DATE: 21-SEP-2020
JASLENE BUFFET/MEDIA CABINET
ASSEMBLY
REQUIREMENTS
Thank you for purchasing our product!
Please refer and use this assembly instruction to assemble the product.
Contact our customer service department in case there are any missing or damage parts or hardware.
Replacement parts are normally shipped within 2 or 3 days.
Email: replacementparts@buylateral.com
Within 30 days from delivery date
ASSEMBLY PREPARATION
1. Remove all packaging materials, staples and packing straps from the carton.
2. Refer to Parts List and Hardware List and ensure they are correct before assembly.
Contact customer service for missing parts.
3. Place all wooden parts on a clean, flat and soft surface (e.g. carpet or rug) to prevent parts from getting scratched.
SAFETY PRECAUTION:
1. KEEP ALL HARDWARE PARTS OUT OF REACH OF CHILDREN.
2. DISPOSE PLASTIC PACKAGING MATERIAL IMMEDIATELY TO AVOID ANY RISK OF SUFFOCATION TO
CHILDREN AND ANIMALS.
TIPS FOR ASSEMBLY:
1. Allow ample room for assembly and in close proximity to where product will be placed.
2. Assemble the product on a surface that does not scratch or damage the exterior gloss and finish of the furniture.
3. Identify all of the parts, hardware and quantities required for each step.
4. During assembly, do not over-tighten any fittings as this may cause damage.
5. DO NOT USE POWER TOOLS TO ASSEMBLE THIS PRODUCT.
6. Always place the product on a flat, level surface.
7. Do not sit or stand on the partially assembled product; only use the product for which it is intended.
CARE AND MAINTENANCE
- Use a slightly damp cloth to clean the product. Do not use bleach or abrasive cleaning material.
- Check all the fittings periodically and re-tighten as necessary. Do not use the product if any of the parts is
damaged or broken.
- Never allow any kind of liquid to remain on your furniture. Absorption can cause wood to warp or delaminate.
- Do not place hot items (e.g. hot drinks) directly onto the wood surface.
- Do not drag and/or pull the furniture.
This product is for indoor and household use only - not for commercial use.
1/12
ASSEMBLY INSTRUCTIONS
1 Hour
2 -Person Assembly
Assembly Time
(Approximate)
Tools Required (Not Provided):
Phillips Screwdriver
Flat Head Screwdriver
We appreciate your business!
ITEM# 80600
Made In China
Advertisement
Related Manuals for overstock 80600
Summary of Contents for overstock 80600
- Page 1 DATE: 21-SEP-2020 ASSEMBLY INSTRUCTIONS JASLENE BUFFET/MEDIA CABINET ITEM# 80600 Tools Required (Not Provided): 1 Hour ASSEMBLY 2 -Person Assembly Assembly Time Phillips Screwdriver REQUIREMENTS (Approximate) Flat Head Screwdriver Thank you for purchasing our product! Please refer and use this assembly instruction to assemble the product.
-
Page 2: Hardware List
ASSEMBLY INSTRUCTIONS JASLENE BUFFET/MEDIA CABINET ITEM# 80600 Hardware List ITEM DESCRIPTION PART ITEM DESCRIPTION PART 8 pcs Cam-Bolt 6 pcs Shelf Pin 6*35mm 4 pcs Cam-Lock 6 pcs Hinge 15*10mm 20 pcs 1 pc Wood Dowel Allen Wrench 8*30mm 24 pcs... -
Page 3: Parts List
ASSEMBLY INSTRUCTIONS JASLENE BUFFET/MEDIA CABINET ITEM# 80600 Parts List PART ITEM DESCRIPTION PART ITEM DESCRIPTION Connect Bar 2 pcs Top Panel 1 pc Bottom Panel 1 pc 1 pc Left Door Right Front and Left 2 pcs Left Panel 1 pc... - Page 4 ASSEMBLY INSTRUCTIONS JASLENE BUFFET/MEDIA CABINET ITEM# 80600 ASSEMBLY OVERVIEW 4/12...
- Page 5 Instructions For Fastening CAM-BOLT AND CAM-LOCK Tools Required CAM-BOLT CAM-LOCK INSERTING AND TIGHTENING CAM-BOLT SHOULDER Place Cam-bolt on pre-drilled Shoulder is flushed (on the Shoulder is above the panel. hole and screw in vertically. same level) with the panel. Place Cam-bolt to the designated pre-drilled holes on the panel. Use a Phillips Screwdriver to tighten Cam-bolt vertically until shoulder is flushed (on the same level) with panel.
- Page 6 STEP 1 6 pcs a) Lay Top Panel (1) bottom-side on a material that does not scratch or damage the part. b) Screw in Cam-bolt (A) into the designated holes on (1). Refer to Page 5 for instructions on inserting and tightening Cam-bolt.
- Page 7 STEP 3 6 pcs 6 pcs 2 pcs 4 pcs 3x14 mm a) Insert Wood Dowel (C) into designated hole on bottom edge of Left Panel (3), Right Panel (5) and Center Panel (4). b) Attach (3, 4 & 5) to Bottom Panel (2) via Wood Dowel and fasten with Screw (E). Use Allen Wrench (L) to drive and tighten (E).
- Page 8 STEP 5 6 pcs 6 pcs a) Insert Wood Dowel (C) into the inner 2 center holes at the top edge of Left Panel, Divide Panel and Right Panel (3, 4 & 5). b) Attach Top Panel (1) to (3, 4 & 5) via Cam-bolts and Wood dowels on the respective parts. c) Insert Cam-lock (B) into the designated holes on (3, 4 &...
- Page 9 STEP 7 8 pcs 4 pcs Hinge Cup 2 pcs 2 pcs 3x12 mm 8 & 12 Hinge Well a) Place the interior of Left Side Door (8) facing up as shown on a material that does not scratch or damage the front surface.
- Page 10 STEP 9 2 pcs 2 pcs Attach Knob (G) to Door using Knob Bolt (F). STEP 10 2 pcs 2 pcs a) Drill two holes in the dry wall that are aligned to the two holes on the Connect Bar. The diameter of the hole on the dry wall needs to fit the diameter of Plastic Anchor (N).
- Page 11 STEP 11 8 pcs Insert Shelf Pin (M) into the designated holes on the same level at the desired height on Side Panel and Center Panel. Place Shelf (6) by tilting it to fit between Side Panels and then level it to sit on Shelf Pin (L). STEP 12A 8 pcs Door Adjustments - If necessary, adjust the doors to reduce...
- Page 12 STEP 12B Door Side Loosen the middle screw of the Hinge and adjust the Door in and out to desired position, then tighten the screw to secure the hinge. Note: If the door cannot stay close, re-loosen the middle screw and pull out the door to increase the gap between door and side panel.
