Instructions for Use
Color LCD Monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For monitor adjustment and settings, refer to the "Installation
Manual".
• For the latest product information including the "Instructions for
Use", refer to our web site :
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo RadiForce RX370
Summary of Contents for Eizo RadiForce RX370
- Page 1 Instructions for Use Color LCD Monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For monitor adjustment and settings, refer to the “Installation Manual”.
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO product specifications are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. - Page 4 A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 5 If the unit falls, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
- Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the power cord or cables attached is dangerous and may result in injury. Carry or place the unit according to the correct specified methods. •...
-
Page 7: Notice For This Product
When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The screen may have defective pixels or a small number of light dots on the screen. This is due to the characteristics of the panel itself, and is not a malfunction of the product. -
Page 8: To Use The Monitor For A Long Time
• To adjust measurement results of the integrated calibration sensor (Integrated Front Sensor) to those of an EIZO external sensor (UX2 sensor) that is sold separately, perform correlation between the Integrated Front Sensor and the external sensor using RadiCS / RadiCS LE. Periodical correlation allows you to maintain the measurement accuracy of the Integrated Front Sensor at a level equivalent to that of the external sensor. -
Page 9: Table Of Contents
CONTENTS ............. 9 Chapter 1 Introduction ........10 1-1. Features ............10 1-2. Package Contents ........12 ● EIZO LCD Utility Disk ........13 1-3. Controls and Functions ......14 Chapter 2 Installation / Connection ....15 2-1. Before Installing the Product .....15 ●... -
Page 10: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features ● Hybrid monochrome and color display When the Hybrid Gamma PXL function is enabled, this product automatically differentiates between monochrome and color parts of the same image at a pixel level, and displays them respectively in optimal gradations. - Page 11 ● Quality control • This monitor has a built-in calibration sensor (Integrated Front Sensor). This sensor enables the monitor to perform calibration (SelfCalibration) and Grayscale Check independently. • Using RadiCS LE that is attached to the monitor, you can manage history related to the monitor, and the SelfCalibration target and execution schedule.
-
Page 12: Package Contents
1-2. Package Contents Check that all of the following items are contained in the package. If any of these are missing or damaged, contact your dealer or local EIZO representative. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport this product. -
Page 13: Eizo Lcd Utility Disk
● EIZO LCD Utility Disk The CD-ROM contains the following items. Refer to "Readme.txt" on the disk for software startup procedures or file reference procedures. • Readme.txt file • RadiCS LE monitor quality control software (for Windows) • User’s Manual... -
Page 14: Controls And Functions
1-3. Controls and Functions Approx. 30° 1. Integrated Front Sensor This sensor is used to perform calibration and Grayscale Check. (Movable) 2. Ambient Light Sensor This sensor measures environmental illumination. Environmental illuminance measurement is performed using the RadiCS / RadiCS LE quality control software. 3. -
Page 15: Chapter 2 Installation / Connection
Chapter 2 Installation / Connection 2-1. Before Installing the Product Carefully read “PRECAUTIONS” (page 3) and always follow the instructions. If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to the composition of the rubber. -
Page 16: Connecting Cables
2-2. Connecting Cables Attention • Check that the monitor, PC, and peripherals are powered off. • When replacing the current monitor with this monitor, refer to “4-2. Compatible Resolutions” (page 23) to change the PC settings for resolution and vertical scan frequency to those that are available for this monitor, before connecting the PC. - Page 17 Attention • Visit the EIZO website for information about monitors and graphic boards that can be used for the daisy- chain connection: www.eizoglobal.com • When using a daisy-chain connection, connect the cable to the input connector •...
- Page 18 Connect the USB cable to the monitor’s USB upstream port and to the computer’s downstream port respectively. The cable connection is required when you use RadiCS / RadiCS LE or when you connect a USB device (USB-connected peripheral device) to the monitor. USB cable: UU300 Attention •...
-
Page 19: Turning On The Power
2-3. Turning On the Power Touch to turn on the power to the monitor. The power switch indicator of the monitor lights up green. If the indicator does not light up, see “Chapter 3 No-Picture Problem” (page 21). Note • When you touch any of the operation switches excluding with the monitor power turned off, starts flashing to let you know where the power switch is located. -
Page 20: Adjusting The Screen Height And Angle
2-5. Adjusting the Screen Height and Angle Hold the top and bottom or left and right edges of the monitor with both hands, and adjust the screen height, tilt and swivel the screen to the optimum position for performing tasks. Attention •... -
Page 21: Chapter 3 No-Picture Problem
• Turn off the main power, and then turn it on again. • Power switch indicator blinks: Orange, • Connect via the signal cable specified by EIZO. Turn off the Green main power, and then turn it on again. -
Page 22: Chapter 4 Specifications
Chapter 4 Specifications 4-1. Specifications List Type RX370: Anti-Glare RX370-AR: Anti-Reflection LCD Panel Type Color (IPS) Backlight Size 54.1 cm (21.3 inch) Resolution (H x V) 1536 × 2048 Display Size (H x V) 324.9 mm × 433.2 mm Pixel Pitch 0.2115 mm Display Colors 10-bit (DisplayPort): 1073.74 million colors (Max.) (from a... -
Page 23: Compatible Resolutions
Operating Temperature 0 ˚C - 35 ˚C (32 ˚F - 95 ˚F) Environmental Humidity 20 % - 80 % R.H. (no condensation) Requirements Air Pressure 540 hPa - 1060 hPa Transportation Temperature -20 ˚C - 60 ˚C (-4 ˚F - 140 ˚F) / Storage Humidity 10 % - 90 % R.H. -
Page 24: Optional Accessories
4-3. Optional Accessories The following accessories are available separately. For the latest information about the optional accessories and information about the latest compatible graphics board, refer to our web site. www.eizoglobal.com Calibration Kit RadiCS UX2 Ver. 5.0.8 or later RadiCS Version Up Kit Ver. 5.0.8 or later Network QC Management Software RadiNET Pro Ver. -
Page 25: Appendix
Appendix Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided. -
Page 26: Emc Information
Be sure to use the cables attached to the product, or cables specified by EIZO. Use of cables other than those specified or provided by EIZO of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and improper operation. - Page 27 Technical Descriptions Electromagnetic emissions The RadiForce series is intended for use in the electromagnetic environment specified below. The customer or the user of the RadiForce series should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions Group 1 The RadiForce series uses RF energy only for its internal function.
- Page 28 Electromagnetic immunity The RadiForce series has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the RadiForce series must ensure that the RadiForce series is used in the following environments: Immunity test Test level for...
- Page 29 Recommended separation distances between portable or mobile RF communication equipment and the RadiForce Series The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the RadiForce series can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series.
- Page 30 The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. For other portable and mobile RF communication equipments (transmitters), minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series as recommended below, according to the maximum output power of the communications equipment.
-
Page 31: Information For Radio Interference
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... - Page 32 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan 中国苏州市苏州工业园区展业路 8 号中新科技工业坊 5B Carl-Benz-Straße 3, 76761 Rülzheim, Germany 00N0N214A1 www.eizoglobal.com IFU-RX370-6 Copyright © 2021 EIZO Corporation. All rights reserved. 1st Edition - February 19th, 2021 Printed in Japan.
