Hussmann impact elite e2sph merchandisers: data sheet
Hide thumbs Also See for IMPACT Elite E2SPH:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

D
C
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part #
Description
F
A
T
AN
SSEMBLIES AND
HERMOSTATS
A. 12W Fan Assembly
0047000
Fan Motor, Evaporator
0124150
Fan Blade,
embossing toward motor
12W Energy Efficient Fan Assembly
0441749
Fan Motor, Evaporator
0124150
Fan Blade,
embossing toward motor
B. 0411744
Standard Non-adjustable
Defrost Thermostat
C. 0353949
Optional Adjustable
Refrigeration Thermostat
Note: Changed items have been underlined.
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
B
A
Wiring Item #
(1)
(1)
(2)
(3)
E
Item Part #
Description
L
B
AMPS AND
ALLASTS
D. 0466234
Ballast, Electronic
2 lamps
D. 0466235
Ballast, Electronic
3 lamps
E.
Fluorescent Lamp
Replace with like fixtures
O
THER
F. 0464718
Hot Well Assembly
E2SPH
Data Sheet Set
P/N 0453532
NSF
®
Certified
October 2005
F
Wiring Item #
P/N 0453532
(4)
(4)
(5)
(6)
