1
Assembled View
2
Parts List
A
Headboard Panel x 1
B
Headboard Support x 1
C
Footboard Panel x 1
D
E
0008 S Full Bed
Assembly Instructions
Side Rail
(Left Hand) x 2
Side Rail
(Right Hand) x 2
F
Headboard
Headboard
Post
(Left Hand)
(Right Hand)
x 1
K
Long Support
x 2
M
Support
Leg x 6
Use 2 People
Note: Do not assemble
using power tools.
This can cause the bolts
to be overtightened
Bed Post
(Left Hand)
x 2
G
Post
Bed Post
(Right Hand)
x 1
x 2
L
Support Bar
x 2
N
Set of Bed Slats x 2
Page 1 of 6
WI-0221
H
J
Advertisement
Related Manuals for overstock 0008 S
Summary of Contents for overstock 0008 S
- Page 1 0008 S Full Bed Assembly Instructions WI-0221 Assembled View Use 2 People Note: Do not assemble using power tools. This can cause the bolts to be overtightened Parts List Bed Post (Left Hand) Headboard Panel x 1 Headboard Headboard Headboard Support x 1...
-
Page 2: Hardware List
0008 S Full Bed Assembly Instructions WI-0221 Hardware List Allen Key Metal Plate Adjustable Wood Screw Foot x 6 (M4 x 32mm) x 24 Wood Dowel Barrel Spring M6 Flat (M10 x 40mm) Nut x 12 Washer Washer JCN Nut... - Page 3 0008 S Full Bed Assembly Instructions WI-0221 Assemble the Headboard Panel (A) & Headboard Support (B) to the Headboard Post (F & G). Fit the Metal Plate to the Side Rail (D & E). x2 x2 Page 3 of 6...
- Page 4 0008 S Full Bed Assembly Instructions WI-0221 Fit the Bed Post (H & J) to the Side Rail (D & E). Assemble the Side Rail (D & E) to the Headboard & Footboard Panel (C). Headboard Page 4 of 6...
- Page 5 0008 S Full Bed Assembly Instructions WI-0221 Fit the Slats (N) to the Long Support (K) & Support Leg (M). Bolt the Bed Slats (N) to the Side Rail (D & E). Headboard Page 5 of 6...
- Page 6 0008 S Full Bed Assembly Instructions WI-0221 Screw the Bed Slats (N) to the Side Rail (D & E). Headboard Lastly, fit the Support Bar (L) in place. Headboard Page 6 of 6...
