin South Korea
LCD Type Samsung grade A industrial TFT LCD Panel
Display Size 17.0 inch diagonal (370.56H x 222.34V)
Resolution 1,280 x 768, SXGA
Display Color 16.2M color
Brightness 450 cd/m
Contrast Ratio 300: 1 (Typical)
Pixel Pitch 0.2895 x 0.2895 mm
Viewing Angle 70 / 70 / 50 / 60 (L / R / U / D)
OSD Control Brightness, Contrast, Phase & Clock,
Color, H & V position, Auto-tune & Recall
VGA Connector D-Sub 15 pin VGA analog
Video Input S-Video and Composite
TV Channel NTSC, PAL, SECAM
TV Input RF F-connector
LCD MTBF 50,000 hrs
Mounting Panel, wall-mount or VESA arm
Dimension 454(W) x 308(H) x 60(D) mm
Weight 4.94 kg (Net)
Packing 508(W) x 536(H) x 18.3(D) mm
OP-17W / WT
*All brand names, logo registered trademarks are properties of their respective owners.
*All information change without any notice
17"
Front View
2
OP-17W / WT
Bottom View
E x t e rn a l P o w e r A d a p t e r
AC Input 110V ~ 220V AC Input
DC Input 12V@5A Output
AC Cable Length 180cm
DC Cable Length 182cm
Size 108(L) x 64(W) x 30(H) mm
Safety Approval UL, CE
E n v i r o n m e n t a l
Operating Temperature 0 to 50
Storage Temperature -25 to 60
Humidity 90%, non condensing
Shock 10G peak acceleration
( 11mec. duration )
Safety Approval CE, FCC
O r d e r i n g G u i d e
Model Description
OP-17W 17" Open Frame Wide-Ranges LCD Panel w/ Video Input
OP-17WT 17" OP WR w/ Video Input & TV Tuner
17" Open Frame TFT LCD Display
16:9
AP
DP
OP
Side View
o
C
o
C
Rev. 3.0
JAN-2005
