Instructions for Use
Color LCD monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For monitor adjustment and settings, refer to the "Installation
Manual".
• For the latest product information including the "Instructions for
Use", refer to our web site :
http://www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo RadiForce RX850
Summary of Contents for Eizo RadiForce RX850
- Page 1 Instructions for Use Color LCD monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For monitor adjustment and settings, refer to the “Installation Manual”.
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • For personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. - Page 4 A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 5 Before installation, make sure that desks, walls, and others an arm stand is fixed on have adequate mechanical strength. When the unit is dropped, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
- Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the cord attached is dangerous. It may result in injury. Carry or place the unit according to the correct specified methods. •...
-
Page 7: Notice For This Monitor
The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. Notice for this monitor... -
Page 8: Cleaning
Do not press on the panel or edge of the frame strongly, as this may result in display malfunctions, such as interference patterns, etc. If pressure is continually applied to the panel, it may deteriorate or damage your panel. (If the pressure marks remain on the panel, leave the monitor with a black or white screen. The symptom may disappear.) Do not scratch or press on the panel with any sharp objects, as this may result in damage to the panel. -
Page 9: Table Of Contents
CONTENTS ............. 9 Chapter 1 Introduction ........10 1-1. Features ............10 1-2. Package Contents ........11 1-3. EIZO LCD Utility Disk........11 ● Disk contents and software overview ....11 ● Using RadiCS LE/ScreenManager Pro for Medical ............11 1-4. Controls and Functions ......12 Chapter 2 Setting Up ........ -
Page 10: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features • 31.1 inches • Wide-gamut panel *1 Displayed image colors may appear to have a different tint than sRGB-enabled monitors due to the different color gamut. -
Page 11: Package Contents
• Digital signal cable: DVI-D - DVI-D (Dual Link) (DD300DL) × 2 pcs. 1-3. EIZO LCD Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with this product. The following table shows the disk contents and the overview of the software programs. ●... -
Page 12: Controls And Functions
1-4. Controls and Functions Monitor Adjustment menu 1. Operation switches Displays the menu. Follow the guide to perform the desired operations. switch • Turns the power on or off. • Indicates the monitor’s operation status. Green: Operating, Orange: Power saving mode, Off: Main power/power off 3. -
Page 13: Chapter 2 Setting Up
Chapter 2 Setting Up 2-1. Compatible Resolutions The monitor supports the following resolutions. √ : Supported 8M Pixel Mode QFHD Mode Vertical Applicable Resolution Dot Clock: scan signal DisplayPort DisplayPort frequency 640×480 60 Hz √ √ √ √ 720×400 VGA TEXT 70 Hz √... -
Page 14: Connecting Cables
• Do not connect or disconnect the cable while the AC adapter main power is on. • Do not install the AC adapter in the wrong orientation. The side with the EIZO logo should face up. Check the shape of the monitor connector, and connect the power cable. -
Page 15: Adjusting The Screen Height And Angle
Turn on the AC adapter main power. -: On, ○: Off Connect the USB cable when using RadiCS LE or ScreenManager Pro for Medical. Connecting to the Monitor Connecting to a Computer Touch to turn on the monitor. The monitor’s power indicator lights up green. Turn on the PC. -
Page 16: Attaching A Power Cord Holder
2-4. Attaching a Power Cord Holder Attach the power cord holder to prevent the power cord from falling off. Attention • Be sure to attach the power cord holder when the main power to the AC adapter is off or before the power cable is plugged into the power outlet. -
Page 17: Chapter 3 Troubleshooting
Chapter 3 Troubleshooting If a problem still remains after applying the suggested remedies, contact your local EIZO representative. Problem Possible cause and remedy 1. No picture • Check whether the power cord and the adapter power • Power indicator does not light. - Page 18 Problem Possible cause and remedy • The message shows that the input signal is • Check whether the PC is configured to meet the resolution out of the specified frequency range. and vertical scan frequency requirements of the monitor Example: (see “2-1.
