M S
ONITOR
The Monitor screens display the signal activity at the LTU/NTU serial data
port, and the 24-hour error counts and other information from the HDSL
Span 1 interface.
Monitor LTU and NTU Interface Screens
The following table lists the information displayed in each field of the
Monitor LTU and Monitor NTU Interface screens.
Information Displayed in Monitor LTU and NTU Interface Screens
Field
Nx64k Port
Data & Clk
Activity
Ctrl Signal
State
Clear 24 Hour
History
UTU-702C and ETU-752C List 1
CREENS
Description
Displays the status of the TT (terminal timing), SD (transmit data),
ST (send timing), RT (receive timing), and RD (receive data) signals
at the Nx64k port at one-second intervals. Asterisks (**) indicate an
active line. Dashes (--) indicate an inactive line. Displayed fields are:
From DTE:
TT SD
Displays the status of the RTS (ready to send), DTR (data terminal
ready), RL, LL, CTS, DSR, RLSD, and TM (test mode) control signals
at the Nx64k port at one-second intervals. ON indicates an active line.
OFF indicates an inactive line. Displayed fields are:
From DTE:
RTS DTR RL LL
Not available from this screen on Nx64k serial data port units. Use
clear history options in console screen History menu.
June 14, 2002
From DCE
ST RT RD
From DCE:
CTS DSR RLSD TM
Viewing Status
19
