Hoshizaki KM-150BAF Instruction Manual

Crescent cuber with storage bin
Hide thumbs Also See for KM-150BAF:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Reliability is a
beautiful thing
TM
INSTRUCTION MANUAL
CRESCENT CUBER
WITH STORAGE BIN
KM-150BAF
KM-150BWF
ISSUED:
JULY 3, 1998
™
REVISED: DEC. 11, 2003

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki KM-150BAF

Summary of Contents for Hoshizaki KM-150BAF

  • Page 1 Reliability is a beautiful thing CRESCENT CUBER WITH STORAGE BIN INSTRUCTION MANUAL KM-150BAF KM-150BWF ISSUED: ™ REVISED: DEC. 11, 2003 JULY 3, 1998...
  • Page 2 HOSHIZAKI provides this manual primarily to assist qualified service technicians in the installation, maintenance and service of the icemaker. Should the reader have any questions or concerns which have not been satisfactorily ad- dressed, please call or write to the HOSHIZAKI Technical Support Department for assistance.

  • Page 3: Table Of Contents

    • Keep this manual with the icemaker for later reference. I. SPECIFICATIONS... 4 1. NAMEPLATE RATING ... 4 [a] KM-150BAF (Air-cooled) ... 4 [b] KM-150BWF (Water-cooled) ... 5 2. DIMENSIONS/CONNECTIONS ... 6 [a] KM-150BAF ... 6 [b] KM-150BWF ... 7 II.

  • Page 4: Specifications

    I. SPECIFICATIONS I. SPECIFICATIONS 1. NAMEPLATE RATING 1. NAMEPLATE RATING 1. NAMEPLATE RATING 1. NAMEPLATE RATING 1. NAMEPLATE RATING [a] KM-150BAF (Air-cooled) [a] KM-150BAF (Air-cooled) [a] KM-150BAF (Air-cooled) [a] KM-150BAF (Air-cooled) [a] KM-150BAF (Air-cooled) MODEL NUMBER MODEL NUMBER MODEL NUMBER...

  • Page 5: [B] Km-150Bwf (Water-Cooled)

    [b] KM-150BWF (Water-cooled) [b] KM-150BWF (Water-cooled) [b] KM-150BWF (Water-cooled) [b] KM-150BWF (Water-cooled) [b] KM-150BWF (Water-cooled) MODEL NUMBER MODEL NUMBER MODEL NUMBER MODEL NUMBER MODEL NUMBER SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER SERIAL NUMBER AC SUPPLY VOLTAGE AC SUPPLY VOLTAGE AC SUPPLY VOLTAGE AC SUPPLY VOLTAGE AC SUPPLY VOLTAGE...

  • Page 6: Dimensions/Connections

    2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS 2. DIMENSIONS/CONNECTIONS [a] KM-150BAF [a] KM-150BAF [a] KM-150BAF [a] KM-150BAF [a] KM-150BAF Units: millimeters (inches)

  • Page 7: [B] Km-150Bwf

    [b] KM-150BWF [b] KM-150BWF [b] KM-150BWF [b] KM-150BWF [b] KM-150BWF Units: millimeters (inches)

  • Page 8: Installation And Operating Instructions

    II. INSTALLATION AND OPERATING INSTRUCTIONS II. INSTALLATION AND OPERATING INSTRUCTIONS II. INSTALLATION AND OPERATING INSTRUCTIONS II. INSTALLATION AND OPERATING INSTRUCTIONS II. INSTALLATION AND OPERATING INSTRUCTIONS 1. CHECKS BEFORE INSTALLATION 1. CHECKS BEFORE INSTALLATION 1. CHECKS BEFORE INSTALLATION 1. CHECKS BEFORE INSTALLATION 1.

  • Page 9: Location

    2. LOCATION 2. LOCATION 2. LOCATION 2. LOCATION 2. LOCATION This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F (7°C) to +100°F (38°C); Normal operat- ing water temperature should be within +45°F (7°C) to +90°F (32°C). Opera- tion of the icemaker, for extended periods, outside of these normal tempera- ture ranges may affect production capacity.

