Innova-Sonic

1 Operation of Keyboard

0 ~
9 are the menu codes to input information
required for the flow measurement exercise.
You can use
to delete or move back to the
previous data.
/ + ~
/ - are to toggle up and down the
menu.
After all data is selected, press ENT to confirm.
MENU
is used to select a menu using two-digit
numbers for each menu. For example, to enter pipe
MENU
outside diameter, select
code of the outer pipe diameter).

2 Transducer Connection

18 Ground
(11)GND--PE
19
(12)L-- AC
Conductor
20
(13)N --AC
Shield Layer
Note The upstream transducer cable is coded red and the downstream is blue.
Figure 2-1 Connection of the flow meter's transducers

3 Measurement Site Selection

Figure2-2 Installation at the 3 o'clock and 9 o'clock positions
®
Model 205 Quick Start Instructions
(Figure1-1)
1
1 to enter into the window ( MENU11 is the address
Figure2-1
-
DN
screen wire
- (DN) red wire-core
23
- (DN) black wire-core
Figure2-2
Figure1-1 Keyboard
21 Ground
-
UP
screen wire
22
Conductor
- (UP) red wire-core
Shield Layer
- (UP) black wire-core
