Hoshizaki KM-61BAH Instruction Manual

Self-contained crescent cuber
Hide thumbs Also See for KM-61BAH:
Table of Contents

Advertisement

Quick Links

See also: Service Manual
Self-Contained Crescent Cuber
Models
KM-61BAH
KM-101BAH
KM-151BAH
KM-151BWH
INSTRUCTION MANUAL
Issued: 6-14-2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM-61BAH and is the answer not in the manual?

Questions and answers

Related Manuals for Hoshizaki KM-61BAH

Summary of Contents for Hoshizaki KM-61BAH

  • Page 1 Self-Contained Crescent Cuber Models KM-61BAH KM-101BAH KM-151BAH KM-151BWH INSTRUCTION MANUAL Issued: 6-14-2013...
  • Page 2 IMPORTANT Only qualifi ed service technicians should install and service the appliance. To obtain the name and phone number of your local Hoshizaki Certifi ed Service Representative, visit www.hoshizaki.com. No installation or service should be undertaken until the technician has thoroughly read this Instruction Manual. Likewise, the owner/manager should not proceed to operate the appliance until the installer has instructed them on its proper operation.

  • Page 3: Table Of Contents

    PAGE Important Safety Information ---------------------------------------------------------------------------3 I. Specifi cations -------------------------------------------------------------------------------------------5 A. Electrical and Refrigerant Data -----------------------------------------------------------------5 B. Dimensions/Connections -------------------------------------------------------------------------6 1. KM-61BAH ----------------------------------------------------------------------------------------6 2. KM-101BAH --------------------------------------------------------------------------------------7 3. KM-151BAH --------------------------------------------------------------------------------------8 4. KM-151BWH -------------------------------------------------------------------------------------9 II. Installation and Operating Instructions --------------------------------------------------------- 10 A. Checks Before Installation --------------------------------------------------------------------- 10 B.

  • Page 4: Important Safety Information

    Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, damage to the appliance, or damage to property. WARNING Indicates a hazardous situation which could result in death or serious injury.
  • Page 5 WARNING, continued • The appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 6: Specifi Cations

    The nameplate provides electrical and refrigerant data. The nameplate is located on the upper part of the left side panel. For certifi cation marks, see the nameplate. We reserve the right to make changes in specifi cations and design without prior notice. Model Number KM-61BAH KM-101BAH KM-151BAH KM-151BWH...

  • Page 7: Dimensions/Connections

    B. Dimensions/Connections 1. KM-61BAH Unit: mm [inches]...

  • Page 8: Km-101Bah

    2. KM-101BAH Unit: mm [inches]...

  • Page 9: Km-151Bah

    3. KM-151BAH Unit: mm [inches]...

  • Page 10: Km-151Bwh

    4. KM-151BWH Unit: mm [inches]...

  • Page 11: Installation And Operating Instructions

    II. Installation and Operating Instructions WARNING • Install in accordance with all applicable national, state, and local codes and regulations. • CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the storage bin.

  • Page 12: How To Remove Panels

    B. How to Remove Panels - See Fig. 1 • Louver: Remove the air fi lter. Lift it up and towards you. Push down snap tabs at the top on both sides by a fl at head screwdriver, pull towards you slightly, and lift off. •...

  • Page 13: Location

    C. Location NOTICE • This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within 45°F to 100°F (7°C to 38°C); Normal operating water temperature should be within 45°F to 90°F (7°C to 32°C). Operation of the icemaker, for extended periods, outside of these normal temperature ranges may affect icemaker performance.

  • Page 14: Electrical Connection

    5) When installing the unit with legs on the bottom, use the Tapped Hole (Leg Mounting) four accessory legs adjustable from 6” (15.2 cm) to 7” (17.8 cm). Screw the legs tightly into the tapped holes in the base (see Fig. 3). Handle the icemaker carefully not to Base damage the exterior.

