- Page 1 L-0403-2E Motorized Intermittent Grease Pump EGM-50TH-10S INSTRUCTION MANUAL ・ For your safety, read and understand this manual thoroughly before handling the pump. ・ Keep this manual at a designated place for easy access at all times. LUBE CORPORATION...
-
Page 2: Introduction
Introduction System Application This Motorized Intermittent Grease Pump Series "EGM-50TH-10S" is designed to lubricate each point on a machine by delivering a relatively small amount of grease through a metering valve. Do not use this system for any other purposes. - Page 3 LUBE Corporation (LUBE Global Center) 4-2-1, Anotsudai, Tsu-shi, Mie-prer, 514-0131 TEL: 059-253-3980 FAX: 059-253-3981 ■ China LUBE LUBRICATING SYSTEM (SHANG HAI) CO., C, 3F, 88 Taigu Road, Waigaoqiao Free Trade Zone, Shanghai TEL: 021-5868-3818 FAX: 021-5868-3880 ■ U.S.A LUBE USA, Inc.
-
Page 4: Table Of Contents
Table of contents Introduction ················································································· 1 Table of contents ··········································································· 3 1.Safety Precautions ······································································ 4 1-1 Basic safety precautions ························································· 4 1-2 Labels················································································· 5 1-2-1 Type of labels ··································································· 5 1-2-2 Location of labels ······························································ 5 2.Specification and Outline ····························································· 7 2-1 Specification ······································································... -
Page 5: Safety Precautions
1-2 Labels The following labels are affixed on the pump. If any label gets damaged or becomes illegible, contact LUBE immediately. A new one will be supplied at your own cost. ＣＡＵＴＩＯＮ • Strictly observe the instructions on the labels... -
Page 6: Type Of Labels
1-2-1 Type of labels (1) Logo (for type 7C) (2) Specification, Serial ＶＯＬＴＡＧＥ ＤＣ２４Ｖ ＲＡＴＥＤ ＣＵＲＲＥＮＴ １．５Ａ ＤＩＳ．ＰＲＥＳＳＵＲＥ １０ＭＰａ ＤＩＳ．ＶＯＬＵＭＥ １０ｍＬ／ｍｉｎ ＭＯＤＥＬ ＥＧＭ－５０ＴＨ－１０Ｓ－７Ｃ－ＬＦＢＤ ＣＯＤＥ Ｎｏ． １０１５００ ＳＥＲＩＡＬ Ｎｏ． ＊＊＊＊＊＊＊＊ (3) "Do not step on" label (4) Wiring (Power supply) (5) Signal line (for type FB) (6) Signal line (for type L) (7) Signal line (for type LFB) (8) Arrow label ＣＬＯＳＥ... - Page 7 (10) Caution label (for types 2C, (9) Refill nipple label 4C, and 7C) 補給用ニップル ＲＥＦＩＬＬ ＮＩＰＰＬＥ (11) Caution label (for type 3P) (12) Caution label (for type 8P)
-
Page 8: Location Of Labels
1-2-2 Location of labels • EGM-50TH-10S-2C-D (10) • EGM-50TH-10S-4C-D (10) - Page 9 • EGM-50TH-10S-7C-D, EGM-50TH-10S-7C-LD EGM-50TH-10S-7C-LFBD (10) ⑧ (6) (LD) (7) (LFBD) • EGM-50TH-10S-3P-D Ｈ (11) Ｌ 補給用ニップル ＲＥＦＩＬＬ ＮＩＰＰＬＥ...
- Page 10 • EGM-50TH-10S-8P-D Ｈ (12) Ｌ 補給用ニップル ＲＥＦＩＬＬ ＮＩＰＰＬＥ...
-
Page 11: Specification And Outline
2. Specification and Outline 2-1 Specification Item Specification Rated voltage 24 VDC±10% Starting current 3.0 A Rated current 1.5 A (at 25°C) Motor lock current 4.4 A Discharge amount 10 mL/min Discharge pressure 10 MPa Dedicated 200 mL cartridge Pump Dedicated 400 mL cartridge Cartridge and tank Dedicated 700 mL cartridge... -
Page 12: Name Of Each Component
2-2 Name of each component • EGM-50TH-10S-2C-D １７３ １０４ １０ Cartridge cover ４３ Caution label Air bleeding valve (Mounting ２－φ９ hole) Pump flange Pumping unit DIN connector １２．５ (24 VDC input) with LED Relief unit Discharge port (Rc1/8) • EGM-50TH-10S-4C-D １７３... - Page 13 • EGM-50TH-10S-7C-D, EGM-50TH-10S-7C-LD EGM-50TH-10S-7C-LFBD Manual switch Caution label １７９ Cartridge cover １０４ １６ Logo label Air bleeding valve (Mounting hole) ２－φ９ Pump flange Pumping unit １２．５ Relief unit DIN connector (24 VDC input) with LED Discharge port (Rc1/8) DIN connector (signal output) •...
