Montage- und Bedienungsanleitung
D
für Gleichstrompumpen
Baureihe DDC
GB
Installation and instruction manual
for DDC pumps

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lowara DDC and is the answer not in the manual?

Questions and answers

Summary of Contents for Xylem Lowara DDC

  • Page 1 Montage- und Bedienungsanleitung für Gleichstrompumpen Baureihe DDC Installation and instruction manual for DDC pumps...
  • Page 2: Einbau

    Montage- und Bedienungsanleitung DDC Anwendung Die Pumpen der Baureihe DDC werden zur Zirkulation von Kühlwasser in Computerkühlsystemen eingesetzt. Ausführung Bei den DDC Pumpen handelt es sich um Kugelmotorpumpen, die sich durch eine besondere Laufruhe und lange Lebensdauer auszeichnen. Der Motor wird elektronisch kommutiert, weshalb die Pumpen einen hohen Wirkungsgrad aufweisen.
  • Page 3 Montage- und Bedienungsanleitung DDC Einbau Der Einbau der Pumpe erfolgt in den Kühlkreislauf vor dem luftge- kühlten Wärmetauscher. Dies ist deshalb sinnvoll damit die Abwär- me der Pumpe nicht vor, sondern nach dem zu kühlenden Prozessor dem Medium zugeführt wird. Vor der Pumpe muss ein Ausdeh- nungsgefäß...
  • Page 4 Montage- und Bedienungsanleitung DDC Elektrischer Anschluss Die DDC Pumpe braucht zum Betrieb 12V Gleichstrom. Beim Anschluß ist auf die richtige Polung zu achten (gelbe Litze Pluspol, schwarze Litze Minuspol) Die DDC-1P und DDC-1T sind bereits mit einem Stecker für die Strom- versorgung ausgerüstet.
  • Page 5 Montage- und Bedienungsanleitung DDC Wartung Die Pumpe bedarf keiner Wartung. Es gibt keine Verschleißteile, die vom Benutzer gewechselt werden können. Wichtig für einen sicheren Betrieb ist, dass die Pumpe immer genug Wasser hat, da ein Betrieb mit Luft dem Pumpenlager schadet und die Fördermenge sinken lässt.
  • Page 6 Montage- und Bedienungsanleitung DDC Nach dem Wiedereinsetzen des Rotors in den Stator muss überprüft werden ob sich der Rotor dreht, wenn die Pumpe eingeschaltet wird. Achtung: um einen Kurzschluss zu vermeiden, muss die Pumpe zum Funktionstest vollständig trocken sein! Wenn der Rotor sich dreht, muss als Nächstes der Dichtring aus dem Stator genommen und sorgfältig gereinigt werden.
  • Page 7 Montage- und Bedienungsanleitung DDC Kennlinie Fördermenge (l/h) www.lowara.de...
  • Page 8 Montage- und Bedienungsanleitung DDC Mehr Informationen auch auf www.lowara.de www.lowara.de...
  • Page 9 Montage- und Bedienungsanleitung DDC Notizen www.lowara.de...
  • Page 10: Installation

    Installation and instruction manual DDC pumps Application The Laing DDC series pumps are primarily used for the circulation of cooling liquid in liquid cooled computers. Construction - The Laing DDC pumps are spherical motor pumps, which provide very quiet operation and long life. - The motor is electronically commutated and the pumps consequently have a high efficiency.
  • Page 11: Installation Position

    Installation and instruction manual DDC pumps The pump must be mounted below the level of an open expansion tank. Ideally the pump should be placed at the lowest point of the system. The pump is mounted on a flat surface. Avoid bending the pump by over tightening of the screws.
  • Page 12: Electrical Connection

    Installation and instruction manual DDC pumps Electrical connection − The DDC pump runs on 12 Volt DC. If you install a pump without connector, make sure to observe the correct polarity. − DDC-1P and DDC-1T are equipped with a connector for the power supply.
  • Page 13: Troubleshooting

    Installation and instruction manual DDC pumps Troubleshooting Pump − If the pump does not operate, housing please check first whether the power supply is operating correctly. Rotor − If this does not resolve the problem please unplug the Seal ring pump several times.
  • Page 14 Installation and instruction manual DDC pumps Dimensional drawing (in mm) Pump curve Flow rate [l/h] www.lowara.com...
  • Page 15 Installation and instruction manual DDC pumps For more information visit www.lowara.com Notes www.lowara.com...
  • Page 16 36075 Italy Tel: +39 0444 707 111 Fax: +39 0444 492 166 Kontakt in Deutschland: neue Anschrift ab 8. August 2014 Xylem Water Solutions Deutschland GmbH Geschäftsbereich Gebäudetechnik (ehemals Laing GmbH) Schultheiß-Köhle-Str. 8 DE-71636 Ludwigsburg Tel.: 07141 4987-0 Fax: 07141 4987-299 Email: info-shk@xyleminc.com...
