- Page 1 Installation, Operation and Maintenance Instruction en Model: Pa Translation of the Original Operation Manual Keep for further use ! Pay attention to this operating instruction before the delivery, installation, start-up a.s.o.! VOGEL SERIES...
- Page 2 Xylem Service Austria GmbH Ernst Vogel-Straße 2 A-2000 Stockerau Telefon: +43 (0) 2266 / 604 Fax: +43 (0) 2266 / 65311 E-Mail: info.austria@xyleminc.com Internet: www.xylemaustria.com...
-
Page 3: Table Of Contents
Operating instructions Table of Contents Data Sheet 1. General .................... page 3 1.1 Foreword .2 Guarantee 1.3 Safety regulations 1.4 Safety instructions Dangers of not following safety instructions Safety instructions for the operator Speed, pressure, temperature Permitted forces on flanges NPSH Sealing, flushing, cooling Minimum flows... - Page 4 Operating instructions Mechanical seals Oil changing Grease lubrication Couplings Cleaning the pump 6. Longer periods of non-operation ..........page 17 6.1 Drained pumps 6.2 Filled pumps 7. Faults - Causes and Solutions ............page 18 page 21 8. Repairs ..................... page 22 9.
-
Page 5: General
Operating instructions 1. General 1.1 Foreword This product complies with the safety requirements of EC Machinery Directive 2006/42/EC. The staff employed on installation, operation, inspection and maintenance must be able to prove that they know about the relevant accident prevention regulations and that they are suitably qualified for this work. -
Page 6: Safety Regulations
Operating instructions In order for the guarantee to apply, it is essential that the pump or pump unit is used in accordance with the operating conditions given on the type plate, confirmation of order and in the Data Sheet. This applies particularly for the endurance of the materials and smooth running of the pump and shaft sealing. -
Page 7: Safety Instructions For The Operator
Operating instructions Safety instructions for the operator • Depending on the operating conditions, wear and tear, corrosion or age will limit the working life of the pump/pump unit, and its specified characteristics. The operator must ensure that regular inspection and maintenance are carried out so that all parts are replaced in good time which would otherwise endanger the safe operation of the system. -
Page 8: Speed, Pressure, Temperature
Operating instructions Speed, Pressure, Temperature Suitable safety measures must be taken at the plant to ensure that the speed, pressure and temperature of the pump and the shaft sealing do not exceed the limit values given in the Data Sheet. The given admission pressures (system pressures) must also be sufficiently high. In addition, the pump must be protected against pressure surges such as can be caused by switching off the plant quickly (e.g. -
Page 9: Back Flow
Operating instructions Back flow In systems where pumps are operating in closed circuits under pressure (gas cushions, steam pressure), the pressure of the gas cushion must not be reduced via the pump, since the back flow speed may be much higher than the operating speed, which would destroy the unit. 2. -
Page 10: Bearing Sizes And Oil Quantities
Operating instructions Bearing sizes and oil quantities Grease lubrication Oil lubrication Pump size Bearing type Bearing type Qty.of oil intake discharge intake discharge in litres 33 Pa 6305-2Z-C3 6305-2Z-C3 43 Pa *) 6306-2Z-C3 6306-2Z-C3 6306-C3 6306-C3 ca. 0.12 51 Pa *) 6307-2Z-C3 2x 7307 BG 6307-C3... -
Page 11: Storage
Operating instructions Please note Please Sling ropes must not be fixed to ends of shafts or the ring loops of the motor. note Do not stand underneath suspended loads; take note of the general regulations on prevention of accidents. The pump/pump unit must be secured against tipping over and slipping until it has been fixed in its final location. -
Page 12: Installation And Alignment Of Coupling
Operating instructions To prevent vibrations being transmitted to adjoining components, the foundation should be laid on a suitable insulating base (panels providing insulation against structure-borne sound or vibration panels). Please The size of these insulating panels will vary, depending on circumstances, and note should therefore be determined by an experienced specialist.. -
Page 13: Permitted Displacement For Flexible Couplings
Operating instructions Adjustment using dial gauge: Adjustment using precision ruler: Normal coupling Expansion coupling • Check/measure the alignment at several points using a precision ruler and sensor. If a dial gauge is used, one coupling side is to be turned. •... -
