Cisco PGW 2200 Softswitch Release 9.8
Software Installation and Configuration
Guide
February 21, 2012
Americas Headquarters
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
http://www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883
Text Part Number: OL-18083-14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PGW 2200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cisco PGW 2200

Summary of Contents for Cisco PGW 2200

  • Page 1 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide February 21, 2012 Americas Headquarters Cisco Systems, Inc. 170 West Tasman Drive San Jose, CA 95134-1706 http://www.cisco.com Tel: 408 526-4000 800 553-NETS (6387) Fax: 408 527-0883 Text Part Number: OL-18083-14...
  • Page 2 Any use of actual IP addresses or phone numbers in illustrative content is unintentional and coincidental. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide © 2012 Cisco Systems, Inc. All rights reserved.

  • Page 3: Table Of Contents

    Preparing for Sun Solaris Operating System and Cisco PGW 2200 Softswitch Software C H A P T E R Installation Introduction Supported Platforms and Cisco Products Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Software Release Preinstallation Checklists Required Software Media Minimum System Requirements Required Site-Specific Information...
  • Page 4 Configuring ILOM on the Sun Netra X4270 Platform Configuring ILOM on the Sun Fire X4800 Platform 3-15 3-16 Installing the License File if the Cisco PGW 2200 Softswitch is NOT Running Installing the License File if the Cisco PGW 2200 Softswitch is Running 3-17 2-54...
  • Page 5 Adding a User with Full MML Privileges Adding a User with Minimal MML Privileges Configuring SNMP Support Resources Migrating the SNMP Configuration to a More Secure Environment (for Cisco PGW 2200 Softswitch Release 9.3(2) or Later) Basic Tasks Before You Run the config-snmp Utility...
  • Page 6 Configuring Disk Monitor During Initial Software Configuration Configuring the Data Dumper Configuring the Data Dumper to Support Cisco BAMS Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8 C H A P T E R Introduction Conditions for Migration...
  • Page 7 Live Upgrade Procedure Falling Back Overview Falling Back to the Cisco PGW 2200 Softswitch Software Release 9.7 without Platform Changes Falling Back to Solaris 8 and Cisco PGW 2200 Softswitch Release 9.5 or 9.6 Falling Back to Solaris 8 If Hard Drives Were Replaced During the Upgrade...
  • Page 8 Client/Server and Secure Connectivity Relationships HP OpenView Sample SNMP Configuration A P P E N D I X Configuring the Cisco PGW 2200 Softswitch to Send Alarms to HP OpenView Formatting Trap Messages Sample Installation Scripts A P P E N D I X Introduction Sample Output from install.sh...

  • Page 9: Document Objectives

    This guide describes the steps necessary to install and configure the Sun Solaris 10 operating system, and the Cisco PGW 2200 Softswitch software Release 9.8. This guide does not cover media gateway (MGW) or Cisco PGW 2200 Softswitch hardware installation. Note For instructions on installing these components, see the Cisco PGW 2200 Softswitch Hardware Installation Guide.

  • Page 10: Obtaining Documentation And Submitting A Service Request

    This document contains information that is related to Cisco PGW 2200 Softswitch software installation and configuration. For additional information on those subjects, see the documents at this URL: http://www.cisco.com/en/US/products/hw/vcallcon/ps2027/tsd_products_support_series_home.html You can also find the Cisco PGW 2200 Softswitch Documentation Map at the following URL: http://www.cisco.com/en/US/products/hw/vcallcon/ps2027/products_documentation_roadmaps_list.ht Other useful reference publications include: Overviews of the related telephony solutions—Describe the Cisco telephony solutions with which...

  • Page 11: Document Change History

    Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Added the new parameter, SIP.udp2tcp_byte_xover, in Table A-1, XECfgParm.dat File Configuration Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide “Migration from 21. The note advises users of the “Migration from Release 9.7 Table A-1, Cisco PGW 2200 Softswitch 9.x...
  • Page 12 9.8(1) OL-18083-02 9.8(1) OL-18083-02 9.8(1) OL-18083-01 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Change Date Change Summary December 9, 2009 Added two new parameters of the XECfgParm.dat file, *.IOI and *.ICID, in Added two footnotes in...

  • Page 13: Introduction

    Sun Solaris operating system and the Cisco PGW 2200 Softswitch software: • Cisco PGW 2200 Softswitch Release 9.8 and up, which requires the Sun Solaris Operating System Note The entire installation procedure takes approximately 2 hours to complete.

  • Page 14: Solaris 10, Cisco Pgw 2200 Softswitch Software Release 9.8 And Higher Software Release Preinstallation Checklists

    Higher Software Release Preinstallation Checklists Table 1-1 through installing the Solaris 10 operating system and the Cisco PGW 2200 Softswitch software Release 9.8 and higher. Before installing the Sun Solaris operating system, Solaris patches, and alarm card software, ensure that you collect the information and complete tasks listed in the following tables.

  • Page 15: Required Machine-Specific Information

    Preparing for Sun Solaris Operating System and Cisco PGW 2200 Softswitch Software Installation Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Software Release Preinstallation Checklists 1. There are two versions of the Cisco Solaris 10 Operating System Jumpstart Disk for Opteron-based platforms. If you are installing the Sun Solaris 10 Operating System on an X4640 Quad-core platform, use the 10/08 version (the latest version).

  • Page 16: Required Tasks

    Solaris 10, Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Software Release Preinstallation Checklists Table 1-3 Information Subnet address for each additional Ethernet IP address Netmask address for each additional Ethernet IP address Required Tasks Before you begin installing the Solaris 10 operating system, perform the tasks listed in...

  • Page 17: Supported Disk Drives

    Loading the Sun Solaris 10 Operating Environment, page 2-53 • For procedures on migrating to Solaris 10 and Cisco PGW 2200 Softswitch software Release 9.8, see Note Chapter 5, “Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8.”...

  • Page 18: C H A P T E R 2 Installing The Sun Solaris 10 Operating System

    If you purchased the Sun hardware platform from Cisco, the Sun Solaris 10 operating system, the operating environment, and the base Cisco PGW 2200 Softswitch software may already be installed. You can skip the installation of the software. You must install all of the Cisco PGW 2200 Softswitch software patches.

  • Page 19: Loading The Sun Solaris 10 Operating System

    — — c1t0d0 igb2 igb3 c3t0d0 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System Second Third Fourth c1t1d0 — — c1t1d0 — — c1t1d0 —...

  • Page 20: Installing The Sun Solaris 10 Operating System For Sparc-Based Platforms

    These instructions will note the differences between the sets of installation instructions. Step 1 Choose one of the following options to connect the Cisco PGW 2200 Softswitch: Connect to the Cisco PGW 2200 Softswitch through a console port.
  • Page 21 1MB of memory at addr 103e002000 1MB of memory at addr 1000000000 1MB of memory at addr File and args: - install All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System...
  • Page 22 - Selecting package (SUNWzebrar) - Selecting package (SUNWzebrau) - Selecting package (SUNWeurf) - Selecting package (SUNWgcmn) - Selecting package (SUNWeuodf) - Selecting package (SUNWxwacx) - Selecting package (SUNWpoolr) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...
  • Page 23 - WARNING: Changing the system's default boot device in the EEPROM Verifying space allocation - Total software size: Preparing system for Solaris install Configuring disk (c1t0d0) OL-18083-14 (c1t0d0s4) (c1t0d0s6) 376.86 Mbytes Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System...
  • Page 24 SUNWipoib...done. SUNWtavor...done. SUNWudapltu...done. SUNWudapltr...done. SUNWaudd...done. SUNWusb...done. SUNWusbs...done. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Chapter 2 Installing the Sun Solaris 10 Operating System 363.07 Mbytes remaining. 359.22 Mbytes remaining. 347.35 Mbytes remaining. 347.23 Mbytes remaining. 337.09 Mbytes remaining.
  • Page 25 55.16 Mbytes remaining. 55.14 Mbytes remaining. 54.43 Mbytes remaining. 54.17 Mbytes remaining. 54.09 Mbytes remaining. 53.21 Mbytes remaining. 51.67 Mbytes remaining. 50.48 Mbytes remaining. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System...
  • Page 26 SUNWmkcd...done. SUNWdtrc...done. SUNWdtrp...done. SUNWfctl...done. SUNWemlxs...done. SUNWemlxu...done. SUNWerid...done. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-10 Chapter 2 Installing the Sun Solaris 10 Operating System 50.11 Mbytes remaining. 50.08 Mbytes remaining. 49.24 Mbytes remaining. 48.61 Mbytes remaining.
  • Page 27 2.70 Mbytes remaining. 2.27 Mbytes remaining. 2.20 Mbytes remaining. 1.79 Mbytes remaining. 1.68 Mbytes remaining. 1.57 Mbytes remaining. 1.00 Mbytes remaining. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-11...
  • Page 28 This system is configured with NFS version 4, which uses a domain name that is automatically derived from the system's name services. The derived domain name is sufficient for most configurations. In a Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-12 All rights reserved.

  • Page 29: Installing The Sun Solaris 10 Operating System For Opteron-Based Platforms

    Connect a keyboard and monitor to the Cisco PGW 2200 Softswitch. • Cisco recommends that you connect to the Cisco PGW 2200 Softswitch using a keyboard and monitor. Note If you choose to connect through the console port, you need to ensure that Console Redirection is...
  • Page 30 Ensure that the CD-ROM is the first bootable device in the list. Choose the Advanced menu from the category selections at the top of the screen. If you connected to the Cisco PGW 2200 Softswitch using the console port, ensure Console Redirection is set to enable or always.
  • Page 31 - Selecting package (SUNWxwplt) - Selecting package (SUNWxwplr) - Selecting package (SUNWdtcor) - Selecting package (SUNWxwice) - Selecting package (SUNWxwrtl) OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-15...
  • Page 32 - Selecting package (SUNWrcmdc) - Selecting package (SUNWdtdmr) - Selecting package (SUNWtltk) - Selecting package (SUNWtnetc) - Selecting package (SUNWtnfd) - Selecting package (SUNWtnetd) - Selecting package (SUNWtnetr) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-16 OL-18083-14...
  • Page 33 347.35 Mbytes remaining. 347.23 Mbytes remaining. 337.09 Mbytes remaining. 335.16 Mbytes remaining. 334.65 Mbytes remaining. 315.55 Mbytes remaining. 315.27 Mbytes remaining. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-17...
  • Page 34 SUNWswmt...done. SUNWsolnm...done. SUNWses...done. SUNWsi3124...done. Completed software installation Solaris 10 packages partially installed Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-18 Chapter 2 Installing the Sun Solaris 10 Operating System 315.01 Mbytes remaining. 314.87 Mbytes remaining. 314.62 Mbytes remaining.
  • Page 35 All rights reserved. 1MB of memory at addr 103feec000 1MB of memory at addr 103fee0000 15MB of memory at addr 103f002000 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-19...
  • Page 36 When you use svcs -xv to see the details, you find the errors are for Sun Solstice Enterprise Master Agent and the CDE Print Viewer. The Cisco PGW 2200 Softswitch uses neither of the two applications. Ignore them while you log in on the platform.

  • Page 37: Installation Of Solaris Js11 Through Ilom

    Click Advanced tab in the BIOS setup utility. You see a screen similar to the one in OL-18083-14 2-30. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System “Configuring Your Figure 2-1.
  • Page 38 Highlight LAN Configuration in the list. Then press Enter. You see a screen similar to the one in Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-22 Advanced Tab in the BIOS Setup Utility on the Sun Netra X4270 Platform Figure 2-2.
  • Page 39 -> set /SP/network pendingipdiscovery=static -> set /SP/network commitpending=true OL-18083-14 LAN Configuration in the BIOS Setup Utility on the Sun Netra X4270 Platform Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-23...
  • Page 40 You see a screen similar to the one in Figure 2-3 Click the Remote Control tab. You will see a screen similar to the one shown in Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-24 Figure 2-3.
  • Page 41 Click Launch Service. If a pop up window appears for warnings and security, tick the trust point and click RUN. You see the Sun ILOM remote console as shown in Figure 2-5. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-25 OL-18083-14...
  • Page 42 If you do not get the error, the CD-ROM is probably not mounted or redirected. Keep this DOS window running in background. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-26 Sun ILOM Remote Console -u root -s changeme -p 2121 10.0.2.247...
  • Page 43 Figure 2-6 Set the boot option “AMI Virtual CDROM” to the first priority, as OL-18083-14 BIOS Setup Utility–Boot Tab Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System Figure 2-6: Figure 2-7...
  • Page 44 After you connect to the Sun server with a console cable, you will get a -> prompt. Enter the following command: -> start /SP/console Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-28 Set Priorities in Boot Tab...
  • Page 45 Re-open the console window of the server. Make sure there is a directory “cdrom” under the root “/”. If not, please make the directory with the command: bash# mkdir /cdrom OL-18083-14 12) X Terminal. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System for details. 2-29...

  • Page 46: Configuring Your Host

    This program will also halt the system. Do you want to continue (y/n) ? Enter y to continue the reconfiguration process and press Enter. Step 3 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-30 Chapter 2 /cdrom SunOS 5.10...
  • Page 47 15MB of memory at addr 16MB of memory at addr 992MB of memory at addr 1024MB of memory at addr All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 103feec000 103fee0000 103f002000...
  • Page 48 Solaris CD, and follow the instructions listed under Help. Networked --------- [X] Yes [ ] No ------------------------------------------------------------------------------- ESC-2_Continue Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-32 Chapter 2 ESC-6_Help Installing the Sun Solaris 10 Operating System OL-18083-14...
  • Page 49 The interface configuration prompts do not provide an option to return to a previous step or exit interface configuration. If you enter an incorrect value, power down the Cisco PGW 2200 Softswitch, power up the Cisco PGW 2200 Softswitch, and return to Step 4.
  • Page 50 Step 11 Note For machine-specific information such as host name, see your notes in Solaris Operating System and Cisco PGW 2200 Softswitch Software Installation” Table “Machine-Specific Checklist” Text similar to the following is displayed: - IP Address for bge0 ----------------------------------------------------------- Enter the Internet Protocol (IP) address for this network interface.
  • Page 51 IP address. ESC-6_Help A netmask must contain four sets of numbers Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System A default 2-35...
  • Page 52 Text similar to the following is displayed: - Default Route IP Address for bge0 -------------------------------------------- Enter the IP address of the default route. This entry will be placed in the Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-36 Chapter 2 ESC-6_Help “Site-Specific Information”...
  • Page 53 Netmask: 255.255.255.224 Enable IPv6: No Default Route: Specify one ESC-4_Change ESC-6_Help Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System Table 1-2 if you used the checklist to record the 2-37...
  • Page 54 DNS domain chosen for this system. concatenated, may not be longer than 250 characters. Search domain: yourdomain.com Search domain: Search domain: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-38 Chapter 2 ESC-6_Help If it is correct, press F2;...
  • Page 55 If it is correct, press F2; ESC-4_Change ESC-6_Help select one of the continents or oceans from the ESC-6_Help Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System You can specify a 2-39...
  • Page 56 [ ] Central Time - North Dakota - Oliver County [ ] Mountain Time [ ] Mountain Time - south Idaho & east Oregon ------------------------------------------------------------------------------- ESC-2_Continue Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-40 Countries and Regions -------------------------- [ ] United States [ ] Anguilla [ ] Antigua &...
  • Page 57 (1-12) : 09 (1-31) : 08 (0-23) : 02 : 58 ESC-6_Help If it is correct, press F2; (US/Eastern) ESC-4_Change ESC-6_Help Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-41...
  • Page 58 8 03:00:15 bge0 login: ROOT LOGIN /dev/console Step 30 If you want to enable root access to the Cisco PGW 2200 Softswitch via telnet, follow these steps: Edit the /etc/default/login file, and make the following changes: –...

