Hussmann EDS1 Technical Data Sheet

E
(Optional
Lights)
B
E
(Optional
Lights)
We reserve the right to change or revise specifications
and product design in connection with any feature of
our products. Such changes do not entitle the buyer to
corresponding changes, improvements, additions or
replacements for equipment previously sold or shipped.
Item Part # Description
F A T
AN SSEMBLIES AND HERMOSTATS
A. 4W Fan Assemblies
0392457 Fan Motor, Evaporator
(MO.4410101)
0409511 Fan Blade (FB.0409511)
embossing toward motor
0404551 Fan Motor, Ambient
(MO.0404551)
B. 0382028 Standard Non-adjustable
disc type Defrost Thermostat
(CT.0382028)
C. 0137880 Optional Adjustable
Refrigeration Thermostat
(CT.4481084)
Note: Changed items have been underlined.
©2007 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
®
Merchandisers
A
Wiring Item #
T'Stat Bulb
Location
C
A
Item Part #
L B
AMPS AND ALLASTS
D. 0355716
(1)
0355398
(2)
E.
(3)
H
EATERS
F. 0496496
(4)
EDS1
Technical Data Sheet
P/N 0431326_A
NSF
® Certified
July 2007
F
D
Description Wiring Item #
Ballast, Electronic
2 lamps (BA.0355716)
Ballast, Electronic
3 lamps (BA.4480118)
Fluorescent Lamp
Replace with like fixtures
Nosing Anti-sweat
Heater, 4 ft (HE.4850738)
P/N 0431326_A
(5)
(6)
(7)
(8)
