Appendix A - Technical Specifications
Appendix A
mDynamo with Outdoor Bezel Technical Specifications
Identification Cards and Financial Transaction Cards (ISO 7810, ISO 7811, ISO 7812, ISO 7813)
Identification Cards Integrated Circuits with Contacts (ISO/IEC 7816-1, 2, 3, & 4)
EMV ICC Specifications for Payment Systems Version 4.3, L1 Contact and L2 Contact
Encryption: TDEA (3DES)-CBC using DUKPT
FCC Title 47 Part 15 Class B
CE Level B EMC
CE Safety
UR/CUR UL Recognized
MasterCard TQM
California Proposition 65 (California)
IPC-A-610 Class II Assembly
EU Directive Waste Electrical and Electronic Equipment (WEEE)
EU Directive Restriction of Hazardous Substances (RoHS)
Universal Serial Bus Specifications 1.1, 2.0
Dimensions (L x W x H):
Weight
Supported Mounting Options:
Magnetic Stripe Reader:
EMV Contact Reader:
Status Indicators:
Display Type:
Display Size (viewable area):
Display Resolution:
Keypad:
Certifications:
Tamper Protection:
mDynamo with Outdoor Bezel| IP34 Rated EMV Chip Card Module | Installation and Operation Manual
Technical Specifications
Reference Standards and Certifications
Physical Characteristics
3.9 in. W x 0.9 in. H x 3.4 in. T
(99.1 mm x 23.4 mm 86.4 mm)
Reader only – 1.8oz (52.0g). Reader with USB cable 3.4oz (95.5g)
Note: USB cable will always be included and attached. This cable
cannot be removed unless you remove the top cover and cover
mounting screws.
Solution-specific enclosure with card slot, screws, and inserts
Card Read Characteristics
NO
EMVCo L1 and L2 Contact Reader
User Interface Characteristics
General Status LED (Red/Green)
Not Applicable
Not Applicable
Not Applicable
Not Applicable
Security Characteristics
Not Applicable
Not Applicable
Page 21 of 23 (D998200546-10)