  • Page 59: Platform-Specific Installation Procedures

    Installing SunVTS Framework as <SUNWvts> ## Installing part 1 of 1. OL-18083-14 2-43. SunOS 5.10 Generic January 2005 ./cdrom/core_finish/core_finish.sh ./cdrom/core_finish/core_finish.sh Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System “Platform-Specific Installation Procedures” 2-43...
  • Page 60 [ verifying class <none> ] Copyright 2006 Sun Microsystems, Inc. Use is subject to license terms. Installation of <SUNWvtsts> was successful. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-44 Chapter 2 Installing the Sun Solaris 10 Operating System All rights reserved.
  • Page 61 [ verifying class <none> ] Modifying /etc/opt/SUNWexplo/1280input.txt Modifying /etc/opt/SUNWexplo/alominput.txt Modifying /etc/opt/SUNWexplo/b1600input.txt Modifying /etc/opt/SUNWexplo/b1600switchinput.txt Modifying /etc/opt/SUNWexplo/ilominput.txt Modifying /etc/opt/SUNWexplo/indyinput.txt Modifying /etc/opt/SUNWexplo/ipmiinput.txt Modifying /etc/opt/SUNWexplo/saninput.txt Modifying /etc/opt/SUNWexplo/scinput.txt Modifying /etc/opt/SUNWexplo/se3kinput.txt Modifying /etc/opt/SUNWexplo/se6320input.txt Modifying /etc/opt/SUNWexplo/se6920input.txt Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-45 OL-18083-14...
  • Page 62 Installing Solaris Print - Client, (usr) as <SUNWpcu> ## Installing part 1 of 1. Copyright 2005 Sun Microsystems, Inc. Use is subject to license terms. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-46 Chapter 2 Installing the Sun Solaris 10 Operating System All rights reserved.
  • Page 63 Materiel Command, USAF, under agreement number F39502-99-1-0512. Additionally, err.c, lsearch.c, fnmatch.c, getcwd.c, snprintf.c, strcasecmp.c, fnmatch.h, err.h, and fnmatch.3 bear the following UCB license: OL-18083-14 All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-47...
  • Page 64 Approved patches will be installed in this order: 123526-01 Checking installed patches... Verifying sufficient filesystem capacity (dry run method)... Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-48 Chapter 2 All rights reserved. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE LIABLE...
  • Page 65 Changes for package FJSVfmd will not be applied to the system. Checking patches that you specified for installation. Done! Approved patches will be installed in this order: 119578-30 OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-49...
  • Page 66 Patch 118833-36 has been successfully installed. See /var/sadm/patch/118833-36/log for details Executing postpatch script... Patch packages installed: SUNW1394 SUNWatfsr SUNWatfsu SUNWaudd SUNWbart Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-50 Chapter 2 Installing the Sun Solaris 10 Operating System OL-18083-14...
  • Page 67 SUNWxcu4 SUNWxge Completed installation of core extra packages Start core hardening Changing EEPROM settings.. Enable recording of failed login attempts OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating System 2-51...
  • Page 68 Unmount the cdrom directory from the CD-ROM drive by entering the following command and pressing Enter: # umount /cdrom Eject the CD from the CD-ROM by entering the following command and pressing Enter: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-52 Chapter 2 swaplo...

  • Page 69: Loading The Sun Solaris 10 Operating Environment

    Software Package (CSCOh026) Installing the Verification Test Suite Script Package (CSCOh021) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment “Loading the Sun Solaris 10 lists the order in which the software packages...

  • Page 70: Installing The Sparc-Based Solaris 10 Patches Package (Cscoh022)

    Step 4 Type y and press Enter to continue. Text similar to the following is displayed: Installing Media Gateway Controller Solaris 10 Patch Cluster as <CSCOh0022> Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-54 Chapter 2 Media Gateway Controller Solaris 10 Patch Cluster (sparc) 3.0(6)
  • Page 71 #reboot -- -r OL-18083-14 Please be patient. You can follow the progress of the reboot -- -r Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment There are a large 2-55...

  • Page 72: Installing The Opteron-Based Solaris 10 Patches Package (Cscoh032)

    Select package(s) you wish to process (or 'all' to process all packages). (default: all) [?,??,q]: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-56 if you want to continue with the list for package installation. If you have “Obtaining Documentation and Submitting a Service Request”...
  • Page 73 2—Attempting to apply a patch that is already applied. 8—Attempting to patch a package that is not installed. 35—A later version of the patch has already been installed. OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-57...
  • Page 74 WARNING force load of misc /md-raid failed WARNING force load of misc /md-hotspares failed WARNING force load of misc /md-sp failed Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-58 8 11:14:25 GMT+8 2008 *** Please be patient.

  • Page 75: Installing The Solstice Disksuite (Cscoh023)

    If you have “Obtaining Documentation and Submitting a Service Request” Media Gateway Controller Solaris 10 DiskSuite (sparc,i386) 3.0(6) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-59...
  • Page 76 You can see the number of sectors allocated in the column marked Sector Count If you do not see a line which shows that partition 4 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-60 Chapter 2 /opt/sun_install/DiskSuite/DiskSuite_1.log...
  • Page 77 12302784 10247232 0 143349312 143349311 8201856 22550016 50880 22600896 116647488 139248383 139248384 4100928 143349311 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Last Sector Mount Directory 12302783 22550015 /var 8201855...
  • Page 78 Enter file name["./format.dat"]: format> Searching for disks...done AVAILABLE DISK SELECTIONS: 0. c1t0d0 <SUN72G cyl 14087 alt 2 hd 24 sec 424> Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-62 - select a disk - select (define) a disk type...
  • Page 79 2216 - 2220 24.84MB 2221 - 13683 55.62GB 13684 - 14086 1.96GB - select a disk Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Blocks (403/0/0) 4100928 (1007/0/0) 10247232 (14087/0/0) 143349312...
  • Page 80 This is part 2 of the script that installs Disk Suite on an PGW system. It assumes that Solaris 10 is installed Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-64 Chapter 2 - select (define) a disk type...
  • Page 81 Resync in progress: 94 % done Resync in progress: 96 % done Resync in progress: 98 % done The Disk Suite installation is now complete OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-65...
  • Page 82 Step 15. Step 13 Type the following command and press Enter to reboot your system. #/usr/sbin/shutdown -g0 -y -i6 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-66 Chapter 2 Installing the Sun Solaris 10 Operating System or the 2-69.

  • Page 83: Rebooting From The Mirrored (Secondary) Disk On Sparc-Based Platforms

    “Rebooting from the Mirrored (Secondary) Disk on Opteron-based 2-69. If you want to return to the list for package installation, go to Step Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Table 2-2...
  • Page 84 This completes the procedures for rebooting from the mirrored (secondary) disk on Sparc-based platforms. If you want to return to the list for package installation, go to Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-68 Chapter 2...

  • Page 85: Rebooting From The Mirrored (Secondary) Disk On Opteron-Based Platforms

    # /usr/sbin/shutdown -g0 -y -i6 Text similar to the following is displayed: OL-18083-14 Start Block Dbase State Reloc Hot Spare Okay Device ID id1,sd@n500000e01861aae0 id1,sd@n500000e01860a690 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-69...

  • Page 86: Removing The Solstice Disksuite

    This section applies to the Cisco PGW 2200 Softswitch Host running either the Cisco PGW 2200 Softswitch or HSI software. You must remove Cisco PGW 2200 Softswitch, HSI, or BAMS software before you remove the DiskSuite. The following procedure works only from platforms that have been mirrored by use of the procedure provided in the (CSCOh023)”...

  • Page 87: Installing The Log And Spool File Systems (Cscoh024)

    Removal of <CSCOh023> was successful. This completes the DiskSuite removal. Installing the Log and Spool File Systems (CSCOh024) This section applies to a Cisco PGW 2200 Softswitch host with 18-GB disk drives running the Note Cisco PGW 2200 Softswitch software.
  • Page 88 Processing package instance <CSCOh024 from </var/tmp/CSCOh024.pkg Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-72 18-GB Disk 1 Partition Table (Cisco PGW 2200 Softswitch with Log and Spool Package) 18-GB Disk 2 Partition Table (Cisco PGW 2200 Softswitch with Log and Spool...
  • Page 89 You must now change directories to /opt/sun_install/Log_Spool and run the ./install_log_spool script as root. Change directory to /opt/sun_install/Log_Spool and run the install_log_spool script. Step 6 OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-73...
  • Page 90 Loading the Sun Solaris 10 Operating Environment Note You must first shut down the Cisco PGW 2200 Softswitch before running the install_log_spool script. # cd /opt/sun_install/Log_Spool # ./install_log_spool Text similar to the following is displayed: Platform is SUNW,Ultra-80 Searching for disks...done...
  • Page 91 - display the current table - write partition map and label to the disk Flag Cylinders Size 1.00GB Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Blocks (726/0/0) 2097414 2-75...
  • Page 92 Enter new starting cyl[0]: 0 Enter partition size[71127180b, 24620c, 34730.07mb, 33.92gb]: 24620c partition> 3 Part 3 unassigned Enter partition id tag[unassigned]: unassigned Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-76 Flag Cylinders Size 726 - 3629 4.00GB...
  • Page 93 - set 8-character volume name - execute <cmd>, then return 28450872 sectors in 9848 cylinders of 27 tracks, 107 sectors Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Blocks (0/0/0)

  • Page 94: Uninstalling The Log And Spool File System

    If you want to save log files before running this script, then exit and do so now Do you want to continue? (y/n) [N] y Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-78 OL-18083-14...

  • Page 95: Installing Cisco Bams Archive Partition (Cscoh027)

    Select package(s) you wish to process (or 'all' to process all packages). (default: all) [?,??,q]: OL-18083-14 Media Gateway Controller BAMS Archive Partition Package (sparc) 3.0(6) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-79...
  • Page 96 Installing Media Gateway Controller BAMS Archive Partition Package as <CSCOh027> ## Installing part 1 of 1. [ verifying class <none> ] ## Executing postinstall script. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-80 Chapter 2 Installing the Sun Solaris 10 Operating System...
  • Page 97 - defect list management - search for backup labels - read and display labels - set 8-character volume name - execute <cmd>, then return Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-81...
  • Page 98 Enter partition id tag[root]: unassigned Enter partition permission flags[wm]: wm Enter new starting cyl[806]: 0 Enter partition size[4100928b, 403c, 402e, 2002.41mb, 1.96gb]: 0c Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-82 c1t1d0 SUN72G 14087 - select a disk...
  • Page 99 Flag Cylinders Size Flag Cylinders Size 0 - 14086 68.35GB Flag Cylinders Size Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Blocks (1007/0/0) 10247232 Blocks (806/0/0) 8201856 Blocks (5/0/0) 50880...
  • Page 100 Mounting /opt/CiscoBAMS/CDR/archive Success!!! The Cisco BAMS archive partition installation is now complete. If you want to return to the list for package installation, go to Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-84 Flag Cylinders Size 0 - 14086 68.35GB...

  • Page 101: Installing The Sparc-Based Communications And Alarm Software Package (Cscoh026)

    Media Gateway Controller PGW Specific Solaris 10 packages(sparc) 3.0(6) Cisco Systems, Inc. OL-18083-14 Media Gateway Controller PGW Specific Solaris 10 packages (sparc) 3.0(6) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-85...
  • Page 102 Enter the following commands to change directories and execute the installation script. cd /opt/sun_install/SolPkg ./install_SolPkg.sh Text similar to the following is displayed: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-86 Chapter 2 Installing the Sun Solaris 10 Operating System...
  • Page 103 ./SUNWftpr/install/r.manifest, 1044 bytes, 3 tape blocks x ./SUNWftpr/pkginfo, 452 bytes, 1 tape blocks x ./SUNWftpr/pkgmap, 982 bytes, 2 tape blocks x ./SUNWftpr/reloc, 0 bytes, 0 tape blocks Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-87 OL-18083-14...
  • Page 104 ./SUNWftpu/reloc/usr/sbin, 0 bytes, 0 tape blocks spawn pkgadd -d . SUNWftpu Processing package instance <SUNWftpu> from </tmp> FTP Server, (Usr)(sparc) 11.10.0,REV=2005.01.21.15.53 Copyright 2001-2003 Sun Microsystems, Inc. All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-88 OL-18083-14...
  • Page 105 If you did not receive a copy of the license, it may be obtained online at http://www.wu-ftpd.org/license.html OL-18083-14 WU-FTPD SOFTWARE LICENSE Where redistribution of this software Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment All rights reserved. 2-89...
  • Page 106 LIABILITY, OR TORT (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-90 Chapter 2...
  • Page 107 ## Removing pathnames in class <none> /opt/SUNWvts/man/man1m/vtsui.1m OL-18083-14 All rights reserved. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE LIABLE SunVTS Man Pages (sparc) 6.4,REV=2007.07.05.12.46 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-91...
  • Page 108 Removal of <SUNWvtsts> was successful. spawn pkgrm SUNWvts The following package is currently installed: SUNWvts SunVTS Framework Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-92 SunVTS for Tests (sparc) 6.4,REV=2007.07.05.12.46 Chapter 2 Installing the Sun Solaris 10 Operating System...
  • Page 109 SUNWvtsts/archive, 0 bytes, 0 tape blocks x SUNWvtsts/archive/none.bz2, 9661272 bytes, 18870 tape blocks x SUNWvtsts/install, 0 bytes, 0 tape blocks x SUNWvtsts/install/checkinstall, 1199 bytes, 3 tape blocks Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-93 OL-18083-14...
  • Page 110 ## Verifying package dependencies. ## Verifying disk space requirements. ## Checking for conflicts with packages already installed. ## Checking for setuid/setgid programs. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-94 Chapter 2 Installing the Sun Solaris 10 Operating System All rights reserved.
  • Page 111 Installation of <SUNWvtsmn> was successful. Archive: 137324-01.zip creating: 137324-01/ creating: 137324-01/SUNWvts/ inflating: 137324-01/SUNWvts/pkgmap inflating: 137324-01/.diPatch inflating: 137324-01/patchinfo inflating: 137324-01/prepatch inflating: 137324-01/README.137324-01 OL-18083-14 All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-95...
  • Page 112 Do you want to continue with the installation of <SUNWnfsckr> [y,n,?] y Installing Network File System (NFS) client kernel support (Root) as <SUNWnfsckr> ## Installing part 1 of 1. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-96 Chapter 2 Installing the Sun Solaris 10 Operating System All rights reserved.
  • Page 113 ## Processing package information. ## Processing system information. 5 package pathnames are already properly installed. OL-18083-14 All rights reserved. All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-97...
  • Page 114 Copyright 2005 Sun Microsystems, Inc. NTP, (Usr)(sparc) 11.10.0,REV=2005.01.21.15.53 Copyright 2005 Sun Microsystems, Inc. Installation of <SUNWntpu> was successful. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-98 Chapter 2 Installing the Sun Solaris 10 Operating System All rights reserved.