- Page 14 • EGM-50TH-10S-8P-D １７５ １０４ １２ ４３ Tank 8P Caution label Ｈ Air bleeding valve （８．５） (Mounting hole) ２－φ９ Ｌ Pump flange 補給用ニップル ＲＥＦＩＬＬ ＮＩＰＰＬＥ Refill nipple Pumping unit １２．５ Relief unit DIN connector (24 VDC input) with LED Discharge port (Rc1/8)
-
Page 15: Repair Parts
2-3 Repair parts 1. Repair parts set (539461) ■ Pumping unit (φ3.5) For the replacement procedure, refer to "6-2 Replacement of repair parts." G3/4 ■ Relief unit For the replacement procedure, refer to "6-2 Replacement of repair parts." 1 Punch Mark M14×1 ■... -
Page 16: Installation
Mount and fix the pump firmly using four (4) M8 bolts through φ9 holes. LUBE recommends anti-vibration rubber to be applied when the pump is exposed to vibration. Be sure to allow necessary space as marked in the chart below for operation and maintenance around the pump. - Page 17 ■ Pump weight and necessary space Ａ Ｂ Ｂ Pump Model Weight (kg) Necessary space (mm) EGM-50TH-10S-2C-D A:150, B:200 EGM-50TH-10S-4C-D A:350, B:200 EGM-50TH-10S-7C-D A:250, B:200 EGM-50TH-10S-7C-LD EGM-50TH-10S-7C-LFBD EGM-50TH-10S-3P-D A:250, B:200 EGM-50TH-10S-8P-D A:300, B:200 The weight of grease is excluded...
-
Page 18: Wiring
If an external lead wire from the 24-VDC power supply is likely to come in contact with your hand, machine exterior or any other surrounding object, use an insulated wire of less than 30 m. EGM-50TH-10S DIN connector Signal output 24 VDC input (with LED) Used wire outer diameter: φ4.5 to 6 mm... -
Page 19: Din Connector Wiring Diagram
3-3-1 DIN connector wiring diagram Wiring diagram EGM-50TH-10S-2C-D, EGM-50TH-10S-4C-D, EGM-50TH-10S-7C-D, • EGM-50TH-10S-3P-D, EGM-50TH-10S-8P-D, ２４ＶＤＣ（＋） １ ２ ０Ｖ（－） EGM-50TH-10S-7C-LD • ２４ＶＤＣ（＋） １ ＣＯＭ １ ２ ２ ０Ｖ（－） Grease level switch グリースレベルスイッチ EGM-50TH-10S-7C-LFBD • Manual switch ２４ＶＤＣ（＋） 手動スイッチ １ １ ＣＯＭ ２... -
Page 20: Din Connector Connection Procedure
3-3-2 DIN connector connection procedure Step 1: Remove the DIN connector from the pump body. Step 2: Remove the screw from the DIN connector, and then remove the terminal with a flat-head screwdriver. Remove the screw. Insert a flat-head screwdriver in the point marked by "▲,"... - Page 21 DIN connector (24 VDC input) DIN connector (Signal input) 1: Manual switch 1: 24 VDC (+) 2: Grease level switch 2: 0 V(-) 3: COM 3: Earth ( ) Use the following wire for the DIN connector. Wire outer diameter: φ4.5 to 6 mm (Lead sectional area: 0.75 mm max) When carrying out wiring, check for detachment.
