- Page 1 L-0356E Motor driven gear pump ACM-Ⅱ INSTRUCTION MANUAL ・ For your safety, read and understand this manual thoroughly before handling the pump. ・ Keep this manual at a designated place for easy access at all times. LUBE CORPORATION...
-
Page 2: Introduction
Introduction ■System application The ACM-Ⅱ continuous delivery motor driven gear pump delivers a relatively small amount of oil for lubrication from the distributor to the lubrication points. Do not use this system for any other purposes. ■Marks used in manual In this manual, safety precautions are provided using the marks below in order to prevent accidents which might cause injuries to human bodies. - Page 3 ■Questions/Contacts If any question or doubt arises concerning the contents of this manual, contact following: ■ Japan LUBE Corporation Head Office 3-30-16(Horizon 1), Nishi Waseda, Shinjuku-ku, Tokyo, 169-0051 Japan TEL:81-3-3204-8431 FAX:81-3-3204-8520 ■ China LUBE LUBRICATING SYSTEM(SHANG HAI)CO.,LTD C, 3F, 88 Taigu Road, Waigaoqiao Free Trade Zone,...
- Page 4 Table of contents Introduction ....................1 Table of contents ....................3 1. Safety precautions ..................4 1-1 Basic safety precautions..............4 1-2 Labels....................4 1-2-1 Type of labels................5 1-2-2 Location of labels ................6 2. Specification and outline.................7 2-1 Specifications ..................7 2-2 Name of each component..............7 3.
-
Page 5: Safety Precautions
LUBE. Labels The following labels are affixed on the pump. If any label gets damaged or becomes illegible, contact LUBE immediately. A new one will be supplied at your own cost. ・ Strictly observe the instructions on the labels ＣＡＵＴＩＯＮ... -
Page 6: Type Of Labels
1-2-1 Types of labels ① Pump label ＮＯ ＲＥＶＥＲＳＥ ＲＯＴＡＴＩＯＮ ＮＯ ＲＥＶＥＲＳＥ ＲＯＴＡＴＩＯＮ ＤＩＲＥＣＴＩＯＮ ＯＦ ＲＯＴＡＴＩＯＮ ＤＩＲＥＣＴＩＯＮ ＯＦ ＲＯＴＡＴＩＯＮ ＶＯＬＴＡＧＥ １００Ｖ ＶＯＬＴＡＧＥ ３φ ２００Ｖ ３φ ２２０Ｖ ３φ ２３０Ｖ ＦＲＥＱＵＥＮＣＹ ５０Ｈｚ ６０Ｈｚ ＦＲＥＱＵＥＮＣＹ ５０Ｈｚ ６０Ｈｚ ６０Ｈｚ ６０Ｈｚ ＡＭＰＥＲＥ ０．５１Ａ ０．５２Ａ ＡＭＰＥＲＥ ０．２３Ａ ０．２１Ａ ０．２１Ａ ０．２２Ａ ＲＡＴＥＤ ＯＵＴＰＵＴ ２５Ｗ ＲＡＴＥＤ ＯＵＴＰＵＴ ２５Ｗ Ｉｎｓ．Ｃｌａｓｓ Ｂ Ｉｎｓ．Ｃｌａｓｓ Ｂ ＣＯＲＰＯＲＡＴＩＯＮ ＣＯＲＰＯＲＡＴＩＯＮ ＭＡＤＥ ＩＮ ＪＡＰＡＮ ＭＡＤＥ ＩＮ ＪＡＰＡＮ 100V 200V ②Terminal connection 100V 200V ③... -
Page 7: Location Of Labels
1-2-2 Location of labels ① ②Inside ③Outside... -
Page 8: Specification And Outline
2. Specifications and outline 2-1 Specification Item Specification Code No. 102484 102486 AC100 V,φ1,4P AC200 V,φ3,4P Power supply AC100 V,φ1,4P AC200 V,φ3,4P Rated voltage Frequency 50/60 Hz 50/60 Hz Rated amperage 0.51/0.52A 0.23/0.21A Motor Rated output Ins. Class Direction of rotation Counter-clockwise from motor upper side 8μF Condenser... -
Page 9: Installation
Insufficient mounting of the pump could fall itself and cause injury. Mount and fix the pump firmly using four (4) M6 bolts. LUBE recommends anti-vibration rubber to be applied when the pump is exposed to vibration. Be sure to allow necessary space around the... -
Page 10: Wiring
3-3 Wiring Only qualified personnel electrical work can ＷＡＲＮＩＮＧ connect wiring. Rotatory direction of a motor is only constant direction. If the motor is reversely rotated, it becomes an unexpected accident. Please wiring refer to terminal connection. Detailed figure of the terminal box Terminal cover installation screw (With rubber seal and metal washer) Terminal cover... -
Page 11: Tubing Connection
Use a 8μF condenser for 100V AC motor. Ｕ Ｖ Ｗ Ｚ２ Ｕ２ Ｕ１ Ｍ４ Earth Ｓｃｒｅｗ Ｃ ８μＦ Ｒ Ｓ Ｔ ＡＣ１００Ｖ，φ１ Earth ＡＣ２００Ｖ，φ３ Ｉｎｐｕｔ Ｉｎｐｕｔ If the wire to the outside touches the outside of the machine or other objects or if it comes in contact with the hand of the operator, use an insulated wire. -
Page 12: Lubricating Oil And Refilling
4. Lubricating oil and refilling 4-1 Lubricating oil to be used Use industrial lubricating oil in the range from 32 to 1300 mm /s of ISO viscosity. Do not use any lubricating oil other than that which has been recommended. Use lubricating oil of the same grade made by the same manufacturer. -
Page 13: Maintenance
5. Maintenance 5-1 Suction filter Replace or clean filter once a year. Before conducting maintenance on the pump, turn off the power and make sure that the pump is not ＷＡＲＮＩＮＧ operating. Conducting maintenance with the power turned on will increase the risk of the operator getting an electric shock or the fingers being pinched in moving parts of the pump drive unit. -
Page 14: Troubleshooting
No oil discharged from Refer to above measures tubing is not built pump due to any of above causes Foreign particle(s) at the Contact LUBE ball seating section relief valve Pump discharge low Contact LUBE pressure due to relief valve... - Page 15 Measures to take Trouble Cause Oil leaking from pump Tighten them with proper Pressure main discharge port pipe torque or re-pipe them tubing is not built connection parts For proper torque machine refer to “Tightening (Due looseness level for connecting excessive tightness) sections”...
- Page 16 Appendix. Oil contamination Causes and measures ■Causes Causes for contamination can be divided into two categories. ○ Before the completion of installation Foreign particles in the tubing or pump tank. （ Manufacturing defects of the assembly parts or connecting parts and unconformity during construction.） ○...