  • Page 115: Installing The Opteron-Based Communications Software Package (Cscoh036)

    You must reboot your system for the changes to take effect. Type yes and press Enter. Step 7 If you require ftp access to your Cisco PGW 2200 Softswitch by Cisco BAMS or some other product, type the following command and press Enter:...
  • Page 116 Enter the following commands to change directories and execute the installation script: Step 5 cd /opt/sun_install/SolPkg ./install_SolPkg.sh Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-100 Chapter 2 Media Gateway Controller PGW Specific Solaris 10 packages (i386) 3.0(6)
  • Page 117 ./SUNWftpr/install/copyright, 93 bytes, 1 tape blocks x ./SUNWftpr/install/depend, 1036 bytes, 3 tape blocks x ./SUNWftpr/install/i.ftpaccess, 2849 bytes, 6 tape blocks OL-18083-14 All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-101...
  • Page 118 ./SUNWftpu/archive, 0 bytes, 0 tape blocks x ./SUNWftpu/archive/none.bz2, 98668 bytes, 193 tape blocks x ./SUNWftpu/install, 0 bytes, 0 tape blocks x ./SUNWftpu/install/copyright, 8644 bytes, 17 tape blocks Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-102 OL-18083-14...
  • Page 119 Portions Copyright (c) 1998 Sendmail, Inc. OL-18083-14 All rights reserved. WU-FTPD SOFTWARE LICENSE Where redistribution of this software Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment All rights reserved. 2-103...
  • Page 120 University nor the names of its contributors may be used to endorse or promote products derived from this software without specific prior written permission. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-104 Chapter 2...
  • Page 121 SUNWvtsmn OL-18083-14 IN NO EVENT SHALL WASHINGTON All rights reserved. IN NO EVENT SHALL THE REGENTS OR CONTRIBUTORS BE LIABLE Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-105...
  • Page 122 ## Verifying package <SUNWvtsts> dependencies in global zone ## Processing package information. ## Removing pathnames in class <none> /opt/SUNWvts/lib/probe/xnetlbtest_probe.so /opt/SUNWvts/lib/probe/vmemtest_probe.so Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-106 SunVTS man pages (i386) 6.4,REV=2007.07.05.13.25 SunVTS Framework (Root) (i386) 6.4,REV=2007.07.05.10.11...
  • Page 123 Use is subject to license terms. ## Executing checkinstall script. Using </opt> as the package base directory. ## Processing package information. OL-18083-14 All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-107...
  • Page 124 137325-01/SUNWvts/reloc/SUNWvts/README inflating: 137325-01/SUNWvts/reloc/SUNWvts/README.64 Patch 137325-01 has been successfully installed. See /var/sadm/patch/137325-01/log for details Patch packages installed: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-108 Chapter 2 Installing the Sun Solaris 10 Operating System All rights reserved.
  • Page 125 All rights reserved. All rights reserved. All rights reserved. All rights reserved. All rights reserved. All rights reserved. All rights reserved. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-109...
  • Page 126 You must reboot your system for the changes to take effect. Type yes and press Enter: Step 7 If you require ftp access to your Cisco PGW 2200 Softswitch by Cisco BAMS or some other product, Step 8 type the following command and press Enter: svcadm enable ftp If you need to disable the ftp communications software, use the svcadm disable ftp command.

  • Page 127: Installing The Verification Test Suite Script Package (Cscoh021)

    Installing the Verification Test Suite Script Package (CSCOh021) The Verification Test Suite (VTS) provides an optional script designed to test configured Sun Solaris 10 platforms used for Cisco PGW 2200 Softswitch, BAMS, and HSI products. VTS test instructions support the following interface cards: •...

  • Page 128: Using The Sunvts Test Package

    Using the SunVTS Test Package Use the SunVTS program to test the following: • CPUs • Memory • Ethernet cards Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-112 Chapter 2 Installing the Sun Solaris 10 Operating System “Obtaining OL-18083-14...

  • Page 129: Normal Unit Test

    Checking to see if vtsk is running starting vtsk giving vtsk a chance to start VTS probe output: Processor(s) OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-113...
  • Page 130 Host ID: 18089793 Domain Name: e1000g2(nettest) Host_Name: Host Address: 172.16.101.119 Host ID: 18089793 Domain Name: e1000g3(netlbtest) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-114 Chapter 2 Installing the Sun Solaris 10 Operating System Sun Microsystems i86pc OL-18083-14...
  • Page 131 System Test done Central Processor Unit Test all done OL-18083-14 /dev/term/a : /devices/ ... :a USB Keyboard Assuming only one CPU installed Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-115...
  • Page 132 Total number of network interfaces: 4 Number of DVD/CD drives : CD-ROM/DVD drives : c3t0d0 Number of LOM or TSALARM devices: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-116 Chapter 2 Installing the Sun Solaris 10 Operating System OL-18083-14...

  • Page 133: Running A Test In Brief Mode

    # /opt/sun_install/vts_script brief OL-18083-14 8064MB 10392MB SSSSSS SSSSSS for the approximate amount of time the test will take on the different platforms Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment 2-117...

  • Page 134: Running A Test In Full Mode

    # pkgrm CSCOh021 Text similar to the following is displayed: The following package is currently installed: CSCOh021 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-118 Sample Estimates of VTS Script Execution Times Brief Mode Execution Time...

  • Page 135: Configuring Lights-Out Management (Lom) Or The Integrated Lights Out Manager (Ilom)

    Removal of <CSCOh021> was successful. This completes the Sparc-based Solaris 10 Patch cluster installation procedures. For Cisco PGW 2200 Softswitch Hosts: The Cisco PGW 2200 Softswitch software can now be loaded. For Cisco HSI: The Cisco HSI software can now be loaded.

  • Page 136: Configuring Lom On Sun Fire V40Z Platform

    Figure 2-8 Step 2 Accept the agreement in the Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-120 V40z Servers--Installation Guide. Follow the steps in “Assigning Static V20z and Sun Fire Figure 2-8...
  • Page 137 A window similar to the one in OL-18083-14 Create Initial Manager-level User Warning Message Window Figure 2-11 is displayed. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Figure 2-10 is displayed. 2-121...

  • Page 138: Configuring Ilom On The Sun Fire X4640 Platform

    Configure the terminal device or the terminal emulation software running on a laptop or a PC to the following settings: • 8N1: eight data bits, no parity, one stop bit • 9600 baud Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-122 LOM Screen Chapter 2 Installing the Sun Solaris 10 Operating System OL-18083-14...
  • Page 139 Locate button/LED (white) PCI-X PCIe card slots card slots connector Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment Power/OK LED (green) 10/100 Ethernet port (for net management) USB ports Video...
  • Page 140 Enter the IP address of the SP in the browser. For example, enter https://10.10.10.1 in the browser. Press Enter. A window similar to Figure 2-13 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-124 Figure 2-13 is displayed.

  • Page 141: Configuring Ilom On The Sun Netra X4270 Platform

    “Installation of Solaris JS11 through ILOM” section on page 2-21 redirecting local PC CD-ROM device. OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Loading the Sun Solaris 10 Operating Environment for detailed steps of for detailed steps of...
  • Page 142 Chapter 2 Installing the Sun Solaris 10 Operating System Loading the Sun Solaris 10 Operating Environment Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 2-126 OL-18083-14...

  • Page 143: Chapter 3 Installing The Cisco Pgw 2200 Softswitch Software Release 9.8 And Higher

    This chapter describes how to install Cisco PGW 2200 Softswitch and later releases of the Cisco PGW 2200 Softswitch software. If you already have Cisco PGW 2200 Softswitch Release 9.8(1) installed, and you want to upgrade to the latest patch level, do not use this document. Use the following two documents: •...

  • Page 144: Cautions, Notes, And Tips

    - Old *.tar files - User-generated toolkit files (in the /var/cust_specific/toolkit directory) Be sure to follow the Cisco PGW 2200 Softswitch software installation sequence listed in Caution Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases” section on page...

  • Page 145: Installing Cisco Pgw 2200 Softswitch Software On A Simplex System

    Note Remove /usr/ucb from the path environment variable before the initial installation of the Cisco PGW 2200 Softswitch software. However, if /usr/ucb is needed, make sure that it is located in the path variable in the user profile after /usr/sbin.
  • Page 146 Enter y to install the CSCOgu000 utilities package on this host. Step 6 The system begins to display various configuration settings for the Cisco PGW 2200 Softswitch Step 7 software. We recommend that you accept the default values (by pressing Enter). You can, however, specify a different user ID and a group ID.
  • Page 147 Uncompressing cfgM Installing chk_inv Installing cisco Uncompressing diskmonitor Uncompressing engine.no_smartalloc Uncompressing engine.smartalloc Uncompressing foverd Uncompressing ioChanMgr OL-18083-14 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 148 Chapter 3 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases Uncompressing lmbase Installing lmgrd Uncompressing lmreport Installing lmutil Uncompressing measMgr Uncompressing mmBldCfg Uncompressing mmSAgt Uncompressing mmdbd...
  • Page 149 The default port number is 16001. The daemon will run on the default port number (16001). OL-18083-14 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 150 Chapter 3 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases Processing /opt/TimesTen/tt60/PERL/perl.tar ... System logging appears to be configured correctly. (TimesTen syslog messages should be recorded in the file '/var/adm/messages') Installing server components ...
  • Page 151 Installing new .dat files in /opt/CiscoMGC/etc Installation of <CSCOgc001> was successful. Miscellaneous Protocols #################################### #################################### BTNUP_BTNR167 BTNUP_IUP DPNSS_BTNR188 #################################### OL-18083-14 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases IETF_SIP Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 152 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases SS7 Protocl Family ######################### ######################### ANSISS7_2K ANSISS7_92 ANSISS7_C2 ANSISS7_C3 ANSISS7_E1 ANSISS7_STANDARD GR317 ######################### Q761 Version 1 Protocol Family ########################################################################################## ########################################################################################## ETS_300_121 ETS_300_356 HONGKONG ISUPV1_POLI Q761_ARGENTINA Q761_ARGENTINA_C2 Q761_AUSTRL Q761_AUSTRL_C2...
  • Page 153 The tt60 daemon has stopped successfully. Installation completed Wed Sep 24 03:52:32 EDT 2008 OL-18083-14 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Step Step 10).

  • Page 154: Installing The Cisco Security Package (Cscoh020)

    Step 13 page 3-12 to install the Cisco Security Package. This completes installation of the Cisco PGW 2200 Softswitch software on a simplex host system. If you have a fault-tolerant system, proceed to the Otherwise, proceed to the next step.
  • Page 155 Change directory to /opt/sun_install and run the install script by entering the following commands: # cd /opt/sun_install # ./CiscoSec.sh install /tmp/security.log OL-18083-14 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases This installation Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 3-13...
  • Page 156 Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher Releases Text similar to the following is displayed: Output will be logged in You are running as root - Good... Operating System: SunOS 5.10 For security reasons, root access from outside the console is disabled by default.

  • Page 157: Enabling Sudo

    If the installation of this package returns an error code of 1 for any of the associated files, you can ignore the error. Those files have encountered an error, but the installation is correct. You can now begin configuring your Cisco PGW 2200 Softswitch software in the Step 11 MGC Environment Configuration Tool”...

  • Page 158: Installing The License File

    PGW 2200 at: http://www.cisco.com/en/US/docs/voice_ip_comm/pgw/9/feature/module/9.7_3_/FlexLM.html Note You must install the license file on both the active and the standby Cisco PGW 2200 Softswitch for it to function properly. Installing the License File if the Cisco PGW 2200 Softswitch is NOT Running If the Cisco PGW 2200 Softswitch is not in a running state, perform the following steps.

  • Page 159: Installing The License File If The Cisco Pgw 2200 Softswitch Is Running

    Installing the License File if the Cisco PGW 2200 Softswitch is Running If the Cisco PGW 2200 Softswitch is in a running state, perform the following steps. Save the license file (.lic) to a temporary directory on your hard disk.
  • Page 160 Exit the provisioning session on the active host and continue to provisioned after it is installed on the active Cisco PGW 2200 Softswitch host, the standby host is not synchronized with the active host. As a result, a forced switchover might cause the switchover to fail.

  • Page 161: Configuring The Cisco Pgw 2200 Softswitch Software

    Configuring the Cisco PGW 2200 Softswitch Software Revised: February 21, 2012, OL-18083-14 Introduction This chapter describes how to configure Release 9.8 of the Cisco PGW 2200 Softswitch software. Quick Guide to Configuring the Cisco PGW 2200 Softswitch Software Note The Cisco PGW 2200 Softswitch software files and processes are located in the /opt/CiscoMGC directory.

  • Page 162: C H A P T E R 4 Configuring The Cisco Pgw 2200 Softswitch Software

    Configuring the Data Dumper Configuring the Data Dumper to Support Cisco BAMS Note For further information on configuring the Cisco PGW 2200 Softswitch software, see the Cisco PGW 2200 Softswitch Release 9.8 Provisioning Guide. Before You Start Before you start, verify the following: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...

  • Page 163: Software Directory Structure

    “Obtaining Documentation and Submitting a Service Request” section on page x support contact information.) • Ensure that you have access to the console port on your Cisco PGW 2200 Softswitch host. The Cisco PGW 2200 Softswitch software is case-sensitive. Ensure that you enter parameter names Caution correctly, or the maximum number of configurations will not be modified.

  • Page 164: Initial Cisco Pgw 2200 Softswitch Software Configuration

    Cisco PGW 2200 Softswitch software on the standby host. As the Cisco PGW 2200 Softswitch software comes up, the data on the standby host is synchronized with the data on the active host. Initiate switchover to bring the active host to the standby state.
  • Page 165 Default: 02 Identifies the Cisco PGW 2200 Softswitch platform. The default value 1 applies to Fault Tolerant mode and Standalone mode. Default: 1 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Initial Cisco PGW 2200 Softswitch Software Configuration...
  • Page 166 Initial Cisco PGW 2200 Softswitch Software Configuration Table 4-3 Parameter *.SysConnectDataAccess TCAP.avgInvokePerDialog Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Chapter 4 Configuration Parameters (continued) Description Controls whether data access is enabled or disabled (if the engine attempts to connect to the MMDB or to call screening database at startup).
  • Page 167 ASN (Auxiliary Signaling Network). Default: 01 Specify virtual IP addresses for the Cisco PGW 2200 Softswitch that are used for SIP Failover Support. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Initial Cisco PGW 2200 Softswitch Software Configuration...

  • Page 168: Parameters Required For Initial Setup

    Note These parameters are located at the top of the XECfgParm.dat file, thus making it easier to find the parameters required for initial setup. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Chapter 4 Configuration Parameters (continued)

  • Page 169: Using The Cisco Mgc Environment Configuration Tool

    Foverd.ipPeerPortA (con 2) Pom.dataSync False Diskmonitor.OptFileSys <blank> NumberOfThreads Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Initial Cisco PGW 2200 Softswitch Software Configuration Changed Values 2, if slave 02, if standby 02, if standby 01, if standby...
  • Page 170 SWITCHED-MGC specifies a dynamic connection such as a trunk group; NAILED-UP specifies a permanent connection such as a sigpath. Indicates the whether the Cisco PGW 2200 Softswitch is operating as a stand-alone system or in a fault-tolerant configuration with an active and standby Cisco PGW 2200 Softswitch.
  • Page 171 The Cisco PGW 2200 Softswitch comments out old parameters and inserts the new parameters. The Cisco PGW 2200 Softswitch inserts a history line to note updated parameters. The Cisco PGW 2200 Softswitch moves required parameters to the top of the file for convenience. •...

  • Page 172: Configuring Groups And Users

    Configuring Groups and Users You must set up groups and users for the Cisco PGW 2200 Softswitch software on each host server. A user must be a member of the “mgcgrp” group to use certain Cisco PGW 2200 Softswitch software functions, such as Man-Machine Language (MML).

  • Page 173: Adding A User With Minimal Mml Privileges

    # passwd username Step 5 Type the user’s password and press Enter twice when prompted. Step 6 Log in to the Cisco PGW 2200 Softswitch as the new user. Step 7 Enter the following command and press Enter: % mml The MML interface launches.

