SiAECOSYS VOTOL EM Series Program Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
SiAECOSYS
V2
VOTOL EM Controller Program Manual
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the VOTOL EM Series and is the answer not in the manual?

Questions and answers

Related Manuals for SiAECOSYS VOTOL EM Series

Summary of Contents for SiAECOSYS VOTOL EM Series

  • Page 1 SiAECOSYS VOTOL EM Controller Program Manual...
  • Page 2 SiAECOSYS Non-profession do not operate! This manual was explained in detail for the IV generation EM series controller, which update download illustrates and parameter adjustment. Before using the software, please read this manual. In order to facilitate the operation, please keep this manual.

  • Page 3: Usb Driver Installation

    SiAECOSYS 1. Software installation (only support win 7/10) 1.1 USB Driver Installation (1) Download the “USB-to-serial-win 10-20150814” file, decompressing file. (2) choose the suitable driver with your computer for installation. win7,win8, win 10 are available. 1.11. Decompress the operation first 2.
  • Page 4 SiAECOSYS then click “device manager” choose “port(COM & LPT)” choose the COM with“!”, click “search automatically for updated driver software...
  • Page 5 SiAECOSYS Close the software when you finish After running, please run the software directly: EM_V3 series debugging program; 自 2012 已停产，请联系供货商(Pls contact supplier if it is stop production since 2012) If the port has” ” Methods and steps: First step: Install driver PL2303_Prolific_DriverInstaller_v110...
  • Page 6 SiAECOSYS Third step: Click to select from the list of drivers for your computer; Fourth and finally, select version 3.3.10.140 (2009-11-19), click Next, close the window when finished;...

  • Page 7: Controller Connection

    SiAECOSYS Close the window when finished. Please run “Em_V3 Series debugging program” directly after completion. 2. Controller connection 2.1 Connect controller Controller host computer simple wiring diagram Description: controller B+ connects battery B+ controller B-connects battery B-, controller electric door locks connect battery or controller B+;...
  • Page 8 SiAECOSYS 2.1.1 According to the controller with CAN or without CAN to select the appropriate USB debug line; with CAN controller need to check the CAN enable, without CAN does not need to check; EM200 controller needs to exchange the debug line CAN-H and CAN- L , otherwise can’t connect the controller;...
  • Page 9 SiAECOSYS 3 Open the computer device manager before connecting to the computer to check whether the USB port is successfully installed. Select the appropriate host computer to connect the host computer to the serial port when the controller is not powered.
  • Page 10 SiAECOSYS 3. The setting 1. SETTING PAGE 1...
  • Page 11 SiAECOSYS 1. CAN debugging Switch 2. Chinese/English Switch 1.Undervoltage,overvoltage selected by default +1V Usually 0 2.overvoltage selected by does not change default+2V 0-350, the larger the start Busbar current≤ECU Specification delay, the more obvious current value No change allowed 10-250, the greater the...
  • Page 12 SiAECOSYS 1.1.4.1、Over voltage fault: After open the electric door lock, the vehicle doesn’t move. The Controller over voltage protection function starts. 1.1.4.2、 ECU under voltage fault: due to the lithium battery protection board over voltage device is too high or the under voltage setting is too low, resulting in lithium battery protection, burning MOS.
  • Page 13 SiAECOSYS Adjust motor jitter 1. The motor shakes more and more to the major 2. The motor does not shake to minor adjustment, Three speed percentage, take a reasonable value, range 100-1200, 50 each landing maximum speed stage. setting value is 100% ≥High speed flux weakening...
  • Page 14 SiAECOSYS 100A ---- 180A ---- ---- ---- 130A ---- 250A 500A 2.2.2、 Sport mode flux weakening value： Flux weakening value for S gear: the parameter value is <3000, and the vehicle speed is adjusted according to the motor parameters. BOOST weak magnetic value> high speed weak magnetic value 2.2.3、Auto exit function: tick to jog key / uncheck to long press key, select one from two.
  • Page 15 SiAECOSYS 2.8.4 、 Speed relation of electric brake setting corresponding to weak magnetic acceleration: the speed corresponding to the highest landing speed of the motor is set by the auxiliary enable of downhill electric brake. When the setting value is lower than the rated speed of the motor, weak magnetic acceleration is not required or optional.
  • Page 16 SiAECOSYS 3.1.3、Motor type：Fill in according to the motor manufacturer parameters. Note: Wheel Hub motor is surface mount 3.1.4、Hall, phase line exchange: exchange the motor forward and reverse. 3.2、 The controller to speedometer date output has 2 types: Single-line speedometer and hall speedometer, it needs to be decided by the vehicle’s speedometer.
  • Page 17 SiAECOSYS Naming method 3. Expanded page...
  • Page 18 SiAECOSYS 1. The actual value corresponds to the first inspection result of controller parameter software. 2. The comparison value corresponds to the parameter software result of the same batch of controllers. If the two values are the same, the parameters are the same.
  • Page 19 SiAECOSYS Analog vehicle instrument display 1.Speed: display the actual speed of the motor 2.Voltage: display the actual output voltage of power supply and battery 3.Current: display the actual output current of power supply and battery 4. Fault display: display vehicle fault 5.Gear display: display the current gear of...
  • Page 20 SiAECOSYS 1. Q-axis voltage: the range is 2000-3000 after the motor angle is correct 2. D-axis voltage: the range is - 600 to - 1000 after the motor angle is correct (there may be slight fluctuation) 2.1: after the final speed of the motor is confirmed by the...
  • Page 21 SiAECOSYS 6. Port setting interface Click/shift three gears 1. Arrange and insert each port corresponding to the main function of the controller Stir up one gear 2. When changing the function, select the number sort table under each port to change, and...
  • Page 22 SiAECOSYS 6. The main function of the corresponding controller is to arrange and plug each port 7. When changing the function, select S gear the number sorting table under each Stealavoid port to change, and each number corresponds to different functions.
  • Page 23 SiAECOSYS 6.3: the above port functions are factory default configuration, corresponding to Lande 2 × 8 transfer line drawing, dedicated to em150sp (after 20200321) controller.

  • Page 24: Port Setting

    SiAECOSYS Display page 4 External tempIs is the motor temperature 6、Port setting 1. One-line setting PB9 choose 11...
  • Page 25 SiAECOSYS Output choose one- Lin 2.Hall setting PB9 choose13...
  • Page 26 SiAECOSYS Output choose hall speedometer 3. Trigger three-speed setting...
  • Page 27 SiAECOSYS 4.Jog three-speed setting PD0 1 PD1 SW choose 7...
  • Page 28 SiAECOSYS Choose Button 3 speed...
  • Page 29 SiAECOSYS 5. To import the configuration, click import prarm, select the appropriate INI file, and then click param write; to export the configuration, click save pram and save； After adjusting the parameters, click paparam write to save the parameters; Remarks: Please carefully read this attentions before the user adjusts the parameters. Since the user does not adjust the parameters according to the precautions, the controller is not responsible for the after-sales of such controllers.

This manual is also suitable for:

Votol em50Votol em100Votol em150
