- Page 1 L-0195 Manually Operated Lubrication Pump (Models: EGH-C and EGH-P) Operation Manual LUBE CORPORATION ...
-
Page 2: Table Of Contents
Contents Overview Page 1. Models of Grease Feed Equipment 1 2. Specifications 2.1 List of Product Specifications 2.2 List of Product Code Numbers for EGH-C and EGH-P 2.3 Name of Each Section 3. -
Page 3: Overview
1. Models of Grease Feed Equipment 1.1 Name: Manually operated lubrication pump 1.2 Models: EGH-C and EGH-P 2. Specifications 2.1 List of Product Specifications (1) EGH-C and E-GH-P type pumps Model EGH-2C EGH-4C EGH-4CB Pump Discharging volume (ｍ/stroke) Discharging pressure... - Page 4 Cartridge (with spring) for outdoor use Polypropylene 2.2 List of Code Numbers for EGH-C and EGH-P Code No. Model Type of Tank Pressure reduction Operation by 103780 EGH-2C Cartridge the handle Ditto 103781 EGH-4CB Cartridge (with spring) Ditto 103782 EGH-4C...
-
Page 5: Name Of Each Section
2.3 Name of Each Section （３１０） ３−φ９（穴） Hole Air bleed valve エア−抜きバルブ ７０ （１５０） 吐出口（Ｒｃ１／８） Discharge port (Rc 1/8) EGH-2C （３１０） 注意銘板 Caution plate ３−φ９（穴） Hole Air bleed valve エア−抜きバルブ ７０ （１５０） 吐出口（Ｒｃ１／８） Discharge port (Rc 1/8) EGH-4C - 3 -... - Page 6 （３１０） Caution plate 注意銘板 ３−φ９（穴） Hole Replenishing 補給口 port Air bleed valve エア−抜きバルブ ７０ （１５０） 吐出口（Ｒｃ１／８） Discharge port (Rc 1/8) EGH-3P - 4 -...
-
Page 7: Handling For Safety
3. Handling for Safety 3.1 Product Installation Choose a place for installation that allows easy operation of the handle, etc. Mount the grease feed equipment on a vertical wall or a flat stand or board and secure it reliably. Use M8 screws for installation and fix at three points. If any vibration is expected, do not install the equipment directly but only through a rubber isolator, etc. -
Page 8: How To Operate The Handle (Operation And P.d.i.)
(4) After completing grease feeding, push the handle until it touches the tank in order to reduce pressure. In the case of EGH-2C, the handle does not tilt to the extent it touches the tank. If pushed toward the tank, it stops moving forward. -
Page 9: Pump Operation
4. Pump Operation During operation, if the handle touches the handle stop, do not push in any more, but pull it. Figure 1 Handle stop The piston and the grand nut touch Detailed drawing each other (1) Disengage the handle with the handle stop (as shown in Figure 1). - Page 10 Take off closure plug(s) at the end and operate pump and bleed air in the tubing. Foreign particle(s) at the Ball seating Contact LUBE section of relief valve. Pump discharge pressure is low due to relief Contact LUBE valve’s wrong pressure setting.
- Page 11 Trouble Cause Measures to take Pressure in tubing’s does Clogged termination fitting(s) and/or Replace termination fitting. not decrease properly. Valve(s) Disassemble valve, inspect and replace them, if necessary. Crashed tubing. Replace the tubing. Grease gets too hard doe to low ambient Check NLGI# and ambient temperature.
