Bin Master C-100-R Operator's Manual page 21

Circular
Body Height
Body Radius
No
Hopper Present
Hopper Height
Outlet Radius
C-50 Setup
This is a menu for automatic setup of Model C-50's connected to the expansion port (EX-485). The
operator can choose between Enabled and Disabled. The operator must use Add/Remove or Auto
Add/Remove prior to making this selection. The default setting is Disabled.
After the user selects Enabled, the C-100-R console will automatically assign available I/O's to
enabled sensors and then enter the I/O Assignment menu for the user to review and/or reassign if
necessary.
925-0389 rev A
Select Vessel(s)
to Edit
Vessel Shape
Rectangular
Hopper Present
Yes
Hopper Height
Outlet Width 1
Outlet Width 2
Sensor
Offset
Product
Density
Body Height
Body Width 1
Body Width 2
No
Yes
21