  • Page 174: Configuring Snmp Support Resources

    In a fault tolerant configuration, the SNMP agent subsystem runs on both the active and standby machines. If your system is running Cisco PGW 2200 Softswitch software Release 9.3(2) or later, go to the Note “Migrating the SNMP Configuration to a More Secure Environment (for Cisco PGW 2200 Softswitch Release 9.3(2) or Later)”...

  • Page 175: Migrating The Snmp Configuration To A More Secure Environment (For Cisco Pgw 2200 Softswitch Release 9.3(2) Or Later)

    4-20. Before You Run the config-snmp Utility If you have completed a first-time installation of the Cisco PGW 2200 Softswitch software with Release Note 9.8 and its associated patches, copy the snmpd.cnf.tmpl to snmpd.cnf before your run the config-snmp utility.

  • Page 176: Running The Config-Snmp Utility

    Running the config-snmp Utility Perform the following steps to run the config-snmp utility: Make sure your system has the latest Cisco PGW 2200 Softswitch patches on both Host A and Host B. Step 1 See the Release Notes for Cisco PGW 2200 Softswitch Release 9.8(1) for detailed information on software patches.
  • Page 177 Enter a selection (1 through 25) or 'q' to quit to Main Menu: Step 6 Enter your selection number (1 through 25) to view your configuration entries. OL-18083-14 May 19 ? SNMPD Configuration Main Menu Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SNMP Support Resources =================== 4-17...

  • Page 178: Adding An Snmp Community Entry

    ReadWriteNotify snmpv2c ApplicationsView ApplicationsView ApplicationsView ReadWriteNotify usm ApplicationsView ApplicationsView ApplicationsView ReadAndNotifyToAll snmpv1 ApplicationsView - ApplicationsView ReadAndNotifyToAll snmpv2c ApplicationsView - ApplicationsView Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-18 Chapter 4 Step 6, above (of the section...
  • Page 179 Enter a selection number, 1 through 6. OL-18083-14 [y]/[n]? Icomname1 comname1 ReadAndNotifyToAll localSnmpID - - nonVolatile SNMPD Configuration Main Menu Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SNMP Support Resources Are you sure that you want to add this =================== 4-19...

  • Page 180: Deleting An Snmp Community

    Enter y to delete SNMP Community (if you enter n to cancel the deletion, you return to the SNMPD Configuration Main Menu): Text similar to the following is displayed: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-20 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software 4-24.

  • Page 181: Adding A Trap Destination

    The IP Address (Target Address) listed below is an example of existing Trap entries. OL-18083-14 Are you sure that you want to delete this [y]/[n]? SNMPD Configuration Main Menu Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SNMP Support Resources =================== 4-21...
  • Page 182 Adding a Trap Destination, page 4-21 Deleting a Trap Destination, page 4-23 • Activating the New Settings, page 4-24 • Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-22 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software ===================...

  • Page 183: Deleting A Trap Destination

    Enter a selection (1 through 6) or 'q' to quit: OL-18083-14 =================== [n]/[y]? Are you sure that you want to delete this Trap Entry SNMPD Configuration Main Menu Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SNMP Support Resources =================== 4-23...

  • Page 184: Activating The New Settings

    The procedure for activating the new settings is now complete and you are exited from the config-snmp utility. Proceed to the following section, Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-24 Chapter 4...

  • Page 185: Verifying The Snmp Configuration Migration

    If you select 12 from the SNMPD Configuration Main Menu, the snmpCommunityEntry is displayed, showing the changes you made: Note The following entries are examples only. OL-18083-14 SNMPD Configuration Main Menu Entries Menu =================== Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SNMP Support Resources =================== 4-25...

  • Page 186: Configuring The Execution Environment

    Environment” section on page 4-26 need assistance, see the page Configuring the Execution Environment This section provides instructions for configuring the Cisco PGW 2200 Softswitch software execution environment and contains the following topics: • Configuring Basic System Information, page 4-29 •...

  • Page 187: Changing Xecfgparm.dat File Parameters

    Do not modify the processes.dat file. This XECfgParm.dat file should remain unmodified, as delivered with the Cisco PGW 2200 Softswitch software. If this file is modified, procM may core dump when you start the Cisco PGW 2200 Softswitch software.

  • Page 188: Changing Xecfgparm.dat File Parameters In A Running Fault Tolerant System

    Log in to the active host (Host X) and make your changes. See Parameters” section on page 4-27 Log in to the standby host (Host Y) as root and stop the Cisco PGW 2200 Softswitch software by Step 2 entering the following command: # /etc/init.d/CiscoMGC stop...

  • Page 189: Configuring Basic System Information

    To determine the desired platform state at initialization, enter one of the following values: • master—If you have two (active and standby) Cisco PGW 2200 Softswitch hosts, and you are editing the file on the active host • slave—If you have two (active and standby)
  • Page 190 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software Modification To identify the local Cisco PGW 2200 Softswitch host in a fault tolerant system, enter the same value that you used for *.transpathID. If you have two Cisco PGW 2200 Softswitch hosts in a fault Note tolerant system, enter this value in the *.peerTranspathID...

  • Page 191: Specifying Ip Addresses

    To specify IP addresses, modify the following parameters in the first section of the XECfgParm.dat file: OL-18083-14 Modification To identify the local Cisco PGW 2200 Softswitch host in a fault tolerant system, enter any one- or two-digit integer. Note If you have two Cisco PGW 2200 Softswitch hosts in a fault tolerant system, this number must be different in the XECfgParm.dat file for each host.
  • Page 192 Configuring the Execution Environment Note If there are two Ethernet interfaces defined on the Cisco PGW 2200 Softswitch, it is mandatory to have these on distinct subnets. For example, consider the following configuration: *.IP_AddrLocalA = 172.22.119.108 *.IP_AddrLocalB = 172.22.119.54 This is not a valid combination because they are on the same subnet. The following example illustrates a valid combination: *.IP_AddrLocalA = 172.22.119.108...

  • Page 193: Configuring Geographic Separation Of Active And Standby Hosts

    *.Virtual_IP_Addr1 *.Virtual_IP_Addr2 Configuring Geographic Separation of Active and Standby Hosts This subsection describes how to configure Cisco PGW 2200 Softswitch hosts that are geographically separated and positioned on different subnets, such as for a campus or WAN. Table 4-6 presents limitations, implications, and caveats taht pertain to remotely locating (physical...
  • Page 194 Release 9.5(2) *.AllLinksFailCausesFailover added in Release 9.4(1) Setting for XECfgParm.dat parameter replicator.reconnectInterval Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-34 Chapter 4 Geographic Separation Requirements (continued) Condition Controls the severity level of the All ISDN IP Conn Fail alarm.
  • Page 195 For the above example, the following next hop address should be configured by editing the XECfgParm.dat parameter as follows: In the Active PGW XECfgParm.dat parameter: *.IP_NextHop1 = 172.22.121.1 OL-18083-14 and do the following procedures: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring the Execution Environment Table 4-7 Step 4-35...
  • Page 196 Parameter *.ipAddrLocalA *.ipAddrPeerA *.ipAddrLocalB *.ipAddrPeerB *.IP_Addr1 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-36 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software Modification Enter the first local IP address; used for checkpointing and switchover heartbeats.

  • Page 197: Configuring Engine Parameters

    Set automatically based on the type of Cisco PGW 2200 Softswitch selected in engine.SysVirtualSwitch. Any attempt to modify this value is overwritten. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring the Execution Environment 4-37...
  • Page 198 Configuring the Execution Environment Parameter engine.SendHardwareBlock engine.SysCdrCollection engine.SysGRSTimerInterval engine.SysGRSBlockSize Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-38 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software Modification To enable the Cisco PGW 2200 Softswitch to send...

  • Page 199: Setting The Call Cutoff Timer

    Configuring the Cisco PGW 2200 Softswitch Software Parameter engine.SysGeneratedCode *.SysConnectDataAccess Setting the Call Cutoff Timer The Cisco PGW 2200 Softswitch call cutoff timer is disabled by default. To set the call cutoff timer, modify the following parameter in the XECfgParm.dat file: Parameter *.CallCutoffTimer Enabling Call Screening To initialize the database that stores call screening information, modify the following parameter in the Engine section of the XECfgParm.dat file:...

  • Page 200: Configuring Call Detail Record File Output

    Configuring Call Detail Record File Output To configure call detail record (CDR) file output, modify the following parameters in the Data Dumper and Engine sections of the XECfgParm.dat file: Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-40 Chapter 4...
  • Page 201 The M setting is mandatory when operating the Cisco PGW 2200 Softswitch in conjunction with the Cisco BAMS adjunct. The default is M in Cisco PGW 2200 Softswitch Release 9.8(1). Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring the Execution Environment 4-41...

  • Page 202: Configuring The Clearing Location And Default Location Parameters

    The ClearingLocation and DefaultLocation parameters are used to determine a call’s location value. If you require a value other than the default to be sent to the switch, use these parameters to override the Clearing Location and Default Location fields in the Call Context. For example, if you need to define a customer-specific default location for your system, set this value in the DefaultLocation parameter, which overrides the default location specified in the protocol type definition.
  • Page 203 Clearing Location in Call Context with LOCATION_ PACKET_MANAGER 13—The Cisco PGW 2200 Softswitch software overrides the • Clearing Location in Call Context with LOCATION_ UNKNOWN Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring the Execution Environment 4-43...
  • Page 204 Configuring the Execution Environment Parameter DefaultLocation Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-44 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software Modification This property overrides the Default Location field in Call Context. Change this value if you need to define a customer-specific default location for your system that can differ from the default location set in the type definition of the protocol.

  • Page 205: Configuring Switchover

    • Typically, if Type is socket, set this value to 1051. • If you have two Cisco PGW 2200 Softswitch hosts in a fault tolerant configuration, enter the foverd.ipLocalPortA value in the foverd.ipPeerPortA field in the XECfgParm.dat file on the secondary host.
  • Page 206 Configuring the Execution Environment Parameter foverd.ipLocalPortB foverd.ipPeerPortB foverd.conn3Type foverd.conn3Addr Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-46 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software Modification To define the secondary local port number used for IP...

  • Page 207: Initializing The Provisioning Object Manager

    Note For more information on switchover, see the Cisco PGW 2200 Softswitch Release 9 Operations, Maintenance, and Troubleshooting Guide. Initializing the Provisioning Object Manager To configure the Provisioning Object Manager (POM), modify the following parameters in the POM section of the XECfgParm.dat file:...

  • Page 208: Configuring Scp Queries

    (located in /opt/CiscoMGC/etc) contains the message-sending table that contains translation values. This section contains the following topics: • Before You Start, page 4-49 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-48 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software...

  • Page 209: Before You Start

    Improper editing of the trigger.dat file can cause service interruption and prevent the Caution Cisco PGW 2200 Softswitch from correctly performing SCP database queries. You can configure the following Cisco PGW 2200 Softswitch trigger.dat file attributes to perform a Transaction Capabilities Application Part (TCAP) query: Translation Type •...

  • Page 210: Configuring The Translation Type Attribute

    255. You can get this information from your network administrator. Step 8 Save your changes and close the editor. Step 9 For your changes to take effect you must reboot the Cisco PGW 2200 Softswitch by entering the following command: # /etc/init.d/CiscoMGC start Note If you have installed the Solaris DiskSuite package (CSCOh023) on your system, the messages below are displayed during system boot-up.