  • Page 15: Water Supply And Drain Connections

    • External fi lters, strainers, or softeners may be required depending on water quality. Contact your local Hoshizaki Certified Service Representative or local Hoshizaki distributor for recommendations. • A plumbing permit and services of a licensed plumber may be required in some areas.
  • Page 16 • An icemaker water supply line shut-off valve and drain valve must be installed. • Be sure there is suffi cient extra water supply line and drain line for the appliance to be pulled out for service. KM-61BAH, KM-101BAH, KM-151BAH Icemaker Drain Outlet 3/4” FPT Minimum 3/4”...

  • Page 17: Water-Cooled Condenser

    2. Water-Cooled Condenser a) Connection to an Open Drain System Condenser Water Minimum Condenser Condenser Drain Minimum Condenser Supply Inlet Water Supply Line Size Outlet Drain Line Size 1/2" Female Pipe 1/4" Nominal ID Copper 1/2" Female Pipe 1/4" Nominal ID Hard Thread (FPT) Water Tubing or Equivalent Thread (FPT)
  • Page 18 b) Connection to a Closed Loop System Condenser Water Minimum Condenser Condenser Minimum Condenser Supply Inlet Water Supply Line Size Return Outlet Return Line Size 1/2" Female Pipe 1/4" Nominal ID Copper 1/2" Female Pipe 1/4" Nominal ID Copper Thread (FPT) Water Tubing or Equivalent Thread (FPT) Water Tubing or Equivalent...

  • Page 19: Final Checklist

    G. Final Checklist WARNING CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the storage bin. 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 90°F (7°C to 32°C) all year around? 3) Is there at least 2”...

  • Page 20: Startup

    H. Startup WARNING All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. NOTICE • If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the compressor. •...

  • Page 21: Cleaning And Maintenance Instructions

    Make sure that none have fallen into the storage bin. A. Cleaning HOSHIZAKI recommends cleaning this unit at least once a year. More frequent cleaning, however, may be required in some existing water conditions. WARNING •...

  • Page 22: Cleaning Procedure

    1. Cleaning Procedure 1) Dilute 5 fl . oz. (148 ml) of recommended cleaner Hoshizaki “Scale Away” with 1 gallon (3.8 lit.) of water. 2) Remove the air fi lter. Remove all ice from the evaporator and the storage bin.
  • Page 23 Fig. 8 Cube Guide Water Tank Snap * This illustration shows KM-61BAH. T h e f o l l o w i n g n u m b e r o f c u b e guides are provided: KM-61BAH...

  • Page 24: Sanitizing Procedure - Following Cleaning Procedure

    16) Wash the bin control switch, water tank, fl oat switch, cube guide, silicone hose and overflow pipe by using a nylon scouring pad, brushes and the cleaning solution. In addition to the removed parts, also wash the bin liner and bracket (L) (R) with the solution.

  • Page 25: Maintenance

    B. Maintenance This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. WARNING • Only qualifi ed service technicians should service this icemaker. • Move the control switch to the “OFF” position, then unplug the appliance from the electrical outlet before servicing.

  • Page 26: Preparing The Icemaker For Periods Of Non-Use

    C. Preparing the Icemaker for Periods of Non-Use NOTICE • During extended periods of non-use, extended absences, or in sub-freezing temperatures, follow the instructions below to reduce the risk of costly water damage. • To prevent damage to the water pump, do not leave the control switch in the “WASH” position for extended periods of time when the water tank is empty.
  • Page 27 HOSHIZAKI AMERICA, INC. 618 Hwy. 74 S., Peachtree City, GA 30269 USA TEL (770) 487-2331 FAX (770) 487-3360 www.hoshizaki.com L1M006104...

  • Page 28: Disposal

    6) Close the door. 7) Place the air fi lter in its correct position. 8) Close the icemaker water supply line drain valve. 3. On water-cooled model only, remove the water from the water-cooled condenser: 1) Make sure the control switch is in the “OFF” position and the appliance is unplugged from the electrical outlet.

This manual is also suitable for:

Km-101bahKm-151bahKm-151bwh
