One station transfer button is included with each Control
Head, a twin screw remote station requires only one
transfer button.
The -2 includes a green LED for synchronization.
Included are gasket, wire, terminals, mounting screws,
and watertight cable grip (for cable entrance on

Actuator).

Optional Control Head levers are available. (Contact
Mathers Controls Inc.)
2.1.2 Actuator
One 585 Actuator for each engine. Included are
installation instructions, ferrite bead, wire, terminals, tie
wraps, anti-static wrist strap, and WAGO tool (See Figure
11). A WAGO tool and a spare fuse are taped inside the
Actuator. Also included are two cable grips for power
cable and for start interlock cable. Mounting hardware is
not included.

2.1.3 Electric Cable

Pc.No. 180
Eight- Conductor Cable (Control to Actuator)
500 foot (152m) spool
Shielded 20 AWG, 300 V, PVC Insulated: -20°C to +80°C, PVC Jacket.
Color Coded UL VW-1.
Pc.No. 212
Two- Conductor Power Cable
250 foot (76m) spool
14 AWG, 300 V, PVC Insulated: -20°C to +105°C PVC Jacket.
Red with purple stripe and black UL VW-1.
Pc.No. 183
Two- Conductor Cable Start Interlock
250 foot (76m) spool
16 AWG, 300 V, PVC Insulated: -20°C to +105°C PVC Jacket.
Yellow with red stripe UL VW-1.
Page 2
Pc.No. 350
Pc.No. 349
Pc.No. 355