  • Page 10: Water Supply And Drain Connections

    4. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 1 4. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 1 4. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 1 4. WATER SUPPLY AND DRAIN CONNECTIONS - See Fig. 1 4.
  • Page 11 KM-150BAF and KM-150BWF KM-150BAF and KM-150BWF KM-150BAF and KM-150BWF KM-150BAF and KM-150BWF KM-150BAF and KM-150BWF KM-150BWF KM-150BWF KM-150BWF KM-150BWF KM-150BWF Water-cooled Condenser Water-cooled Condenser Water-cooled Condenser Water-cooled Condenser Water-cooled Condenser Connections Connections Connections Connections Connections Fig. 1 Fig. 1 Fig. 1 Fig.

  • Page 12: Final Check List

    5. FINAL CHECK LIST 5. FINAL CHECK LIST 5. FINAL CHECK LIST 5. FINAL CHECK LIST 5. FINAL CHECK LIST 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F (7°C) to +100°F (38°C) and the water temperature within +45°F (7°C) to +90°F (32°C) all year around? 3) Is there at least 6"...

  • Page 13: Start Up

    6. START UP 6. START UP 6. START UP 6. START UP 6. START UP 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the Compressor.

  • Page 14: Preparing The Icemaker For Long Storage

    7. PREPARING THE ICEMAKER FOR LONG STORAGE 7. PREPARING THE ICEMAKER FOR LONG STORAGE 7. PREPARING THE ICEMAKER FOR LONG STORAGE 7. PREPARING THE ICEMAKER FOR LONG STORAGE 7. PREPARING THE ICEMAKER FOR LONG STORAGE When shutting off the icemaker for an extended time, drain out all water from the water line and remove the ice from the Storage Bin.
  • Page 15 4) Close the Potable Water Supply Line Shut-off Valve and open the Potable Water Supply Line Drain Valve. See Fig. 1. 5) Allow the line to drain by gravity. 6) Attach compressed air or carbon dioxide supply to the Potable Water Line Drain Valve. 7) Move the Control Switch to the “ICE”...

  • Page 16: Cleaning And Maintenance Instructions

    [a] CLEANING PROCEDURE [a] CLEANING PROCEDURE [a] CLEANING PROCEDURE 1) Dilute approximately 5 fl. oz. (148 ml.) of recommended cleaner, Hoshizaki “Scale Away” or “Lime-A-Way” (Economics Laboratory, Inc.) with 1 gal. (3.8 l.) of water. 2) Remove the Front Panel.
  • Page 17 18) Remove the Water Tank Brackets and the Thermostat Bracket from the Bin by removing the Thumbscrews. 19) Dilute approximately 5 fl. oz. (148 ml.) of recommended cleaner Hoshizaki “Scale Away” or “Lime-A-Way” (Economics Laboratory, Inc.) with 1 gal. (3.8 l.) of water.

  • Page 18: [B] Sanitizing Procedure

    20) Wash the bin liner, the Thermostat Bracket, the Water Tank Brackets and the Water Tank by using a nylon scouring pad, brushes and the cleaning solution. 22) Rinse them thoroughly with water. [b] SANITIZING PROCEDURE - Following Cleaning Procedure [b] SANITIZING PROCEDURE - Following Cleaning Procedure [b] SANITIZING PROCEDURE - Following Cleaning Procedure [b] SANITIZING PROCEDURE - Following Cleaning Procedure...

  • Page 19: Maintenance

    2. MAINTENANCE 2. MAINTENANCE 2. MAINTENANCE 2. MAINTENANCE 2. MAINTENANCE This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. 1) Exterior Panels To keep the exterior clean, wipe occasionally with a clean and soft cloth. Use a damp cloth containing a neutral cleaner to wipe off oil or dirt build up.
  • Page 20 HOSHIZAKI HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269...
