CHIPPER
CH10
OPERATION, MAINTENANCE
AND SPARE PARTS MANUAL
PLEASE READ THE OPERATING AND MAINTENANCE
INSTRUCTIONS BEFORE YOU OPERATE THE MACHINE.
FROM MACHINE: 3620001
TRANSLATION OF THE INSTRUCTION MANUAL
C-EN-170120-ER

Advertisement

Table of Contents
loading

Summary of Contents for Farmi Forest CH10

  • Page 1 CHIPPER CH10 OPERATION, MAINTENANCE AND SPARE PARTS MANUAL PLEASE READ THE OPERATING AND MAINTENANCE INSTRUCTIONS BEFORE YOU OPERATE THE MACHINE. FROM MACHINE: 3620001 TRANSLATION OF THE INSTRUCTION MANUAL C-EN-170120-ER...
  • Page 3: Table Of Contents

    HYDRAULIC MOTOR AND HOSES, ACCESSORY CH10 HYDRAULIC CONTROL, ACCESSORY WARRANTY PRODUCT REGISTRATION FORM When ordering spare parts, please indicate machines type from the machine plate, spare parts order number, description and quantity required. Example. CH10, knife, 43620080, 2 pc CH10...
  • Page 4 Farmi Machine denomination: Farmi wood chipper with attachable Farmi feed hopper Machine type: Wood chipper: CH10 Machine series number: Herewith, we declare that the machine brought into circulation conforms with the pertinent requirements of the Machinery Directive 2006/42/EC and the EMC Directive (directive relating to electromagnetic compatibility) 2004/108/EC.
  • Page 5: Introduction

    Complete the registration form on the last pages of this manual and return it to us within 30 days after the receipt of the product. CUSTOMER FEEDBACK We are happy to receive your opinions and suggestions for improvements by mail or e-mail. All implemented suggestions for improvements will be rewarded. CH10...
  • Page 6: General Safety Instructions

    The top link is to be mounted by • misuse caused by an untrained person’s improper adjusting its length. actions. • alterations made without the manufacturer’s permis- sion. Written authorization must be requested from the manufacturer for any alterations to the machine. ATTENTION CH10...
  • Page 7: Transport

    11. Never exceed the given operating values. 12. All safety and warning signs on and in the machine must be legible and intact. 13. The machine may not be operated by persons who are unwell or under the influence of drugs or alcohol. CH10...
  • Page 8: Maintenance

    11. Most hydraulic oils do not evaporate easily. Risk fac- tors include hot oil, spills and oil mist (pressurized). 12. If oil gets into your eyes, rinse with plenty of water CH10...
  • Page 9 Caps, funnels, sieves and filling holes must also be clean. 18. Never store oil outdoors, as water could condense in it. 19. Always dispose of oil in a suitable container, never into the environment! CH10...
  • Page 10: General Safety Instructions For The Chipper

    12. Do not remove, lock, disable or modify in any other way the stop lever of the feed unit. 13. The feed hopper or the feed unit must not be mounted at a higher or lower position as this would impede the stop lever function. CH10...
  • Page 11: Stickers And Plates

    STICKERS AND PLATES These plates and stickers must be found on the chipper. Replace missing plates or stickers immediately. CH10...
  • Page 12 Before operation, mount the chipper to the 3-point hitch of the tractor. CAUTION! Before maintenance and repair, please turn off the tractor and disconnect the PTO drive shaft. CAUTION! Before detaching the chipper from the tractor, it must be placed on a level surface. CH10...
  • Page 13 4. Wear personal protective equipment. (40142080). 5. Cutting hazard! (40147010) 6. Lifting point sticker (41014270). 7. SPEED sticker (40141160) Recommended speed range. The rated speed must not be exceeded. 8. FARMI Forest sticker 9. Sticker “10” CH10...
  • Page 14: Ch10 - General Description And Intended Use

    UPPER CHAMBER AND INTENDED USE LOWER CHAMBER CUTTING DISK CH10 is a single-disk chipper with two knives used for KNIFE chipping wood with a diameter of up to 100 mm (chip VERTICAL KNIFE size 12 mm). In addition, it is used to clear the embank-...
  • Page 15: Technical Data

    550 mm Disk weight 46 kg Discharge pipe turning to two sides Feeder drop spout Sound pressure level 104,2 dB(A) SFS-EN ISO 4254-1:2014, ISO 11201:2010 (Measurement Uncertainty 2,5 dB) Sound power level 117 dB(A) ISO 3744:2010 (Measurement Uncertainty 5 dB) CH10...
  • Page 16: Mounting