Page 14: Connecting The Pipes To The Pump
Operating instructions Design NAN.. and NHN.. • Align the coupling again after pump has reached normal operating temperature and system pressure (if applicable), check once again and if necessary adjust. Read Point 4.5 „Starting up“ first. • It must be possible to turn the unit by hand smoothly and easily. •... -
Page 15: Auxiliary Pipes
Operating instructions • Before connecting up to pump: remove protective coverings from suction and discharge branches. • To protect the shaft sealing (especially mechanical seals) against foreign bodies, it is recommended that a sieve, 800 micron, is installed in the suction/intake pipe when the motor is being started up. -
Page 16: Starting Up
Operating instructions 4.5 Starting up The plant may only be started up by people who are familiar with the local safety regulations and with these Operating Instructions (especially with the safety regulations and safety instructions given here). In order to be able to observe and monitor the shaft sealing, no protective covering is provided in this area. -
Page 17: Operation And Monitoring
Operating instructions 4.6 Operation and Monitoring Be particularly careful not to touch hot machine parts and when working in the unprotected shaft seal area. Remember that automatically controlled systems may switch themselves on suddenly at any time. Suitable warning signs should be affixed. Please Regular monitoring and maintenance will extend the life of your pump or pump note... -
Page 18: Shutting Down
Operating instructions 4.7 Shutting down • Close slide valve in discharge pipe. This is not necessary if there is a spring-loaded non-return valve. • Switch of motor (make sure it runs down quietly). • Close slide valve on suction side. •... -
Page 19: Mechanical Seals
Operating instructions Mechanical seals If the liquid being handled drips out at the mechanical seal, it is damaged and must be replaced. Before opening the pump, it is essential that you note Point 1.4 „Safety Instructions“, Point 4.8 „Dismantling“ and Point 8 „Repairs“. Oil changing (only with oil-lubricated pumps) •... -
Page 20: Drained Pumps
Operating instructions 6.1 Drained pumps • Turn by hand at least 1x week (do not switch on because of dry running). • If necessary, unblock by tapping gently on the shaft in axial direction. • Replace bearing oil after 2 years or grease after 4 years. 6.2 Filled pumps •... - Page 21 Operating instructions Speed too high • reduce speed • compare speed of motor with specified pump speed (rating plate) • when adjusting speed (frequency transformer) check reference value setting Speed too low • increase speed (check available motor power) • compare speed of motor with specified pump speed (rating plate) •...
- Page 22 Operating instructions 14. Inner components suffering from wear • replace worn parts 15. Density and/or viscosity of liquid handled is too high • seek assistance 16. Stuffing box not straight • tighten evenly 17. Stuffing box too tight • loosen 18.
-
Page 23: Repairs
Operating instructions 27. Electricity supply not right • check voltage of all phases (2-phase running) • check cable connections • check fuses 28. Sealing insufficient • tighten screws • replace sealing 29. Bearing damaged • replace • check lubricant and bearing space for pollutants (rinse oil area) 30. -
Page 24: Spare Parts, Spare Pumps
Operating instructions 9. Spare Parts, Spare Pumps 9.1 Spare parts Spare parts should be selected to last for two-years continuous operation. If no other guidelines are applicable, we recommend that you stock the number of parts listed below (in accordance with VDMA 24296). Number of pumps (incl. -
Page 25: Plant Manager List
Operating instructions 10. Plant Manager List Each plant manager should sign below to confirm that he has received, read and understood these Operating Instructions. He undertakes to follow the instructions conscientiously. If these instructions are not followed, the manufacturer's guarantee and liability shall cease to apply. Name: Date: Signature:... -
Page 26: Log Book
Operating instructions 11. Log Book Each plant operator shall duly enter all maintenance and service work that has been carried out, and shall see that the person responsible confirms such work by signing below. maintenance work: Date: Signature Confirmed by Plant operator person responsible: Pa 100/3-en...