-
Page 22: Tubing
Step 7: Check that the gasket is in the pump side, place the DIN connector, and then tighten the screw. Be sure to insert the gasket in the direction shown in the photograph above. Inserting the gasket in the wrong direction prevents sealing. 3-4 Tubing connection Connect tubing to the machine to the discharge port (Rc1/8). -
Page 23: Setting Of Timer On Machine
4. Setting of Timer on Machine Install timer(s) on the machine and set the discharge time and interval cycle as defined below. If these instructions are not followed, the pump will not operate. (1) Power supply from the machine controller for the pump "ON" (2) Discharge timer "ON."... -
Page 24: Refilling Grease
5. Refilling Grease 5-1 Grease refilling method Pump Model Grease refilling method EGM-50TH-10S-2C-D Dedicated 200 mL cartridge EGM-50TH-10S-4C-D Dedicated 400 mL cartridge EGM-50TH-10S-7C-D Dedicated 700 mL cartridge EGM-50TH-10S-7C-LD EGM-50TH-10S-7C-LFBD EGM-50TH-10S-3P-D 260 mL tank EGM-50TH-10S-8P-D 800 mL tank 5-2 Replacement of grease cartridge... - Page 25 1) Turn the cover CCW with hands remove it from the pump. 2) Turn the empty cartridge CCW and remove it. 3) Mount a new cartridge. Discharge a small amount of grease from the cartridge first, and mount the cartridge by turning it CW. During replacement, be careful no air and/or foreign particle is introduced.
-
Page 26: Grease Replenishment Method (For The Tank Type Only)
5-3 Grease replenishment method (for tank type only) When the follow plate inside the tank comes down to the L line, be sure to replenish with new grease in the tank. Use a grease gun to fill grease through the refill nipple to the level just under the H line. -
Page 27: Maintenance
6. Maintenance 6-1 Bleeding air Make sure to bleed air when air is introduced into the pump. Air and grease often splash out from air bleeding ＷＡＲＮＩＮＧ valve. Wear safety glasses during air bleeding. 1) Loose the air bleeding valve (roughly one turn CCW) with a spanner, etc. -
Page 28: Replacement Of Repair Parts
6-2 Replacement of repair parts Replace the pumping unit and the relief unit at the same time. 6-2-1 Replacement of pumping unit 1) Put a special tool on the 12 square nut of the pumping unit and turn it counter clockwise to loosen and remove the pumping unit from the pump. -
Page 29: Replacement Of Relief Unit
6-2-2 Replacement of relief unit 1) Insert a thin plate between the cap and pump to remove the cap. 2) Remove the relief assembly with the special tool. Special tool The special tool can only fit in the outer groove. Never insert the special tool into the inner groove to rotate it, because doing so changes the set pressure. -
Page 30: Replacement Of Filter
6-2-3 Replacement of filter (1) Filter for 7C-D (531403) Replace the filter once in about two years or at the time of replacing around ten cartridge containers; we recommend the more frequent one. 1) Wipe out grease attached around the filter, and then hold the filter between two fingers to remove it by turning it to the left or the right. - Page 31 4) Place the removed gasket around the filter circumference in place. Remove the cap of a new cartridge, and then mount the cartridge by turning it clockwise. Discharge a small amount of grease from the cartridge before mounting it. Refer to "5-2 Replacement of grease cartridge."...
- Page 32 2) Push the filter in with a finger cushion until it reaches the bottom. 3) After installing the filter, check that the level switch moves up and down. When the filter is replaced, some air enters into the pump. Be sure to bleed air.
-
Page 33: Troubleshooting
6-3 Troubleshooting When troubles occur, take the measures as defined in the chart below. Trouble Cause Measures to take No grease Little grease left in the tank Replenish with grease or the cartridge discharged from of the same brand and pump grade as the grease currently used, or... - Page 34 Trouble Cause Measures to take Pressure in main No grease discharged Refer to above measures tubing is not built from pump due to any of above causes Air in the tubing Take off closure plug(s) at the end and operate pump and bleed air in tubing Grease leaking from Tighten them with proper...
- Page 35 Tightening level for connecting sections Tightening level Reference torque (N·m) OD 4 mm nylon pipe Turn compression bushing with (Valve discharge port) hands until it stops and then tighten it 2/3 turn with a spanner, etc. OD 6 mm nylon pipe Turn compression bushing with hands until it stops and then tighten it 2/3 turn with a...
-
Page 36: Appendix. Grease Contamination: Causes And Measures
Appendix. Grease contamination: Causes and measures ■Causes Causes for contamination can be divided into two categories. ○Before the completion of installation Foreign particles in the tubing or pump tank. (Manufacturing defects assembly parts connecting parts and unconformity during construction.) ○During operation Foreign particles from outside or generated inside of the system.
