SiAECOSYS VOTOL EM Program Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SiAECOSYS
V2
VOTOL EM Controller Program Manual
Non-profession do not operate!
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VOTOL EM and is the answer not in the manual?

Questions and answers

Related Manuals for SiAECOSYS VOTOL EM

Summary of Contents for SiAECOSYS VOTOL EM

  • Page 1 SiAECOSYS VOTOL EM Controller Program Manual Non-profession do not operate!
  • Page 2 SiAECOSYS This manual was explained in detail for the IV generation EM series controller, which update download illustrates and parameter adjustment. Before using the software, please read this manual. In order to facilitate the operation, please keep this manual. In order to make the software of maximum utility, please make sure the end user to use this manual.

  • Page 3: Usb Driver Installation

    SiAECOSYS 1. Software installation (only support win 7/10) 1.1 USB Driver Installation (1) Download the “USB-to-serial-win 10-20150814” file, decompressing file. (2) choose the suitable driver with your computer for installation. win7,win8, win 10 are available. 1.11. Decompress the operation first 2.
  • Page 4 SiAECOSYS then click “device manager” choose “port(COM & LPT)” choose the COM with“!”, click “search automatically for updated driver software...
  • Page 5 SiAECOSYS Close the software when you finish After running, please run the software directly: EM_V3 series debugging program; 自 2012 已停产，请联系供货商(Pls contact supplier if it is stop production since 2012) If the port has” ” Methods and steps: First step: Install driver PL2303_Prolific_DriverInstaller_v110...
  • Page 6 SiAECOSYS Third step: Click to select from the list of drivers for your computer; Fourth and finally, select version 3.3.10.140 (2009-11-19), click Next, close the window when finished;...
  • Page 7 SiAECOSYS Close the window when finished. Please run “Em_V3 Series debugging program” directly after completion.

  • Page 8: Controller Connection

    SiAECOSYS 2. Controller connection 2.1 Connect controller Controller host computer simple wiring diagram Description: controller B+ connects battery B+ controller B-connects battery B-, controller electric door locks connect battery or controller B+; The USB debug line is connected to the controller debug port;...
  • Page 9 SiAECOSYS 2.1.2 Host computer selection EM50 EM100 EM150 without CAN choose EM50 EM100 EM150 with CAN choose EM200 choose EM50 EM100 EM150 EM200 model XY-03-P with CAN and without CAN can share a host computer Specific host model needs to inquire the related sales;...
  • Page 10 SiAECOSYS Then power on (connect with e-lock), click connect (in setting 1 page), the nominal voltage should not be 0. If it’s 0, click connect again.
  • Page 11 SiAECOSYS 3. The setting 1. SETTING PAGE 1 1. CAN debugging Switch 2. Chinese/English Switch 1.Undervoltage,overvoltage selected by default +1V Usually 0 2.overvoltage selected by does not change default+2V 0-350, the larger the start Busbar current≤ECU Specification delay, the more obvious...
  • Page 12 SiAECOSYS 1.1.2、 Lead-acid battery over voltage, under voltage, soft under voltage basic value default: due to software settings defects, the original voltage compensation +1V. 1.1.3、The lithium battery is set according to the actual lithium battery parameter value. Due to software setting defects, the original voltage compensation +1V.
  • Page 13 SiAECOSYS Adjust motor jitter 1. The motor shakes more and more to the major 2. The motor does not shake to minor adjustment, Three speed percentage, take a reasonable value, range 100-1200, 50 each landing maximum speed stage. setting value is 100%...
  • Page 14 SiAECOSYS ≥High speed flux weakening Change not allowed Percentage of 1 gear current Percentage of current level 2 The overshoot shall not 1. NO/YES 1.4000 Corresponding exceed 20 2. Adjustable exit time slope of front acceleration and line current limiting value of front phase 2.
  • Page 15 SiAECOSYS 2.1： Parameters setting for sports mode(S gear) 2.2.1 、 Bus bar current setting: According to the controller type current corresponding to the selection, absolutely no over current is allowed. VOLTAGE EM-30 EM-50 EM-50S EM-100 EM-100S EM-150 EM-150S EM-200 EM-300...
  • Page 16 SiAECOSYS magnetic speed is less than <125%, 110KM/H motor weak magnetic speed is less than <135%. 2.4.4.2 Inner rotor motor Hall: The built-in Hall weak magnetic speed is less than <135%, and the external Hall weak magnetic speed is less than 170%.
  • Page 17 SiAECOSYS 3. The setting page 3 1. Pole pair shall be filled in according to motor parameters 2. Opposite adjustment 3. Phase shift angle adjustment angle, hub usually - 60 4. The motor type hub table is pasted, and the center is checked...
  • Page 18 SiAECOSYS 3.7、Reversing, EBS setting, low brake selection, starting safety switch function。 3.7.1、According to the weight of the vehicle (recommended within 30%) 3.7.2、Two-wheeler 35~60 interval 3.7.3、Two-wheeler 45~75 section 3.7.4、Energy recovery with lithium battery parameter value equipment, the actual road test shall prevail.
  • Page 19 SiAECOSYS 4. Expanded page 1. The actual value corresponds to the first inspection result of controller parameter software. 2. The comparison value corresponds to the parameter software result of the same batch of controllers. If the two values are the same, the parameters are the same.
  • Page 20 SiAECOSYS "d", indicating that the download is successful. Serial port line is divided into the following models: em-30 ~ em-150 general, em-200, em-300, can 4.2: import configuration 4.2.1: select the INI file, open the file, import the controller parameters, and receive the prompt "import succeeded"...
  • Page 21 SiAECOSYS 1. Q-axis voltage: the range is 2000-3000 after the motor angle is correct 2. D-axis voltage: the range is - 600 to - 1000 after the motor angle is correct (there may be slight fluctuation) 2.1: after the final speed of the motor is confirmed by the...
  • Page 22 SiAECOSYS 6. Port setting interface Click/shift three gears 1. Arrange and insert each port corresponding to the main function of the controller Stir up one gear 2. When changing the function, select the number sort table under each port to change, and...
  • Page 23 SiAECOSYS 6. The main function of the corresponding controller is to arrange and plug each port 7. When changing the function, select S gear the number sorting table under each Stealavoid port to change, and each number corresponds to different functions.
  • Page 24 SiAECOSYS 6.3: the above port functions are factory default configuration, corresponding to Lande 2 × 8 transfer line drawing, dedicated to em150sp (after 20200321) controller.
