- Page 1 Video-inserter www.car-interface.com www.car-interface.com VL2-MMI2G www.car-interface.com for Audi with MMI2G navigation system Video-inserter with 2 video + RGB + rear-view camera input www.car-interface.com www.car-interface.com www.car-interface.com www.car-interface.com www.car-interface.com Version 18.06.2013...
-
Page 2: Table Of Contents
To receive a free update, the interface must be sent in at own cost. Labor cost for and other expenses involved with the software-updates will not be refunded. www.car-interface.com www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G... -
Page 3: Prior To Installation
Technical knowledge is necessary for installation. The place of installation must be free of www.car-interface.com moisture and away from heat sources. 1.1. Delivery contents www.car-interface.com www.car-interface.com www.car-interface.com Take down the serial number of the interface and store this manual for support purposes: ____________________ www.car-interface.com www.car-interface.com www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G... -
Page 4: Checking The Compatibility Of Vehicle And Accessories
Only the enabled video inputs can be accessed when switching through the video sources. It is recommended to enable only the required inputs. Video-input ON (down) OFF (up) www.car-interface.com Dip 1 enabled disabled Dip 2 Video IN1 enabled disabled Dip 3 Video IN2 enabled disabled www.car-interface.com www.car-interface.com www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G... -
Page 5: Rear-View Camera Settings (Dip 5)
The Interface has to be installed into the LVDS leads between monitor control-box and monitor. The monitor control box is located at A6, A8 and Q7 behind the dash board, at A4 www.car-interface.com and A5 behind the air-conditioning control panel. www.car-interface.com www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G... -
Page 6: Connections
The vehicles MMI wire is on pin 16 of the 20pin connector of the monitor control-box. The connector can be red or black. No liability for vehicle wire colors and pin definition! www.car-interface.com Possible changes by the vehicle manufacturer. The given information must be verified by the installer. Version 18.06.2013 CI-VL2-MMI2G... -
Page 7: Installation Procedure - Function Check
Then the AV-inputs will be controlled by the AUX-in interface (see manual of the AUX-1xx). Important! Do not connect the white wire additionally to pin 16 of the monitor control box when connected to the AUX-in interface. www.car-interface.com www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G... -
Page 8: Picture Settings
Audio pins Definition Audio input signal R/L of source IN2 Audio input signal R/L of source IN1 www.car-interface.com Audio output signal R/L of AUX-1xx, Gateway 500 or FM-modulator Ground No function www.car-interface.com Audio-switch-port Audio-cable www.car-interface.com www.car-interface.com Video-interface www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G... -
Page 9: Interface Operation
BATT/ACC range 7V ~ 25V Power 0.3A @12V Video input 0.7V~1V Video input formats PAL/NTSC Weight 195g www.car-interface.com Dimensions (box only) B x H x T 182 x 24 x 100 mm www.car-interface.com www.car-interface.com www.car-interface.com www.car-interface.com Version 18.06.2013 CI-VL2-MMI2G...