  • Page 211: Sample Trigger.dat File

    # All fields are pointers to records of other types # F1 # MA #---------------------------------------------------------- # TT 1: Customer 1 LNP #---------------------------------------------------------- OL-18083-14 Table 4-8 $MessageSending Table Values Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries RR10 4-51...
  • Page 212 # TT 13: Specialized Resource Report for CS1/INAP Based CLI Screening #---------------------------------------------------------- #---------------------------------------------------------- # TT 14: INAP Free Phone Service (Service Key = 0) #---------------------------------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-52 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 213 INAP CS1 Event Report (EventReportBCSM) #---------------------------------------------------------- #---------------------------------------------------------- # TT26 : INAP CS1 DisconnectForwardConnection(re-trigger to restore original trigger) #---------------------------------------------------------- #---------------------------------------------------------- # TT27 : INAP CS1 Final_End(Apply ChargingReport) OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-53...
  • Page 214 # MA 7: INAP Free Phone, LNP & Carrier Pre-Selection Services #------------------------------------------------- #------------------------------------------------- # MA 8: INAP LNP for Norway #------------------------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-54 Chapter 4 ACT3 REQ ACT4 REQ ACT5 REQ...
  • Page 215 # MA 16: INAP CS1 Provoke SCP Abort #------------------------------------------------- ################### $MessageSendingName ################### # Name c1-lnp generic-lnp genesys-800 ansi-ain-800-npa ansi-ain-800-npa-nxx ansi-ain-800-npanxxx ansi-ain-800-ti ansi-pre-ain-800 ansi-pre-ain-800-ti ansi-pre-ain-800-ssn ansi-pre-ain-800-ts cs1-inap-cli-initdp cs1i-nap-cli-srr inap-freephon-initdp inap-lnp-initdp inap-precarr-initdp OL-18083-14 Index Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-55...
  • Page 216 #----------------------------------------------------------------------------------------- ----------------------------------- #----------------------------------------------------------------------------------------- ----------------------------------- # MS 5: ANSI AIN 800 NPA-NXX #----------------------------------------------------------------------------------------- ----------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-56 Chapter 4 asn1Encoding OS10 Configuring the Cisco PGW 2200 Softswitch Software translationType tcapBodyType OS1 OL-18083-14...
  • Page 217 ----------------------------------- # MS 12: CS1/INAP Based CLI Screening InitialDP Query #----------------------------------------------------------------------------------------- ----------------------------------- #----------------------------------------------------------------------------------------- ----------------------------------- # MS 13: CS1/INAP Based CLI Screening SpecializedResourceReport #----------------------------------------------------------------------------------------- ----------------------------------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-57...
  • Page 218 # MS 20: INAP Prepaid Services EventReportBCSM #----------------------------------------------------------------------------------------- ----------------------------------- #----------------------------------------------------------------------------------------- ----------------------------------- # MS 21: INAP Prepaid Services ApplyChargingReport (Time Period Expired) #----------------------------------------------------------------------------------------- ----------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-58 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 219 # MS 28: INAP CS1 (Dummy entry only to permit Message reception operation data access) #----------------------------------------------------------------------------------------- ----------------------------------- #----------------------------------------------------------------------------------------- ----------------------------------- # MS 29: INAP CS2 InitialDP #----------------------------------------------------------------------------------------- ----------------------------------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-59...
  • Page 220 = 1 #----------------------------------------------------------------------------------------- ---- #----------------------------------------------------------------------------------------- ---- # OS 6: ANSI PRE AIN 800 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-60 Chapter 4 opCodeFamily opCodeSpecifier opCodeFlag correlationRequired Configuring the Cisco PGW 2200 Softswitch Software Should have...
  • Page 221 # OS 12: INAP Prepaid Services InitialDP #----------------------------------------------------------------------------------------- ---- #----------------------------------------------------------------------------------------- ---- # OS 13: INAP Prepaid Services ApplyChargingReport #----------------------------------------------------------------------------------------- ---- #----------------------------------------------------------------------------------------- ---- # OS 14: INAP Prepaid Services EventReportBCSM OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-61...
  • Page 222 ################# # F1 # PA1 PA10 REQ PA11 REQ #----------------------------------------------------------------------------------------- ------------------------------------------------------------ Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-62 Chapter 4 opCodeFamily opCodeSpecifier opCodeFlag correlationRequired PA12 REQ PA13 REQ PA14 REQ Configuring the Cisco PGW 2200 Softswitch Software...
  • Page 223 # PS 7: ANSI PRE AIN 800 Termination Information #----------------------------------------------------------------------------------------- ------------------------------------------------------------ #----------------------------------------------------------------------------------------- ------------------------------------------------------------ # PS 8: CS1/INAP Based CLI Screening #----------------------------------------------------------------------------------------- ------------------------------------------------------------ #----------------------------------------------------------------------------------------- ------------------------------------------------------------ OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-63...
  • Page 224 # PS 15: INAP CS1 InitialDP #----------------------------------------------------------------------------------------- ------------------------------------------------------------ #----------------------------------------------------------------------------------------- ------------------------------------------------------------ # PS 16: INAP CS1 EventReportBCSM #----------------------------------------------------------------------------------------- ------------------------------------------------------------ #----------------------------------------------------------------------------------------- ------------------------------------------------------------ Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-64 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 225 # RR 5: Genesys 800 2st expected (Error) #----------------------------------------------------------------------------------------- ---------- #----------------------------------------------------------------------------------------- ---------- # RR 6: ANSI AIN 800 With termination status notification #----------------------------------------------------------------------------------------- ---------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-65...
  • Page 226 PlayAnnouncement #----------------------------------------------------------------------------------------- ---------- #----------------------------------------------------------------------------------------- ---------- # RR 15: CS1/INAP Based CLI Screening, Expected Response 3, Conintue: ConnectToResource, PlayAnnouncement Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-66 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 227 # RR 22: INAP Prepaid Services, Expected Response (Continue, ReleaseCall) #----------------------------------------------------------------------------------------- ---------- #----------------------------------------------------------------------------------------- ---------- # RR 23: INAP Prepaid Services, Expected Response (Continue, Connect) #----------------------------------------------------------------------------------------- ---------- #----------------------------------------------------------------------------------------- ---------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-67...
  • Page 228 RequestReportBCSMEvent) #----------------------------------------------------------------------------------------- ---------- #----------------------------------------------------------------------------------------- ---------- # RR 32: INAP CS1, Expected Response (Continue, ReleaseCall) #----------------------------------------------------------------------------------------- ---------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-68 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software (Continue, Connect) OL-18083-14...
  • Page 229 # RR 40: ANSI PRE AIN CNAM Response expected, Take the same action as AIN #----------------------------------------------------------------------------------------- #----------------------------------------------------------------------------------------- # RR 41: ANSI PRE AIN CNAM Response unexpected #----------------------------------------------------------------------------------------- ################# $MessageReceiving ################# OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-69...
  • Page 230 # MR 6: ANSI PRE AIN 800 with termination status notification #----------------------------------------------------------------------------------------- ------------- #----------------------------------------------------------------------------------------- ------------- # MR 7: ANSI PRE AIN 800 #----------------------------------------------------------------------------------------- ------------- #----------------------------------------------------------------------------------------- ------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-70 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 231 # MR 14: INAP Prepaid Services, Expected Response (Continue, ApplyCharging) #----------------------------------------------------------------------------------------- ------------- #----------------------------------------------------------------------------------------- ------------- # MR 15: INAP Prepaid Services, Expected Response (Continue, ReleaseCall) #----------------------------------------------------------------------------------------- ------------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-71...
  • Page 232 ------------- #----------------------------------------------------------------------------------------- ------------- # MR 23: INAP CS1 , Expected Response (Continue, ReleaseCall or Continue and optional RequestReportBCSMEvent) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-72 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 233 # MR 29: INAP CS2 , Expected Response (CWA,RRBE,CON,CTR,PA) #----------------------------------------------------------------------------------------- ------------- #----------------------------------------------------------------------------------------- ------------- # MR 30: ANSI PRE AIN CNAM , msg=response #----------------------------------------------------------------------------------------- ------------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-73...
  • Page 234 # OR 11: INAP Free Phone, LNP & Carrier Pre-Selection Services Connect Operation #---------------------------------------------------------------------- #---------------------------------------------------------------------- # OR 12: INAP LNP for Norway, Expected Response (Connect) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-74 Chapter 4 opCodeFamily opCodeSpecifier opCodeFlag PR...
  • Page 235 # OR 23: INAP CS1 , Expected Response (RequestReportBCSMEvent) #---------------------------------------------------------------------- #---------------------------------------------------------------------- # OR 24: INAP CS1, Expected Response (FurnishCharging) #---------------------------------------------------------------------- OL-18083-14 opCodeFamily opCodeSpecifier opCodeFlag PR Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-75...
  • Page 236 #---------------------------------------------------------------------- # componentType opClass #---------------------------------------------------------------------- # OR 36: INAP CS2, Expected Response (PlayAnnouncement operation) #---------------------------------------------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-76 Chapter 4 opCodeFamily opCodeSpecifier opCodeFlag PR opCodeFamily opCodeSpecifier opCodeFlag PR opCodeFamily opCodeSpecifier opCodeFlag PR...
  • Page 237 ------------------------------------------------------------------------------------------ --------------------------------------------- OL-18083-14 opCodeFamily opCodeSpecifier opCodeFlag PR opCodeFamily opCodeSpecifier opCodeFlag PR opCodeFamily opCodeSpecifier opCodeFlag PR PA10 REQ PA14 REQ PA15 REQ Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries PA11 REQ PA12 REQ 4-77...
  • Page 238 # PR 8: CS1/INAP Based CLI Screening Connect Prameters #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- # PR 9: CS1/INAP Based CLI Screening PlayAnnouncement Prameters Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-78 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 239 # PR 13: INAP Prepaid Services ApplyCharging Parameters #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- # PR 14: INAP Prepaid Services RequestReportBCSMEvent Parameters #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-79...
  • Page 240 # PR 19: INAP CS1 Connect Parameters #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- # PR 20: INAP CS1 ApplyCharging Parameters #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-80 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 241 --------------------------------------------- # PR 25: INAP CS1 RequestReportBCSMEvent Parameters #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- # PR 26: INAP CS1 Etc(Establish temporary connection) , OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries Parameter 4-81...
  • Page 242 # PR 30: INAP CS2 MoveLeg Parameters(CallSegmentId, LegId) #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- # PR 31: INAP CS2 SplitLeg Parameters(CallSegmentId ,LegId) #----------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------ --------------------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-82 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 243 # RA 1: Customer 1 LNP Default & Generic LNP Default #-------------------------------------------------------------------------- #-------------------------------------------------------------------------- # RA 2: Customer 1 LNP 1st Expected OL-18083-14 ACT2 REQ ACT3 REQ Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries ACT4 REQ ACT5 REQ 4-83...
  • Page 244 #-------------------------------------------------------------------------- #-------------------------------------------------------------------------- # RA 14: INAP Free Phone, LNP & Carrier Pre-Selection Services, Connect reponse actions #-------------------------------------------------------------------------- #-------------------------------------------------------------------------- Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-84 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software OL-18083-14...
  • Page 245 # RA 26: INAP CS1, Expected Response (In Release) #-------------------------------------------------------------------------- #-------------------------------------------------------------------------- # RA 27: INAP CS1, Expected Response (No action - ignoring call gap response ) #-------------------------------------------------------------------------- OL-18083-14 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-85...
  • Page 246 #-------------------------- # AD 6: CS1/INAP Based CLI Screeing Data for RESULT_ACTION_SEND_ACTION_TO_LCM information # Act Null Null Null Null Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-86 Chapter 4 Data for RESULT_ACTION_RE_TRIGGER_VIA_LCM (to send termination NULL NULL...
  • Page 247 # AD 16: INAP Prepaid Services Data for RESULT_ACTION_SEND_ACTION_TO_LCM information (IN_PREPAID) # Act Null Null Null Null #-------------------------- # AD 17: INAP LNP for Portugal Data for RESULT_ACTION_SEND_ACTION_TO_LCM information (IN_NONE) OL-18083-14 Null Null Null Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Configuring SCP Queries 4-87...

  • Page 248: Initializing The Call Screening Database

    Incorrect use of these commands can cause database corruption. During installation, the installation script (install.sh) installs and initializes the Main Memory Database (MMDB) that the Cisco PGW 2200 Softswitch can use for the following: Store call-screening information for calling- and called-number analysis •...

  • Page 249: Odbc.ini File Information

    Installdir=/opt/TimesTen4.1/32 Setting Up Replication If you have two Cisco PGW 2200 Softswitch hosts in a fault tolerant system, you must set up database replication between the two hosts. During replication, any updates applied to the database on one host are replicated on the other. Data is transferred real time and does not require committing or deploying a configuration.

  • Page 250: Network Requirements

    IP address as the hostname in the CREATE REPLICATION statement used to configure your replication scheme.) The following are example hosts files from an active Cisco PGW 2200 Softswitch host and an associated peer Cisco PGW 2200 Softswitch host: Active Cisco PGW 2200 Softswitch Host /etc/hosts 27.0.0.1 localhost...

  • Page 251: Initializing Database Replication

    Logging Enabled Replication Manually Started Step 2 Log in to the standby host as the root user and stop the Cisco PGW 2200 Softswitch software by entering the following UNIX command: # /etc/init.d/CiscoMGC stop Log back in to the standby host as mgcusr.

  • Page 252: Verifying Database Replication

    Then change the value of the TTREPPORT variable from 2890 to 2891 in the setup_replication.sh script on both active and standby hosts and save your changes. Perform the whole procedure again. Step 5 Start the both active and standby Cisco PGW 2200 Softswitch as root: # /etc/init.d/CiscoMGC start Proceed to “Verifying Database...

  • Page 253: Troubleshooting The Main Memory Database Replication

    Run the script by typing the following command: % ./replication_status.sh The output shows the following replication status: Peer name ---------------- OL-18083-14 Host name Port ------------------------ ------ Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Initializing the Call Screening Database State Proto ------- ----- 4-93...

  • Page 254: Verifying Database Synchronization

    Assuming the active host is the "better" database, do the following on the standby host: Step 1 Log in as root. Stop the Cisco PGW 2200 Softswitch software by entering the following command: Step 2 # /etc/init.d/CiscoMGC stop Stop MMDB replication by entering the following command: Step 3 # /etc/init.d/ttreplic stop...

  • Page 255: Checking For Installation Errors

    Reinstalling CSCOga002 If you experience database errors such as an incorrect timestamp after completing the Installation Errors” section on page the Cisco PGW 2200 Softswitch database components. Follow these steps to reinstall the CSCOga002 package: Step 1 Remove the CSCOga002 package as root using the pkgrm command. To remove the package file, enter...

  • Page 256: Configuring Disk Monitor During Initial Software Configuration

    The setting of the disk monitor parameters in the XECfgParm.dat file typically occurs while you are performing the initial configuration procedures for your Cisco PGW 2200 Softswitch software. To configure the disk monitor settings in the XECfgParm.dat file during initial software configuration, perform the following steps: While configuring your settings in the XECfgParm.dat file, find the disk monitor parameters in the file...

  • Page 257: Configuring The Data Dumper

    Configuring the Data Dumper The data dumper is a Cisco PGW 2200 Softswitch software function that controls the destinations for active and archived log files for CDRs, measurements, and alarms, and controls when the active files are archived.

  • Page 258: Configuring The Data Dumper To Support Cisco Bams

    Configuring the Data Dumper to Support Cisco BAMS If your system will use Cisco BAMS to retrieve CDRs from the Cisco PGW 2200 Softswitch, perform the following procedure to configure the data dumper to support Cisco BAMS: Step 1 Log into a Cisco PGW 2200 Softswitch as root if you are not already logged in.
  • Page 259 Step 10 on this second Cisco PGW 2200 Softswitch if your system is equipped “Obtaining Documentation and Submitting a Service Request” section on Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 260 Chapter 4 Configuring the Cisco PGW 2200 Softswitch Software Configuring the Data Dumper to Support Cisco BAMS Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 4-100 OL-18083-14...

  • Page 261: Migrating To Solaris 10 And Cisco Pgw 2200 Softswitch Software Release

    Release 9.8 Revised: February 21, 2012, OL-18083-14 Introduction This chapter describes how to migrate your Cisco PGW 2200 Softswitch to the Solaris 10 operating system and Cisco PGW 2200 Softswitch software Release 9.8. This chapter contains the following information: Conditions for Migration, page 5-1 •...

  • Page 262: Cautions And Notes

    Your system must have at least two disks. Note If you plan to replace the Cisco PGW 2200 Softswitch hard disks during the upgrade, ensure that you have two replacement disks. The disks in the system must be at least 18 GB in size.

  • Page 263: Required Software

    Please keep the rollback procedure at hand when you are going to upgrade your system. Caution The Cisco PGW 2200 Softswitch supports a live upgrade from the Sparc-based platforms to the Note Opteron-based platforms. There is no service outrage during the upgrade. For detailed procedure of this...

  • Page 264: License Installation

    During the migration procedure, you must set each host to both active and standby. For clarity, the Cisco PGW 2200 Softswitches are labeled PGW 1 and PGW 2. PGW host 1 is the host that is active at the beginning of the procedure, and PGW host 2 is the host that is set to standby at the beginning of the procedure.

  • Page 265: Migration From Release 9.5 Or 9.6 To Release 9.8 Without Platform Changes

    Prior to Release 9.7(3), only Sparc-based platforms are supported. In order to migrate to Release 9.8(1), you need find out the old Cisco PGW 2200 Softswitch software version, the old Sun platform, and the target Sun platform you are going to use.

  • Page 266: Backing Up The Cisco Pgw 2200 Softswitch Configuration Files

    Migration from Release 9.5 or 9.6 to Release 9.8 without Platform Changes Note If you want to use two new disk drives to install the Cisco PGW 2200 Softswitch software, complete the “Installing Sun Solaris before you begin this procedure.
  • Page 267 The backup file is stored in the specified directory path in the following format: mgc_<hostname>_<yyyymmdd>_<hhmmss>_backup Where: • hostname is the name of the Cisco PGW 2200 Softswitch host, such as MGC-01. • yyyymmdd is the date the backup file is created, in a year-month-day format, such as 20011130.

  • Page 268: Installing Sun Solaris 10

    Verify that the files are successfully transferred to the remote file server before continuing. Step 13 At this point, the Cisco PGW 2200 Softswitch configuration data has been saved in MGC.tar files on a tape or remote file server. The file backup is now complete. Proceed to Installing Sun Solaris 10 Follow these steps to install Sun Solaris 10 on PGW host 2.

  • Page 269: Loading The Sun Solaris 10 Operating Environment Packages

    Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8 Note If you want to use two new disk drives to install the Cisco PGW 2200 Softswitch software Release 9.8, you can use the original disk drives to revert to the previous Cisco PGW 2200 Softswitch software version if there is a problem during the upgrade procedure.

  • Page 270: Restoring Data Files

    Follow these instructions to restore the Cisco PGW 2200 Softswitch configuration files (MGC.tar) on PGW host 2: Step 1 Log in as root and move the Cisco PGW 2200 Softswitch configuration files to the /tmp directory. # cd /var/tmp Create a mount point.

  • Page 271: Migrating The First Cisco Pgw 2200 Softswitch Software To Release 9.8

    Use the steps in the following sections to upgrade PGW 1 to Cisco PGW 2200 Softswitch Release 9.8. Note If you want to use two new disks drives to install the Cisco PGW 2200 Softswitch software Release 9.8, complete the Packages”...

  • Page 272: Backing Up The Cisco Pgw 2200 Softswitch Configuration Files

    • Follow these steps to back up the configuration files on PGW host 1: Verify that the pom.dataSync variable is set to False on both Cisco PGW 2200 Softswitch hosts. To edit Step 1 the pom.datasync variable, use an editor such as vi to edit /opt/CiscoMGC/etc/XECfgParm.dat.
  • Page 273 Chapter 5 Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8 Step 5 Stop TimesTen database replication on PGW hosts 1 and 2: % ./delete_replication.sh Step 6 Follow these steps to back up the MMDB on the PGW host 1: Log in to the PGW host 1 as mgcusr.

