Assembly Instructions
Caution: You must read this before you proceed
Please look in the Leg Panel for hardware packs
LOVESEAT
Caution: This Loveseat is NOT a TOY.
Keep your child / children at bay during the assembly process.
Whenever moving or lifting the Loveseat and to prevent any possible
damage to it, two adults are needed to execute this action.
Noble House Home Furnishings LLC
Page 1 OF 9
Advertisement
Related Manuals for overstock LOVESEAT
Summary of Contents for overstock LOVESEAT
- Page 1 Caution: This Loveseat is NOT a TOY. Keep your child / children at bay during the assembly process. Whenever moving or lifting the Loveseat and to prevent any possible damage to it, two adults are needed to execute this action.
-
Page 2: Parts List
Parts List Description Label Picture Right Leg Panel Left Leg Panel Backrest Panel Seat Panel First Support Bar Second Support Bar Third Support bar Backrest Cushion Seat Cushion Noble House Home Furnishings LLC Page 2 OF 9... - Page 3 Hardware Description Label Picture Bolt (M6x35 mm) Bolt (M6x45 mm) Bolt (M6x60 mm) Allen Wrench Screw (M4x35mm) (Use with Screwdriver) (Not provided) Screwdriver Asembly Preparation Before Beginning Assembly: Read instructions, cover to cover- Have 2 adults on hand for assembly- Do not assemble on flooring or carpet- Assemble on a clean non-marring surface (packing foam)- Save all packaging until finished-...
- Page 4 This Loveseat has multiple parts and may require up to 30 minutes to assemble. To give you an overview of the Loveseat parts, the above picture is to help you put the various parts into perspective. Please read through the instructions below to familiarise yourself with the parts and steps before assembly.
- Page 5 Step 1 Unpack and place all parts on a clean, non-marring surface. Step 2 Attach Third Support Bar (G) to the Seat Panel (D) using Screw (⑤) and a Screwdriver (⑥) as shown above Noble House Home Furnishings LLC Page 5 OF 9...
- Page 6 Step 3 With the help of your adult partner, put the tenon of the First Support Bar (E) and Second Support Bar (F) into the mortise of the Right Leg Panel (A) then secure the First Support Bar (E) and Second Support Bar (F) to the Right Leg Panel (A) using 4 Bolts (②) and the Allen Wrench (④) as shown above Do not fully tighten the Bolts.
- Page 7 Step 5 With the help of your adult partner, position the Left Leg Panel (B) to the assembled part in step 3 then: 5.1. Attach the tenons of the First Support Bar (E) and Second Support Bar (F) into the mortise of the Left Leg Panel (B) using Bolts (②) and the Allen Wrench (④) as shown above 5.2.
- Page 8 Step 7 With assistance from your adult partner, stand the Loveseat up Exert pressure floorwards, onto the Loveseat with both your hands. This pressure will help the Legs and Loveseat reach full alignment status. Check for wobbles on a LEVEL surface.
- Page 9 Step 8 Put Seat Cushion (I) then put Back Cushion (H) onto the Loveseat. Tie the magic tape straps of Seat Cushion (I) to the slat of Seat Panel (D) as shown above Step 8 Adjust height for balance Adjust low for balance...
- Page 10 Care & Maintenance Noble House Home Furnishings LLC Page 9 OF 9...