    Select the transport routes for lifting so that the load is not transported over people or a location where people might be. Fig. 2. Measure A, when the distance between the splined shafts is at its shortest. Fig. 3. Shortening the PTO shaft CH10...
  • Page 17: Assembly Instructions

    Screw Fig. 4. Installation of the feed chute / M12X120 Lock nut Chipping position M12 DIN985 Screw M12X30 Lock nut M12 DIN985 Fig. 4a. Installation of the feed chute / Transport position Screw M12X30 Butterfly nut M12 DIN 315 CH10...
  • Page 18: Mounting Of The Chipper And Pre-Operation Inspections

    10. Direct the discharge pipe so that the thrown out chips do not pose a risk to the operator of the chip- per or to or anyone else. Always keep a safe distance to the discharge position of the chips. CH10...
  • Page 19: Stopping A Tractor-Driven Chipper

    -> 0 rpm). STOPPING A HYDRAULIC MOTOR DRIVEN CHIPPER IMPORTANT! When the chipper is driven by the HD 50, it is extremely important to slow the driving engine speed to idle before disconnecting ATTENTION the hydraulics, to prevent cavitation. CH10...
  • Page 20: Chipping

    Re- gularly, check the temperature of the bearings. Pay special attention to careful maintenance, and keep the chipper free from dust. If the chipper starts smoking, pour water into the feed hopper. Fig. 5 Operating lever functions CH10...
  • Page 21: Emptying The Chipper After Use

    The knife-to-anvil clearance is adjusted to the speci- fied values. For instructions on adjusting the clearan- ce, see Adjusting the knife-to-anvil clearance. Screw M12X30 Butterfly nut M12 DIN 315 Fig 6. Swiveling the feed hopper to the transport position CH10...
  • Page 22: Replacing The Bearing

    The bearing at the splined shaft side, Fig. 7b., does not have spacer rings (4 and 9) and an end plate (1). The bearing at the splined shaft side has dust covers on both sides (11). CH10...
  • Page 23: Adjusting The Bearing Clearance

    12. Install the upper bearing housing and tighten the bolts (6) to 50 Nm (36 7/8 lbf). 13. Lubricate the bearing housing. An excessive 1amount of grease causes overheating and impairs lubrication. Fig. 8c. Measuring the clearance Fig. 8d. Tightening the bearing CH10...
  • Page 24: Lubricating The Bearings

    Swing the joints sideways for lubrication Lubricate the shield tubes in Lubricate the outer profile wintertime to prevent them tube’s inner surface from freezing and sticking h= working hours Fig. 9. Lubrication points and intervals for the PTO shaft CH10...
  • Page 25 3. Check the anvil bolts for tightness. 19 (12/16”) 80 (58 15/16) 4. Check the clearance between knives and vertical 19 (3/4”) 1,2 - 1,5 mm (0,02 - 0,06”) anvils. 5. Check the bearings for radial clearance. 0,02 - 0,03 mm (0,008 - 0,0012”) CH10...
  • Page 26: Knife And Anvil Maintenance

    Remove the knife fastening bolts (M12). Turn Fig. 12. Removing the knife fastening bolts the wrench in such a way that your hands would not hit the knife if the wrench should slip. Fig. 12. Wear protective gloves when hand- ATTENTION ling knives or anvils. CH10...
  • Page 27 Anny burrs can be removed by parallel grinding of the surface opposite to the knife mounting bolts. Fig. 15. Surface opposite to the mounting bolts Fig. 15. Final grinding of the knife CH10...
  • Page 28 Slide a feeler gauge between the knives. Tighten the screws of the anvil (A). Adjust the play of the horizontal anvil towards the front edge of the knife to 1.2-1.5 mm. Tigthen the locking screw (B). Recheck the knife play. CH10...
  • Page 29 1,5-2,0 mm vertical anvil disc Observe the correct position! screw horizontal anvil M12x30 DIN933 10.9 Nord-lock M12 lock washer 2 pcs Fig. 18. Cross-section of the disk and knives / anvils CH10...
  • Page 30 CH10 CH10...
  • Page 31: Ch10

    CH10 Part Order no Description Remarks 52062041 Screw M12X50 DIN933 88ZN 52117124 Lock nut M12 DIN985 8ZN 52200490 Washer M12 DIN 7349 ZN 52062502 Screw M12X120 DIN931 88ZN 43340934 End plate 52211042 Spring washer M10 DIN127 ZN 52060209 Screw M10X16 DIN933 88ZN...
  • Page 32: Disc, Complete

    DISC, COMPLETE Part Order no Description Remarks 33620070 Disc 43620080 Knife 52214269 Lock washer M12 NORD-LOCK 52091839 Screw M12x30 DIN933 10.9ZN CH10...
  • Page 33: Ch10 Bearing System