  • Page 274: Installing Sun Solaris 10

    Follow these steps to install Sun Solaris 10 on PGW host 1: Note If you want to use two new hard disks to install the Cisco PGW 2200 Softswitch software Release 9.8, you can use the original hard disks to revert to the previous Cisco PGW 2200 Softswitch software version if there is a problem during the upgrade procedure.

  • Page 275: Loading The Sun Solaris 10 Operating Environment Packages

    Follow these instructions to restore the Cisco PGW 2200 Softswitch configuration files (MGC.tar) on PGW host 1: Step 1 Log in as root and move the Cisco PGW 2200 Softswitch configuration files to the /tmp directory. # cd /var/tmp Create a mount point.

  • Page 276: Installing And Verifying The Cisco Pgw 2200 Softswitch Software

    Step 5 Wait for PGW host 1 to come up fully as standby host. When the Cisco PGW 2200 Softswitch software starts, it updates the following files to function with the Step 6 Cisco PGW 2200 Softswitch software Release 9.8: •...

  • Page 277: Transferring Additional Configuration Files

    If you need to transfer additional configuration files, follow these steps, using the config-lib tool: Step 1 Set the pom.dataSync variable to False on both Cisco PGW 2200 Softswitch hosts. To view or modify the pom.dataSync variable, use an editor such as vi to edit /opt/CiscoMGC/etc/XECfgParm.dat.
  • Page 278 Quit Perform the following steps on PGW host 2 when the file transfer is complete: Step 4 Enter the following command to start the Cisco PGW 2200 Softswitch software: # /etc/init.d/CiscoMGC start Verify that all protocols are operational: mml> rtrv-ne mml>...
  • Page 279 Complete the following steps to migrate the files to PGW host 1: Step 7 Log in to PGW host 1 as root. Enter the following command to stop the Cisco PGW 2200 Softswitch software on PGW host 1: # /etc/init.d/CiscoMGC stop Enter the following command on PGW host 1: # config-lib At the configuration file library main menu, type 3.
  • Page 280 XECfgParm.dat in the /opt/CiscoMGC/etc/ directory. Log in to PGW host 1 as root. Enter the following command to start the Cisco PGW 2200 Softswitch software on PGW host 1: # /etc/init.d/CiscoMGC start Wait for PGW host 1 to come up fully as standby host.

  • Page 281: Migration From Release 9.7 To Release 9.8 Without Platform Changes

    9.7 and release 9.8. Note As you migrate from Cisco PGW 2200 Softswitch Release 9.7(3) to Release 9.8(1), before you start the Release 9.8(1) system software, first install the base Release of 9.8(1), and then install Release 9.8(1) patch S7P7 or later.

  • Page 282: Upgrading Lively From Sparc-Based Platforms To Opteron-Based Platforms

    To download the mgcTTmigrate script, follow the procedure in the section, of the Release Notes for the Cisco PGW 2200 Softswitch Release 9.8(1). You can find the mgcTTmigrate.981 script in system patches for 9.8(1) Sparc platforms. This script works for Release 9.8(1) software on both Sparc and Opteron platforms.

  • Page 283: Live Upgrade Procedure

    Cisco PGW 2200 Softswitches. Provisioning is allowed only when the new pair of Cisco PGW 2200 Softswitches on Opteron-based platforms are running normally as an active and standby pair. To view the status of the Cisco PGW 2200 Softswitch, use the MML command “rtrv-ne”. Live Upgrade Procedure This section describes the live upgrade procedure from Sparc-based platforms to Opteron-based platforms.
  • Page 284 Back up the odbc.ini file using the following command: Step 3 # cp /opt/CiscoMGC/local/.odbc.ini /var/tmp/upgrade/ Step 3 is only required when PGW 2’s software version is Cisco PGW 2200 Softswitch Note Release 9.7. Step 4 Use ftp utility to transfer MGC.tar, ttbackup.tar, and .odbc.ini which are generated in Step 2 and Step 3...
  • Page 285 /opt/CiscoMGC/etc/*.ttdb Finished import configuration files. Please go ahead to install PGW software Install the Cisco PGW 2200 Softswitch software Release 9.8(1) on PGW 4 using the steps in Step 16 “Installing the Cisco PGW 2200 Softswitch Software Release 9.8 and Higher.”...
  • Page 286 Step 25 For example, the IP address on PGW 4 should be the same with PGW 2. Step 26 Log in PGW 4 as root and start the Cisco PGW 2200 Softswitch software using the following command: # /etc/init.d/CiscoMGC start Note Before you start the Cisco PGW 2200 Softswitch software, make sure that you have installed the license file in the /opt/CiscoMGC/license directory.

  • Page 287: Falling Back Overview

    Sun platform you are using, the previous Cisco PGW 2200 Softswitch software version to fall back to, and the target Sun platform to fall back to. See the Cisco PGW 2200 Softswitch Hardware Installation Guide (Release 7 & 9) to find out supported Sun platforms for Cisco PGW 2200 Softswitch software Release 9.5(2), 9.6(1), and 9.7(3).

  • Page 288: Falling Back To The Cisco Pgw 2200 Softswitch Software Release 9.7 Without Platform Changes

    Changes, page 5-34 Falling Back to the Cisco PGW 2200 Softswitch Software Release 9.7 without Platform Changes Perform the following procedure to fall back to the Cisco PGW 2200 Softswitch software Release 9.7(3) without platform changes. Step 1 Log in the Cisco PGW 2200 Softswitch as root.

  • Page 289: Falling Back To Solaris 8 And Cisco Pgw 2200 Softswitch Release 9.5 Or

    From the ok prompt, boot the secondary boot disk. Step 2 ok boot disk1 Log in as mgcusr and verify that the system boots Solaris 8 and the Cisco PGW 2200 Softswitch Step 3 software starts properly. Enter the following command to verify the operating system version.
  • Page 290 Falling Back to Solaris 8 and Cisco PGW 2200 Softswitch Release 9.5 or 9.6 Note “5.8” indicates that the system is running the Solaris 8 operating system. Start the MML command interface and use the following command to see if the software starts properly.
  • Page 291 # init 0 ok boot disk1 Log in as root and run vxdiskadm. Step 13 OL-18083-14 Falling Back to Solaris 8 and Cisco PGW 2200 Softswitch Release 9.5 or 9.6 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 5-31...
  • Page 292 Falling Back to Solaris 8 and Cisco PGW 2200 Softswitch Release 9.5 or 9.6 # vxdiskadm Step 14 Enter 5 to replace a failed disk. Replace a failed or removed disk Menu: VolumeManager/Disk/ReplaceDisk Use this menu operation to specify a replacement disk for a disk that you removed with the "Remove a disk for replacement"...

  • Page 293: Restoring The Original Cisco Pgw 2200 Softswitch Software

    Cisco PGW 2200 Softswitch software configuration: OL-18083-14 Falling Back to Solaris 8 and Cisco PGW 2200 Softswitch Release 9.5 or 9.6 to verify that the correct software is running. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...

  • Page 294: Falling Back To Previous Cisco Pgw 2200 Softswitch Software Releases With Platform Changes

    Step 1 Verify that the pom.dataSync variable is set to False on the active and standby pair of Cisco PGW 2200 Softswitches. To view or modify the pom.dataSync variable, use an editor such as vi to edit /opt/CiscoMGC/etc/XECfgParm.dat. You must set pom.dataSync to false on the active and standby pair of Note Cisco PGW 2200 Softswitches before you perform the fallback.

  • Page 295: Replacing Hard Disks On An Existing Solaris 10 Platform

    Step 10 Repeat Step 2 to Step 9 to fall back the new version Cisco PGW 2200 Softswitch to the old version platform. Verify that the pom.dataSync variable is set to True on the active and standby pair of old version Step 11 Cisco PGW 2200 Softswitches.

  • Page 296: Hard Disk Replacement Procedure

    You must now move the backup file to a remote file server using the ftp program so that you can recover it if you need to return the Cisco PGW 2200 Softswitch to the previous version of Solaris or Cisco PGW 2200 Softswitch software. You are responsible for providing the mechanism and storage location.

  • Page 297: Loading The Sun Solaris 10 Operating Environment Packages

    Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8 Loading the Sun Solaris 10 Operating Environment Packages Before you install the Cisco PGW 2200 Softswitch software, you need to load the Sun Solaris 10 Operating Environment packages. To load the environment packages, complete the steps in the section...
  • Page 298 Chapter 5 Migrating to Solaris 10 and Cisco PGW 2200 Softswitch Software Release 9.8 Replacing Hard Disks on an Existing Solaris 10 Platform Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 5-38 OL-18083-14...

  • Page 299: Configuring The Local Area Network Switch

    This chapter provides a brief overview of the local area network (LAN) switches (Cisco Catalyst Switch family) in your solution. The LAN switch connects the Cisco PGW 2200 Softswitch hosts to the media gateways (MGWs) or to the Cisco IP Transfer Point LinkExtender (ITP-L). A LAN switch is not provided with the Cisco PGW 2200 Softswitch..

  • Page 300: C H A P T E R 6 Configuring The Local Area Network Switch

    For information on the image that your switch supports, see the documentation that came with your switch. If you have questions or need assistance, see the Request” section on page x Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration of a Duplex LAN Switch 5500 5500 “Obtaining Documentation and Submitting a Service...

  • Page 301: Appendix

    Revised: February 21, 2012, OL-18083-14 Introduction This appendix describes the parameters found in the XECfgParm.dat file for the Cisco PGW 2200 Softswitch software Release 9.x and how they are used by the media gateway controller (MGC). Understanding the XECfgParm.dat File Format The XECfgParm.dat file contains system-wide as well as system tuning parameters.

  • Page 302: Special Parameters

    • XE—Execution environment Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Parameter Definitions The XECfgParm.dat file configuration parameters for the Cisco PGW 2200 Softswitch software release 9.x are presented alphabetically in Caution This list of parameters is provided as a reference. Do not edit any parameters unless they are listed in the following table or unless you have been instructed to do so by Cisco technical support;...
  • Page 303 Valid values: 1, 0 where 0=existing analysis behavior 1=longest match capability enabled Property domain: XE Parameter Dynamically reconfigurable: No Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format...
  • Page 304 Configuration Parameter *.autonomous *.chargingmode *.chargingtarifftype *.chkPtPort Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Enables a process, for example the engine, to be started without the system.
  • Page 305 Note During the startup of the Cisco PGW 2200 Softswitch software, this parameter will be set automatically to tune the system for optimal performance. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format...
  • Page 306 *.dataSourceName *.DaylightSavingsTime added in Release 9.8(1) S9P9 *.debugLevel Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Controls INAP (Intelligent Network Application Protocol) behavior, including advertised application context.
  • Page 307 (active and standby) Cisco PGW 2200 Softswitch hosts. Enter standalone if you have a single-host system. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format...
  • Page 308 *.DisableCCBSoverTunneledQSIG *.disableMeas *.disablemultiplecdrs *.eventTrace *.FastConnect Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Specifies the protocol used to deliver Call Back Services messages over the network. Valid Values: •...
  • Page 309 CODEC. The valid upspeed CODECs are G711alaw and G711ulaw. Valid value: null (default) - the PGW 2200 does not upspeed the CODEC if the T.38 fails, G711alaw - up-speeds to G.711A-law if T.38 fails, G711ulaw - up-speeds to G.711 U-law if T.38 fails,...
  • Page 310 Understanding the XECfgParm.dat File Format Table A-1 Configuration Parameter *.GWClearChannelAlgorithm Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-10 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Specify a clear channel codec or multiple clear channel codecs that you want gateways to use for data calls in the GWClearChannelAlgorithm parameter.
  • Page 311 If you have two Cisco PGW 2200 Softswitch hosts in an active/standby configuration, this value is the IP address of the second host. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-11...
  • Page 312 *.IP_NextHop8 *.IUA.maxNasExtNodes *.IUA.maxNasPathsPerExtNode *.IUA.maxNasPaths *.LISupport *.logDirectory Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-12 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Second corresponding peer IP address; used for checkpointing and failover heartbeats. If your configuration does not use an external card, Note leave this setting as the default value, 0.0.0.0.
  • Page 313 • Default: true Caution Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format If you set this parameter to false for the engine and the engine logging level is Debug, the system can fail at high call rates.
  • Page 314 Understanding the XECfgParm.dat File Format Table A-1 Configuration Parameter *.logPrio Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-14 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Defines the initial default logging level used by logging clients when sending messages to the logging server.
  • Page 315 This is based on the maximum number of SS7 links in a Cisco ITP-L. Value: 4 Default: 4 Note Do not change this value. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-15...
  • Page 316 *.maxLocationLabels (Added in Release 9.6(1) *.maxNumDChansPerPort *.maxnumRLMports *.MgcpBehavior Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-16 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Specifies the maximum number of location labels that can be provisioned.
  • Page 317 Valid values: 7-characters string. The first character must be either + or -. The next 6 characters should be numbers. Note This parameter is used only for Radius with Lawful Intercept. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-17...
  • Page 318 *.PartialCliPnoIdentity *.PartialCliSwitchNumber *.PartialCliTypeOfSwitch *.platformId *.popDataSync Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-18 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition This parameter controls the method of loading dial plan tables and instructs the system whether to expect overdecadic (base 16) or regular decadic (base 10) digits in dial plans, routing, and other digit streams.
  • Page 319 CUSTGRPID of the Terminating Leg SigPath. If this parameter is set to False, you should always select CUSTGRPID of the Originating Leg SigPath. Default: False Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-19...
  • Page 320 *.shortdurationcallperiod *.sipFailover *.sipRoutingMode *.sm_meas_baseaddr *.stPort Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-20 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Allows you to specify the period used to determine a short duration call. Calls with a duration less than the specified value are recorded as a short duration call in the CDR.
  • Page 321 If you have two Cisco PGW 2200 Softswitch hosts Note in a failover configuration, enter true. If you have a standalone configuration, enter false. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-21...
  • Page 322 *.tablesFile *.tempDir *.tibcoSupport *.transpathId *.Virtual_IP_Addr1 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-22 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Controls whether data access is enabled or disabled (if the engine attempts to connect to the MMDB or to call screening database at startup).
  • Page 323 • • 1 (minute) • 2 (seconds) Storage location of the configuration manager recovery information. Default: ../var/cfgMRecovery Note Do not change this value. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-23...
  • Page 324 Table A-1 Configuration Parameter diskmonitor.CdrRmFinished diskmonitor.CfgRmDirs diskmonitor.CoreRmDays Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-24 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Specifies the number of days to keep finished CDR files. The default value is 0, which means that if the Cisco BAMS is polling the Cisco PGW 2200 Softswitch, CDR.bin files...
  • Page 325 CDR files when disk usage surpasses the precentage of use set by the diskmonitor.Threshold parameter. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-25...
  • Page 326 Understanding the XECfgParm.dat File Format Table A-1 Configuration Parameter diskmonitor.PreserveLogs diskmonitor.SoftLimit Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-26 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Specifies, along with diskmonitor.SoftLimit, whether platform log data should be preserved or deleted once the disk usage percentage set in diskmonitor.Threshold is...
  • Page 327 Value: Any positive integer. Default: 500 This is a platform-specific value and depends on Note your system installation. No auditing is available for nailed trunks. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-27...
  • Page 328 (added in Release 9.6(1) engine.CALL_MEM_BLOCK_SIZE engine.CALL_MEM_CHUNK_SIZE engine.CDRencodingFormat Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-28 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Allows enabling or disabling the call limiting capability on the Cisco PGW 2200 Softswitch.
  • Page 329 False—The Cisco PGW 2200 Softswitch does not create a new Call-ID header field for the terminating side in the B2BUA mode. Default: False. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-29...
  • Page 330 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-30 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Enables or disables the circuit reservation feature. Values: True, False Default: False Location of call processing libraries.
  • Page 331 Enables or disables Calling Line Identity (CLI) validation processing on calls. Values: • true— Enables CLI validation • false—Disables CLI validation Default: false Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-31...
  • Page 332 Table A-1 Configuration Parameter engine.SysGeneratedCode engine.SysGSMTimerInterval engine.SysGRSBlockSize engine.SysMaxOverlap Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-32 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Determines whether compiled or interpreted code is used. Values: •...
  • Page 333 Do not change this value. Note Maximum number of simple gateway control protocol (SGCP) retry messages after a failure. Default: 3 Note Do not change this value. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-33...
  • Page 334 Table A-1 Configuration Parameter engine.SysSGCPREtryTimerInterval engine.SysTraceLevel engine.SysVirtualSwitch engine.VersionTimeoutValue Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-34 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition The interval between SGCP message transmissions, in milliseconds. Default: 1000 Note Do not change this value.
  • Page 335 Typically, set this value to socket. Sets the connection type for connection number 2. Values: Serial • Socket • Typically, set this value to socket. Note Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-35...
  • Page 336 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-36 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Specifies the address of the peer system. Example: /dev/term/b If your configuration does not use connection number 3, enter /dev/null (default).
  • Page 337 If a timeout occurs, the system is restarted. Default: 10000 milliseconds (10 seconds). Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-37...
  • Page 338 H248.localMID H248.maximumActionsInTransaction H248.maxNumH248Links H248.MgcHeaderAddrType ioChanCtl.DPNSSTestFrames ioChanMgr.alarmTimer Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-38 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition For network continuity test on VISM. Valid values: 1—Network continuity is present/requested.
  • Page 339 Maximum number of events sent from the queue at one time. Default: 10 Note Do not change this value. Amount of time the Cisco PGW 2200 Softswitch waits for a BSM session set to recover from failure before declaring the session set failure. Values: 1–10 seconds.
  • Page 340 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-40 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Creates unit test tracing of line and channel state machines. Generates a considerable amount of information to the log.
  • Page 341 Do not change this value. Note Timeout value for the vld-cic MML command in milliseconds; overrides MML.timeout. Default: 25000 milliseconds Note Do not change this value. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-41...
  • Page 342 Table A-1 Configuration Parameter pom.dataSync pom.port procM.almDwellInterval Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-42 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Indicates that the Provisioning Object Manager (POM) should synchronize the provisioning data at startup.
  • Page 343 Do not change this value. Software release version number. Note Do not change this value. Enables the RADIUS server feature. Values: On or Off. Default: Off Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-43...
  • Page 344 RadiusAccounting.numberPort RadiusAccounting.smSize replicator.portCommChannelRecv replicator.portCommChannelSend replicator.portDataChannelRecv Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-44 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition The number of local port to communicate with RADIUS server. One port is used for 256 records.
  • Page 345 Defines the length of time (in seconds) that a TCP connection can remain idle before the Cisco PGW 2200 Softswitch closes the connection. A value of 0 means that the Cisco PGW 2200 Softswitch does not close idle TCP connections. Value: Integer...
  • Page 346 (Added in Release 9.8(1)) SIP.MaxConnection SIP.naptr_record_locate (Added in Release 9.8(1)) Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-46 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition The amount of time in seconds before a Cisco PGW 2200 Softswitch DNS NAPTR query times out.
  • Page 347 DNS SRV queries for all SIP messages. This setting provides RFC 3263 compatibility. Default: 0 Defines the transport protocol used to complete calls. The Cisco PGW 2200 Softswitch can only set up new calls using one protocol at a time. Values: •...
  • Page 348 Understanding the XECfgParm.dat File Format Table A-1 Configuration Parameter SIP.udp2tcp_byte_xover sipModeSelectionControl Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-48 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Determines the SIP message size (in bytes) above which the Cisco PGW 2200 Softswitch switches to TCP transport.
  • Page 349 Invoke. The number of Invokes depends on the call flow for the TCAP dialog. Values: 1-10 Default: 1 See the note for the TCAP.maxSsnNum parameter. Note Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Understanding the XECfgParm.dat File Format A-49...
  • Page 350 Understanding the XECfgParm.dat File Format Table A-1 Configuration Parameter TCAP.maxSsnNum XE.CallNumberToWriteIntoTracefile Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide A-50 Cisco PGW 2200 Softswitch 9.x XECfgParm.dat File Configuration Parameters Definition Defines the maximum number of local subsystem numbers allowed by the PGW for the entire TCAP IOCC subsystem.