-
Page 19: Chapter 4 Specifications
Chapter 4 Specifications LCD Panel Type RX850: IPS (Anti-Glare) RX850-AR: IPS (Anti-Reflection) Backlight Size 79 cm (31.1 inch) (78.9 cm diagonal) Native Resolution 4096 dots × 2160 lines Display Size (H x V) 697.9 mm × 368.0 mm Pixel Pitch 0.1704 mm Display Colors 10-bit colors... - Page 20 Transportation/ Temperature -20 ˚C to 60 ˚C (-4 ˚F to 140 ˚F) Storage Humidity 10 % to 90 % R.H. (no condensation) Environmental Air pressure 200 hPa to 1060 hPa Requirements Outside Dimensions Unit: mm Monitor 501.5 (342.5) SWIVEL 344° (23.3) (23.3) 700.4 Ambient light Sensor...
- Page 21 Accessories Calibration Kit EIZO “RadiCS UX1” Ver. 4.3.0 or later EIZO “RadiCS Version Up Kit” Ver. 4.3.0 or later Network QC Management Software EIZO “RadiNET Pro” Ver. 4.3.0 or later Cleaning Kit EIZO “ScreenCleaner” For the latest information about the accessories and information about the latest compatible graphics board, refer to our web site.
-
Page 22: Chapter 5 Glossary
Chapter 5 Glossary DDC (Display Data Channel) VESA provides the standardization for the interactive communication of the setting information, etc. between a PC and the monitor. DICOM (Digital Imaging and Communication in Medicine) The DICOM standard was developed by the American College of Radiology and the National Electrical Manufacturer’s Association of the USA. - Page 23 HDCP (High-bandwidth Digital Content Protection) Digital signal coding system developed to copy-protect the digital contents, such as video, music, etc. This helps to transmit the digital contents safely by coding the digital contents sent via the DVI or HDMI connector on the output side and decoding them on the input side. Any digital contents cannot be reproduced if both of the equipments on the output and input sides are not applicable to HDCP system.
-
Page 24: Appendix
Kensington and MicroSaver are trademarks of ACCO Brands Corporation. EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorNavigator, EcoView NET, EIZO EasyPIX, EIZO ScreenSlicer, i • Sound, Screen Administrator, and UniColor Pro are trademarks of EIZO Corporation. -
Page 25: Medical Standard
Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided. -
Page 26: Emc Information
Be sure to use the cables attached to the product, or cables specified by EIZO. Use of cables other than those specified or provided by EIZO of this equipment could result in in- creased electromagnetic emissions or decreased electromagnetic immunity of this equipment and improper operation. - Page 27 Technical Descriptions Electromagnetic emissions The RadiForce series is intended for use in the electromagnetic environment specified below. The customer or the user of the RadiForce series should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment - Guidance RF emissions Group 1 The RadiForce series uses RF energy only for its internal function.
- Page 28 Electromagnetic immunity The RadiForce series has been tested at the following compliance levels according to the testing requirements for professional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the RadiForce series must ensure that the RadiForce series is used in the following environments: Immunity test Test level for...
- Page 29 Recommended separation distances between portable or mobile RF communication equipment and the RadiForce Series The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the RadiForce series can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series.
- Page 30 The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. For other portable and mobile RF communication equipments (transmitters), minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series as recommended below, according to the maximum output power of the communications equipment.
-
Page 31: Fcc Declaration Of Conformity
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... -
Page 32: Declaration Of Compliance With India Rohs
Declaration of compliance with India RoHS We, EIZO Corporation, hereby declare and guarantee that this product has been designed and manufactured in compliance with the E-Waste management rule 2016 which prohibit the inclusion of the following substances except for the exemptions listed in schedule II. - Page 33 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan 中国苏州市苏州工业园区展业路 8 号中新科技工业坊 5B Carl-Benz-Straße 3, 76761 Rülzheim, Germany 00N0L853F1 http://www.eizoglobal.com IFU-RX850-4 Copyright © 2014-2019 EIZO Corporation. All rights reserved. 6th Edition - October 15th, 2019...
