To clear all nonvolatile memory, press and hold both the
inside the wiring cabinet or power cycling the console.
Language/Idioma
This is a menu that allows the operator to select either the English or Spanish language for
displaying the text-based menu system. The default is English.
This menu is also presented to the user when the C-100-R control console is powered up for the
very first time.
Info/About
This screen simply displays company, product and firmware version information. Knowing the
firmware version may be needed when working with BinMaster's service department.
information is also displayed momentarily when powering up.

4.3 Messaging System

The Model C-100-R has a messaging system that, if certain conditions are met, will display an important
message to the operator. This message may remain visible until the conditions that caused it are corrected
or until the user presses the
"One or more enabled expansion consoles are offline."
This message will be displayed if C-50 setup is enabled and one or more previously detected C-50
expansion consoles are not responding to communication requests. The operator should verify all
Expansion network wiring and that all C-50s on the network are powered.
"One or more assigned expansion outputs are disconnected."
This message will be displayed if C-50 setup is enabled and one or more 4-20mA outputs, which
are assigned to a sensor, are disconnected. The operator should verify that all assigned 4-20mA
outputs on all C-50s expansion consoles are properly connected to their appropriate PLC input or
load.
Status LEDs on the C-50 expansion console should further assist in identifying the
disconnected output. For additional information, refer to the Model C-50 Operators Manual.
925-0389 rev A
key.
24
and
keys while either pressing S1
This