  • Page 351: Appendix

    Cisco PGW 2200 Softswitch platform is considered to be a server system to Cisco BAMS. The Cisco BAMS platform is a client of the Cisco PGW 2200 Softswitch platform. This means that in the current, non-secure interface environment, to transfer files from the Cisco PGW 2200 Softswitch to Cisco BAMS, the Cisco BAMS system invokes the FTP program which talks to an FTP daemon process on the Cisco PGW 2200 Softswitch platform.

  • Page 352: Secure Connectivity Among Cisco Pgw 2200 Softswitch Applications

    Figure B-1 illustrates the client/server relationship and the secure connectivity used among the different application types of the Cisco PGW 2200 Softswitch and its network management elements. Note that Cisco VSPT has SSH and SFTP interfaces to Cisco HSI. Note For simplicity, redundant platforms are not shown in this figure.

  • Page 353: A P P E N D I X B Client/Server And Secure Connectivity Relationships

    Cisco BAMS pair controls multiple Cisco PGW 2200 Softswitch application platforms. Note For simplicity, the redundant Cisco PGW 2200 Softswitch application platforms are not shown. The secure connectivity between the redundant Cisco BAMS pair and the redundant Cisco PGW 2200 Softswitch application platforms is the same.
  • Page 354 Appendix B Client/Server and Secure Connectivity Relationships Client/Server and Secure Connectivity Relationships Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...

  • Page 355: Appendix

    Open the MIB browser and select the Tools menu, then choose SNMP MIB Browser. Step 2 Under Name or IP Address, enter the name or IP address of the Cisco PGW 2200 Softswitch you are Step 3 configuring. Step 4 Under Community Name, enter public.
  • Page 356 HP OpenView must be entered. This SNMP field is a generic six-byte field designed to accommodate IP and non-IP SNMP implementations. Since the Cisco PGW 2200 Softswitch supports only SNMP over IP, this field always contains the IP address of the network management system. The IP address, however, must be converted into a six-byte hexadecimal value.

  • Page 357: Formatting Trap Messages

    The trap is sent with basic information indicating the alarm category, description, and severity. Because many failures require extra detail for troubleshooting, you should refer to the log file on the Cisco PGW 2200 Softswitch for complete alarm information and for determining root causes.
  • Page 358 Step 9 Verify that alarms are being received and formatted correctly by generating an alarm on the Cisco PGW 2200 Softswitch (for instance, take a signaling channel out of service to see if you get an alarm). Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Alarm category description Alarm set/not set.

  • Page 359: Introduction

    • Updated Configuration File Sample, page D-12 Sample Configured snmpd.cnf File, page D-13 • Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1), • page D-16 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3), •...

  • Page 360: Sample Installation Scripts

    Uncompressing SUA Uncompressing TCAP Uncompressing almM Uncompressing amDmpr Uncompressing cdrDmpr Uncompressing cfgM Installing chk_inv Uncompressing diskmonitor Uncompressing engine.no_smartalloc Uncompressing engine.smartalloc Uncompressing foverd Uncompressing ioChanMgr Uncompressing measMgr Uncompressing mmBldCfg Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...

  • Page 361: Sample Output From Install.sh

    Updating parameters for mgcbackup Updating parameters for mgcrestore Updating parameters for restore.sh Updating parameters for rmsem.sh Updating parameters for startAudit.mml Updating parameters for startLogServer Installation of <CSCOga001> was successful. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...
  • Page 362 Starting the daemon ... The tt60 daemon has started successfully. Installing client components ... Creating new /var/TimesTen/sys.ttconnect.ini Extracting 3rd party tools ... Creating /opt/TimesTen/tt60/doc ... Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Appendix D Sample Installation Scripts OL-18083-14...
  • Page 363 Updating parameters for XECfgParm.dat Updating parameters for trigger.dat Updating parameters for di Updating parameters for migrate Updating parameters for migrateTKGFile Installing /opt/CiscoMGC/etc/CONFIG_LIB/migrate_mod.tar.gz Installing /opt/CiscoMGC/etc/migrate/migrate_scr.tar.gz Installing new .dat files in /opt/CiscoMGC/etc Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...
  • Page 364 ISUPV2_FRENCH ISUPV2_GERMAN ISUPV2_ISRAEL ###################################################################### ################### Q721 Protocol Family ####################### ####################### Q721_BASE Q721_BRAZILIAN Q721_CHINA Q721_FRENCH Q721_PHILLIPINE Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide IETF_SIP PRI Protocol Family ###################### ###################### ATT_41459 ATT_41459_C2 BELL_1268 BELL_1268_C2 ETS_300_102 ETS_300_102_C2 ETS_300_172 ######################...
  • Page 365 Uncompressing LEG_CONTROLLER.mdo Uncompressing LEG_CONTROLLER.so Uncompressing LEG_CONTROLLER_H248V2.mdo Uncompressing LEG_CONTROLLER_H248V2.so Uncompressing LEG_CONTROLLER_MGCP.mdo Uncompressing LEG_CONTROLLER_MGCP.so OL-18083-14 ########################################## at line 118 in file getport.c at line 123 in file getport.c Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Output from install.sh...
  • Page 366 Uncompressing ETS_300_102.mdo Uncompressing ETS_300_102.so Uncompressing ETS_300_102_C2.mdo Uncompressing ETS_300_102_C2.so Uncompressing ETS_300_172.mdo Uncompressing ETS_300_172.so Installation of <CSCO20000> was successful. Uncompressing ETS_300_121.mdo Uncompressing ETS_300_121.so Uncompressing ETS_300_356.mdo Uncompressing ETS_300_356.so Uncompressing HONGKONG.mdo Uncompressing HONGKONG.so Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...
  • Page 367 Uncompressing Q761_99VER_BASE.mdo Uncompressing Q761_99VER_BASE.so Uncompressing Q761_MALAYSIAN.mdo Uncompressing Q761_MALAYSIAN.so Uncompressing Q761_SINGAPORE.mdo Uncompressing Q761_SINGAPORE.so Uncompressing Q761_SINGAPORE_C2.mdo Uncompressing Q761_SINGAPORE_C2.so Uncompressing Q761_TAIWAN.mdo Uncompressing Q761_TAIWAN.so Uncompressing Q761_THAILAND.mdo Uncompressing Q761_THAILAND.so Installation of <CSCO33000> was successful. Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...
  • Page 368 Uncompressing ISUPV3_UK_C4.so Installation of <CSCO50000> was successful. Uncompressing Q721_BASE.mdo Uncompressing Q721_BASE.so Uncompressing Q721_BRAZILIAN.mdo Uncompressing Q721_BRAZILIAN.so Uncompressing Q721_BRAZILIAN_C2.mdo Uncompressing Q721_BRAZILIAN_C2.so Uncompressing Q721_CHINA.mdo Uncompressing Q721_CHINA.so Uncompressing Q721_FRENCH.mdo Uncompressing Q721_FRENCH.so Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide D-10 OL-18083-14...
  • Page 369 Please Verify that you have over 4000000K Available swap The tt60 daemon has stopped successfully. Installation completed Wed Sep 24 03:52:32 EDT 2008 Installation log can be found in /var/adm/MGC_install.log bash-3.00# Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide D-11 OL-18083-14...

  • Page 370: Updated Configuration File Sample

    *.Peer_NextHop3 = 0.0.0.0 *.Peer_NextHop4 = 0.0.0.0 *.Peer_NextHop5 = 0.0.0.0 *.Peer_NextHop6 = 0.0.0.0 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide D-12 REQUIRED STARTUP PARAMETERS DO NOT MOVE THESE PARAMETERS BEYOND THIS BOX # Transpath Id for ASN...

  • Page 371: Sample Configured Snmpd.cnf File

    # don't synch slave data with master transpath "Herndon, Virginia" "Cisco Systems, Inc. +1 703 484 3000" Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configured snmpd.cnf File # Must be from *.IP_Addr1 Subnet. # Must be from *.IP_Addr2 Subnet. D-13...
  • Page 372 #Entry type: usmUserEntry #Format: usmUserEngineID usmUserName usmUserAuthProtocol usmUserPrivProtocol usmUserStorageType usmTargetTag AuthKey PrivKey Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide D-14 80000 65536 (text) (text) (text) (octetString) (text) (text) (nonVolatile, permanent, readOnly) admin mgcusr mgcusr localSnmpID - - nonVolatile...
  • Page 373 RemoteWrite critAppProcEntry.0.2 ff:f7 excluded \ RemoteWrite critAppProcEntry.0.3 ff:f7 excluded \ RemoteWrite critAppProcEntry.0.4 ff:f7 excluded \ (text) (text) (trap(1), inform(2)) (nonVolatile, permanent, readOnly) 32 TrapSink trap nonVolatile Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configured snmpd.cnf File D-15...