    CH10 BEARING SYSTEM Part Order no Description Remarks 54513569 Dust cover 54512371 Tightener sleeve complete Axle nut Locking plate Tightener sleeve 43513360 Spacer ring D90/83X12.7 54512363 Tapered roller bearing 54513590 Bearing housing 52401015 Grease nipple AR1/8 Screw M10x50 DIN 931 10.9...
  • Page 34 BELT TRANSMISSION 10 I=2,0 5.5 5.2 15 14 CH10...
  • Page 35: Belt Transmission Ch10

    BELT TRANSMISSION CH10 i=2,0 Part Order no Description Remarks 53220570 Belt pulley D315 43621220 Splined shaft 43514450 Bearing housing 53220590 Belt pulley D150 53220580 Taber-Lock 53220560 Tapered adapter sleeve 43341437 54822382 Belt 43512020 Belt tightener complete 43512030 Belt tightener 43341106...
  • Page 36: Discharge Pipe

    DISCHARGE PIPE Part Order no Description Remarks 33620400 Discharge pipe complete 43510240 Vizor 94612082 Tension spring 03514590 Chain 52117108 Lock nut M10 DIN985 8ZN 52117082 Lock nut M8 DIN985 8ZN 52200037 Washer M8 DIN126 58ZN CH10...
  • Page 37: Hydraulic Motor And Hoses, Accessory

    Order no Description Remarks 56001310 Hydraulic motor 56001320 Pressure relief valve 80 bar 52001280 Hexagonal socket head screw M8X35 DIN912 88ZN 52450020 Coupling 1/2” 52450030 Angle nipple 1/4” 43621330 Hydraulic hose L=1350 43621340 Hydraulic hose L=1500 52449220 Quick-fitting 1/2” CH10...
  • Page 38: Ch10 Hydraulic Control, Accessory

    CH10 HYDRAULIC CONTROL, ACCESSORY CH10...
  • Page 39 CH10 HYDRAULIC CONTROL, ACCESSORY Part Order no Description Remarks 52200045 Washer M10 DIN125 58ZN 03621280 Centaflex 16 Clutch R1/2” 56001310 Hydraulic motor 33621000 Adjusting frame Avant 52060209 Screw M10X16 DIN933 88ZN 43620970 Protective plate 52214269 Lock washer M12 NORD-LOCK 52063161...
  • Page 43: Warranty

    The warranty does not cover wearing parts. Send faulty parts, carriage paid, to the manufacturer for inspection. Repairs will be conducted by Farmi Forest Oy or an authorized expert. The warranty is valid only if the bottom part of this page is filled in and returned to the manu- facturer within 30 days of receipt of the product.
  • Page 44: Product Registration Form

    PRODUCT REGISTRATION FORM Date of delivery:_____/_____ 20_____ Dealer: Dealer’s address: Dealer’s tel: Product and type: Serial number: Return to the manufacturer Date of delivery:_____/_____ 20_____ Dealer: Dealer’s address: Dealer’s tel: Customer: Customer’s address: Customer’s tel: E-mail: Product and type: Serial number: CH10...
  • Page 45 Farmi Forest representatives: Western Europe Austria Belgium & Luxemburg Esch-Technik Maschinenhandel G.m.b.H. Déom Sa Klagenfurter Str. 129 Rue de Monty, 177 Sankt Veit an der Glan B-6890 Libin A-9300 Austria Tel. +32 (0)61 65 00 20 Tel. +43 4212 29600 contact@deom.be...
  • Page 46 CH-9554 Tägerschen TG Aydinli Tuzla Istanbul Tel. +41 (0) 71 918 8020 Tel. +90 216 593 09 42 info@adbachmannag.ch mustafa.kemal@rekarma.com adbachmannag.ch rekarma.com.tr Farmi Forest representatives: Eastern Europe Estonia Belarus Melit AP Oü TIGER Ltd Punane 6-311 Kozlova Lane 25-17 13619 Tallinn Minsk 220037 Tel.
  • Page 47 Farmi Forest representatives: North and South America Argentina Canada Inderfor S.A. MTI Canada Inc. Pasco 1732 - 10º "A" 2000 Rosario 1720 Boulevard Guillaume-Couture SANTA FE Saint-Romuald Lévis QC G6W 0R5 Tel. +54 (0)341 679 25 66 Tel. 418 839-4127 info@inderfor.com...
  • Page 48 Farmi Forest Ahmolantie 6, 74510 IISALMI, FINLAND +358 (0)17 832 4400, info@farmiforest.fi...
