Liz 05 Drawers Chest
D717-05 White
D717-90 Gray
D717-101 Coffee
Assembly Requirements
Images for illustration only
ASSEMBLY INSTRUCTIONS
To clean your furniture, use a dry or wet cloth, and do not use chemicals
that may damage your product.
The products' assembly system works according to the increasing order
of the indicated numbers. For example: 01, 02, 03, 04 ... to the end of the
assembly.
NOTICE
ASSEMBLY SYSTEM