  • Page 374: Sample Configured Xecfgparm.dat Files For Cisco Pgw 2200 Softswitch Release 9.8(1

    Password Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) The following sample XECfgParm.dat files for Cisco PGW 2200 Softswitch Release 9.8(1) are located in the /opt/CiscoMGC/etc directory. # File: XECfgParm.dat # Copyright (c) 1997-2008 by Cisco Systems, Inc.
  • Page 375 *.ipAddrPeerB = *.IP_Addr1 = motherboard *.IP_Addr2 = OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) Thus application overrides of the default parameter values - call verification utility - Execution Environment REQUIRED STARTUP PARAMETERS DO NOT MOVE THESE PARAMETERS BEYOND THIS BOX...
  • Page 376 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) *.IP_Addr3 = *.IP_Addr4 = # These are Next Hop (router) IP Addresses # They should be used when the Next Hop address(es) # are different on the two MGC hosts *.IP_NextHop1 =...
  • Page 377 *.CPUTimerInterval = 3000 *.CallCutoffTimer =0 *.CallCutoffTimerUnits =0 OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) REQUIRED STARTUP PARAMETERS DO NOT MOVE THESE PARAMETERS BEYOND THIS BOX # T ==> Don't accumulate meas in shared mem /tmp # temporary directory ../var...
  • Page 378 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) *.tibcoSupport = *.PartialCliTypeOfSwitch = 0 *.PartialCliPnoIdentity = 0 *.PartialCliSwitchNumber = 0 *.LISupport = disable *.PNPopulate = disable *.maxLocationLabels = 3000 *.DisableCCBSoverTunneledQSIG = 0 # 0 = Enable, 1 = Disable *.analysisCapabilityLevel = 0...
  • Page 379 #------------- # Engine #------------- engine.SysPropagateChanAvail = false engine.SysGeneratedCode = true engine.SysGRSTimerInterval = 0 engine.SysGRSBlockSize = 0 engine.SysSGCPRetryCount = 3 OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) Debug Debug Debug Debug Debug Debug Debug Debug Debug...
  • Page 380 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) engine.SysSGCPRetryTimerInterval = 1000 engine.SysCLIval = false engine.SysToneDetect = false engine.SysNumTrans = false engine.SysMinOverlap = 0 engine.SysMaxOverlap = 28 engine.SysGSMTimerInterval = 10000 engine.LCMMdlFile = ../lib/lcm engine.CCMdlFile = engine.mdoDir = ../lib/ engine.VersionTimeoutValue = 10000...
  • Page 381 = true ioChanCtl.ituIsNewZealand = false properties #----------- # SIP OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) = true = ../var/.cdr.seq If IPCTimer is 0, then hard-coded value will be 30000 - Heart-beat timer, Not yet implemented.
  • Page 382 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) #----------- SIP.maxConnection = 200 simultaneourly SIP.connIdlePeriod = 43200 state in second. 0 means PGW never close idle connection SIP.connLocalMsgQueueSize = 1500 connection queue SIP.naptr_record_locate = 1 # whether to perform natpr dns query SIP.transportProtocol = udp # obsolete value, keep here to data migration...
  • Page 383 = 2974 replicator.reconnectInterval = 15 replicator.numberReadThreads = 1 #----------------- # Audit properties #----------------- engine.AuditTimerInterval = 1000 engine.MaxAuditCics = 32 OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) serial /dev/null 1000 6000 1000 3000 1000 /dev/null...
  • Page 384 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.8(1) #----------------- # INAP prepaid properties #----------------- engine.RelINAPCallsAfterSwOver = true #---------------------------------- # Disk Monitor Parameters #---------------------------------- diskmonitor.Limit occurs when threshold is exceeded. diskmonitor.Threshold diskmonitor.SoftLimit setting it to false does not affect log file removal, see also PreserveLogs setting.
  • Page 385 #------------------------------------------------------------------------------ MML.rtrv-callinfo = 30000 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) The following sample XECfgParm.dat files for Cisco PGW 2200 Softswitch Release 9.7(3) are located in the /opt/CiscoMGC/etc directory. # File: XECfgParm.dat # Copyright (c) 1997-2007 by Cisco Systems, Inc.
  • Page 386 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) # diskmonitor - disk monitor shell script # XE #------------------------------------------------------------------------------ #---------------- MGC Environment Configuration Tool Usage -------------------- *.platformId = *.transpathId = 01 *.ownTranspathId = 01 *.peerTranspathId = 02 *.MGC_CDR_NODE_ID = MGC-CDR-NODE-STRING *.desiredPlatformState = master...
  • Page 387 *.maxNumPril3IOCCs = 3 *.maxTrueOPCs = *.maxCapOPCsPerTrueOPC =8 *.maxNumRLMPorts = 8 IUA.maxExtNodes = IUA.maxSigPathsPerExtNode = OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) # MIGRATED # MIGRATED # MIGRATED # MIGRATED # MIGRATED # MIGRATED # MIGRATED...
  • Page 388 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) IUA.maxSigPaths = M3UA.maxSgp = 96 M3UA.maxSigServices = M3UA.maxOPCs = M3UA.maxRoutesPerOpcDpc = SUA.maxSgp = 8 SUA.maxSigServices = SUA.maxOPCs = SUA.maxRoutesPerOpcApcSSN = and remote SSN *.AllLinksFailCausesFailover = false *.AllISDNLinksFailCausesFailover = false *.dataSourceName = howdydb...
  • Page 389 = procM.procHealthDfltAlmCat = procM.servicesDir procM.servFmt procM.recovDbFile procM.logDBFile procM.runAsDaemon #------------- OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) If the DISK alarm is activated because Only the logging level of Debug Debug Debug Debug Debug Debug...
  • Page 390 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) # cfgM #------------- cfgM.recovDbFile #------------- # Engine #------------- engine.SysPropagateChanAvail = false engine.SysGeneratedCode = true engine.SysGRSTimerInterval = 0 engine.SysGRSBlockSize = 0 engine.SysSGCPRetryCount = 3 engine.SysSGCPRetryTimerInterval = 1000 engine.SysCLIval = false engine.SysToneDetect = false...
  • Page 391 # in IOCC after recovery of SS7 sigserv, before forwarding to engine ioChanMgr.IDUHoldTimer = 500 #----------- # ioChanCtl #----------- ioChanCtl.DPNSSTestFrames = true ioChanCtl.xgcpMultiThread = true OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) # MIGRATED # MIGRATED # MIGRATED # MIGRATED # MIGRATED # MIGRATED # MIGRATED = true = ../var/.cdr.seq...
  • Page 392 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) ioChanCtl.ituIsNewZealand = false properties #----------- # measM #----------- Currently we assume 8000 XEMeas objects fit into 8 Mb of shared memory. measM.sm_seg_size = 32 measM.loadBalanceFactor = 20 # num of measmgr distribution points every 5 minutes measM.port = default...
  • Page 393 # Audit properties #----------------- engine.AuditTimerInterval = 1000 engine.MaxAuditCics = 32 #----------------- # INAP prepaid properties #----------------- engine.RelINAPCallsAfterSwOver = true OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) # MIGRATED serial /dev/null 1000 6000 1000 3000 1000...
  • Page 394 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.7(3) #---------------------------------- # Disk Monitor Parameters #---------------------------------- diskmonitor.Limit = 7 diskmonitor.Threshold = 80 diskmonitor.SoftLimit = false diskmonitor.CdrRmFinished = 0 diskmonitor.OptFileSys = diskmonitor.CoreRmDays = 1 diskmonitor.CfgRmDirs = 64 diskmonitor.logPrio = Info diskmonitor.logFileNamePrefix = diskmonitor # causes log messages to be diverted to...
  • Page 395 Appendix D Sample Installation Scripts Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) The following sample XECfgParm.dat files for Cisco PGW 2200 Softswitch Release 9.6(1) are located in the /opt/CiscoMGC/etc directory. # File: XECfgParm.dat # Purpose: # This file contains configuration parameters that may be accessed by # XE application programs at run-time.
  • Page 396 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) *.transpathId = *.ownTranspathId = *.peerTranspathId = *.MGC_CDR_NODE_ID = *.desiredPlatformState = *.virtualFaultTolerant = *.SysConnectDataAccess = Subsystem *.GWClearChannelAlgorithm = *.SipToIsupInterworkingInd = *.ipAddrLocalA = 10.0.1.160 *.ipAddrLocalB = 10.128.1.5 *.ipAddrPeerA = 10.0.1.161 *.ipAddrPeerB = 10.128.1.6 *.IP_Addr1 = 10.0.1.160...
  • Page 397 *.CPUTimerInterval = 3000 *.CallCutoffTimer = *.tibcoSupport = OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) REQUIRED STARTUP PARAMETERS DO NOT MOVE THESE PARAMETERS BEYOND THIS BOX # T ==> Don't accumulate meas in shared mem # shared memory based address...
  • Page 398 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) *.PartialCliTypeOfSwitch = 0 *.PartialCliPnoIdentity = 0 *.PartialCliSwitchNumber = 0 *.LISupport = disable *.maxLocationLabels = 3000 #------------------------------------------------------------------------ # Log Server logfile locations #------------------------------------------------------------------------ # daemonAddr is socket port for logger daemon logger.daemonAddr = ../var/lsd_addr...
  • Page 399 = 1 engine.CircuitReservation = false engine.CallBackDBCleanUpTimer = 3600000 (min:600000 to max:10800000 *.MaxNumTGAdvances = 1 *.RedirectingATree = 0 OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) Debug Debug Debug true true false # smallest check health interval...
  • Page 400 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) *.ClearingLocation = 0 the Clearing Location field in Call Context *.DefaultLocation = 0 not override the Default Location field in Call Context *.detailedCallEventCapture = 1 *.SelectTermCustGrpId = 0 SigPath CustGrpId is 0000.
  • Page 401 MML.logFileNamePrefix = mml MML.autonomous = true MML.runAsDaemon = false MML.timeout=10000 OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) 30000 - Heart-beat timer, Not yet implemented. all the queued stat events. 1000 # enable threading for the IP receive loop in MGCP...
  • Page 402 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) resolution) # individual timeout values for MML commands: # format is: # (verb all lowercase) MML.chg-cfg = MML.startPM = MML.stopPM = MML.vld-cic = MML.snd = MML.enhancedHelpCompletion = true #----------...
  • Page 403 = 0 engine.SendHardwareBlock = false OL-18083-14 Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) # optional thread (0=no threads,1=one thread) # Minimum number of days to preserve (Trimming only There is no maximum number of days topreserve.)
  • Page 404 Appendix D Sample Installation Scripts Sample Configured XECfgParm.dat Files for Cisco PGW 2200 Softswitch Release 9.6(1) *.maxNumPril3IOCCs = 3 *.FaxUpspeedCodecPreference = null ISDNBRI.tcpPingPort = 0 *.MMLManualBlockingCic = 0 *.analysisCapabilityLevel = 0 MML.rtrv-callinfo = 30000 *.AllISDNLinksFailCausesFailover = false diskmonitor.PreserveCDRs = false pom.respTimeout = 1200000...

  • Page 405: Appendix

    Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh You must stop running the Cisco PGW 2200 Softswitch software and quit all the MML sessions before you uninstall the Cisco PGW 2200 Softswitch software. The following is a sample output from the uninstall script.
  • Page 406 Appendix E Sample Uninstall Scripts Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh Removing /opt/CiscoMGC/etc/migrate/migrate_4_5 Removing /opt/CiscoMGC/etc/migrate/migrate_5_6 Removing /opt/CiscoMGC/etc/migrate/migrate_6_7 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0001_7.0002 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0001_7.1 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0002_7.1 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0003_7.1 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0004_7.1 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0005_7.1006 Removing /opt/CiscoMGC/etc/migrate/migrate_7.0_7.0001 Removing /opt/CiscoMGC/etc/migrate/migrate_7.1001_7.1002 Removing /opt/CiscoMGC/etc/migrate/migrate_7.1002_7.1003 Removing /opt/CiscoMGC/etc/migrate/migrate_7.1003_7.1004...
  • Page 407 Appendix E Sample Uninstall Scripts Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh Removing /opt/CiscoMGC/etc/CONFIG_LIB/4.0_to_5.0/propLookUp.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/4.0_to_5.0/services.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/alarmCats.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/compTypes.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/components.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/propSet.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/properties.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/5.0_to_6.0/services.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/6.0_to_7.0/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/6.0_to_7.0/alarmCats.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/6.0_to_7.0/compTypes.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/6.0_to_7.0/components.mod...
  • Page 408 Appendix E Sample Uninstall Scripts Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1005_to_7.1006/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1005_to_7.1006/properties.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1006_to_8.0/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1006_to_8.0/properties.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1006_to_8.0/services.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1007_to_7.1008/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1007_to_7.1008/properties.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1008_to_8.0/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1008_to_8.0/properties.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1009_to_8.0/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1009_to_8.0/properties.mod Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1010_to_8.0001/ Removing /opt/CiscoMGC/etc/CONFIG_LIB/7.1010_to_8.0001/components.mod...
  • Page 409 Saving table CISCO.A_NUMBERDIALPLANSELECTION Saving rows... 0/0 rows saved. Table successfully saved. OL-18083-14 Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh SunOS 5.10 Generic January 2005 SunOS 5.10 Generic January 2005 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 410 Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh Saving table CISCO.BLACKLIST_A Saving rows... 0/0 rows saved. Table successfully saved. Saving table CISCO.BLACKLIST_B Saving rows... 0/0 rows saved. Table successfully saved. Saving table CISCO.CBBOOKINGINFO Saving index CISCO.CBBOOKINGINFO_IDX1 Saving rows...
  • Page 411 The tt60 daemon has stopped successfully. Removing directories and files... Modifying /etc/syslog.conf Removal of <CSCOga002> was successful. OL-18083-14 Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 412 Appendix E Sample Uninstall Scripts Removing a Cisco PGW 2200 Softswitch Software Version: Sample Output for uninstall.sh Removal of <CSCOga001> was successful. Removal of <CSCOga000> was successful. Modifying /etc/init.d/inetinit Removal of <CSCOgu000> was successful. Removal of <CSCO00000> was successful. Removal of <CSCO01000> was successful.

  • Page 413: Appendix

    OL-18083-14 A P P E N D I X 9600 Catalyst_5513A Jim Smith 913 555-7998 public private module chassis Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide...
  • Page 414 8022toether set bridge ipx 8023rawtofddi snap #vtp set vtp domain vsc3000 set vtp mode transparent set vtp v2 disable set vtp pruneeligible 2-1000 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide bridge repeater auth ippermit vmps entity...
  • Page 415 #syslog set logging console enable set logging server disable OL-18083-14 1003 1003 1003 1003 4 1005 1005 1005 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 A...
  • Page 416 #protocolfilter set protocolfilter disable #mls set mls enable set mls flow destination set mls agingtime 256 set mls agingtime fast 0 0 set mls nde disable Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide OL-18083-14...
  • Page 417 100% static 2/1-2 desirable isl 1-1005 desirable isl 1-1005 2/1-2 disable 2/1-2 3019 2/1-2 cost 3018 cost 3018 3/19-20,3/22-24 3/1-18 3/21 3/1-24 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 A...
  • Page 418 4/7 set spantree portvlanpri 4/8 set spantree portvlanpri 4/9 set spantree portvlanpri 4/10 0 set spantree portvlanpri 4/11 0 set spantree portvlanpri 4/12 0 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide 3/1-24 normal 3/1-24 half 3/1-24...

  • Page 419: Sample Configuration For Cisco Catalyst 5500 A Rsm

    3018 cost 3018 cost 3018 cost 3099 12/1 normal 12/1 disable 12/1 12/1 on isl 1-1005 12/1 3005 12/1 cost 3004 4-8,11-15 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 A...
  • Page 420 0 line aux 0 line vty 0 4 password cisco login Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Appendix F Sample LAN Configurations OL-18083-14...

  • Page 421: Sample Configuration For Cisco Catalyst 5500 B

    0.0.0.0 209.165.200.224 set ip alias default #Command alias OL-18083-14 9600 Catalyst_5513B John Smith 913 555-7998 public private enable enable 0.0.0.0 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 B...
  • Page 422 4 1 set spantree hello set spantree maxage set spantree priority 2000 1 #vlan 2 set spantree fwddelay 4 2 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide F-10 8023raw 8023 Appendix F Sample LAN Configurations...
  • Page 423 LOCAL7 set logging server severity 4 set logging buffer 500 OL-18083-14 1003 1003 1003 1003 4 1005 1005 1005 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 B F-11...
  • Page 424 1/1 set spantree portvlanpri 1/2 set spantree portvlancost 1/1 set spantree portvlancost 1/2 #module 2 : 2-port 10/100BaseTX Supervisor Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide F-12 1/1-2 1/1-2 1/1-2 normal...
  • Page 425 3/1-24 3/1-24 enable 3/1-24 3100 3/1-24 4/1-2 4/7-8 4/3-6 4/1-12 4/1-12 normal 4/1-10 auto 4/11-12 4/11-12 full 4/1-12 disable 4/1-12 Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 B F-13...
  • Page 426 #module 7 empty #module 8 empty #module 9 empty #module 10 empty #module 11 empty #module 12 : 1-port Route Switch set module name Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide F-14 4/1-12 disable 4/1-12 static 4/1-12...

  • Page 427: Sample Configuration For Cisco Catalyst 5500 B Rsm

    3 authentication vsc3000 OL-18083-14 12/1 normal 12/1 disable 12/1 12/1 on isl 1-1005 12/1 3005 12/1 cost 3004 4-8,11-15 preempt preempt Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide Sample Configuration for Cisco Catalyst 5500 B F-15...
  • Page 428 0 line aux 0 line vty 0 4 password cisco login Cisco PGW 2200 Softswitch Release 9.8 Software Installation and Configuration Guide F-16 Appendix F Sample LAN Configurations OL-18083-14...

Table of Contents

Save PDF
