Installation
4
Connect the data port cable from the DTE to the data port connector on
the ETU-752C rear panel.
5
Connect the HDSL line cable to the HDSL line connector on the ETU
rear panel. The pinouts for the HDSL line connector are listed in the
following table.
Pin*
4
9
1
6
* No other pins are used.
6
Set the DTE interface (TT clock) for the default HDSL payload rate of
256 kbps (4 time slots).
10
HDSL Line Connector (DB9F) Pinouts
Signal
HDSL_RING_A
HDSL_TIP_A
HDSL_RING_B
HDSL_TIP_B
June 14, 2002
700-702-900-04, Revision 04
Description
HDSL Ring Loop 1
HDSL Tip Loop 1
HDSL Ring Loop 2
HDSL Tip Loop 2
UTU-702C and ETU-752C List 1
