MODEL VCA605LED-HEBK / VCA605LED-HEWH / VCA725LED-HEBK / VCA725LED-HEWH
VCA608LED-HEBK / VCA608LED-HEWH / VCA728LED-HEBK / VCA728LED-HEWH
VCA605LED-HEBK / VCA605LED-HEWH
VCA725LED-HEBK / VCA725LED-HEWH
VCA608LED-HEBK / VCA608LED-HEWH
VCA728LED-HEBK / VCA728LED-HEWH
READ AND SAVE THESE INSTRUCTIONS
Address: 46101 Fremont Boulevard, Fremont, CA 94538
US Toll Free Number:
1-888-979-9889 - Technical Support
1-877-685-4384 - Customer Sales Support
www.deltabreez.com
CEILING FAN
TABLE OF CONTENTS
2
3
4
5
6
6
8
9
10
11
11
12
Advertisement
Table of Contents
Related Manuals for DELTA BREEZ VCA605LED-HEBK
Summary of Contents for DELTA BREEZ VCA605LED-HEBK
-
Page 1: Table Of Contents
CEILING FAN MODEL VCA605LED-HEBK / VCA605LED-HEWH / VCA725LED-HEBK / VCA725LED-HEWH VCA608LED-HEBK / VCA608LED-HEWH / VCA728LED-HEBK / VCA728LED-HEWH TABLE OF CONTENTS SUPPLIED CONTENTS GENERAL SAFETY INFORMATION MOUNTING OPTIONS HANGING YOUR FAN ELECTRICAL CONNECTIONS VCA605LED-HEBK / VCA605LED-HEWH VCA725LED-HEBK / VCA725LED-HEWH COMPLETING THE INSTALLATION... -
Page 2: Supplied Contents
SUPPLIED CONTENTS MODEL MODEL VCA605LED-HEBK / VCA605LED-HEWH VCA608LED-HEBK / VCA608LED-HEWH VCA725LED-HEBK / VCA725LED-HEWH VCA728LED-HEBK / VCA728LED-HEWH PART DESCRIPTION PART DESCRIPTION Blades Blades Hanger Bracket Hanger Bracket Hanger Ball/Down-rod assembly Hanger Ball/Down-rod assembly Ceiling Canopy Ceiling Canopy Canopy Cover Canopy Cover... -
Page 3: General Safety Information
GENERAL SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS WARNING GENERAL SAFETY INFORMATION TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE 1. Make sure that the electric service supply FOLLOWING: voltage is AC 120V, 60Hz. 1. -
Page 4: Mounting Options
MOUNTING OPTIONS 1. Disconnect the power by removing fuses or turning off circuit breakers. Ceiling Joists CAUTION TO AVOID POSSIBLE ELECTRICAL SHOCK, BEFORE INSTALLING YOUR FAN, DISCONNECT THE POWER BY TURNING OFF THE CIRCUIT BREAKERS TO THE OUTLET BOX. Outlet Boxes 2. -
Page 5: Hanging Your Fan
HANGING YOUR FAN WARNING Do not attach the blades to the fan until it is assembled and hanging from the ceiling. Doing so Down-rod assembly beforehand will likely bend the blades and could cause the fan to wobble. Ceiling canopy 1. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS REMEMBER – Power should remain off! BLACK BLACK 1. Connect the fan supply (black) wire to the black 120V Supply Circuit WHITE WHITE household wire. (Fig. 9) GREEN GREEN Ground Conductor 2. Connect the fan neutral (white) wire to the white household wire. - Page 7 COMPLETING THE INSTALLATION Note: Remove the eight rubber packing mounts from the fan motor assembly and discard prior to attaching the blade arms. 4. Blade installation (Fig. 13), attach the fan blades Blade to the blade holders by using three blade screws. Tighten screws securely.
-
Page 8: Operating Your Remote Control And Fan
OPERATING YOUR REMOTE CONTROL AND FAN INSTALLING THE BATTERIES (Fig.17) 1. Remove the battery cover by pushing on the arrow Battery cover direction and sliding the cover off. 2. Install two 1.5V AAA batteries (included). 3. Replace the battery cover on the remote control. Push NOTE: The battery will weaken with age and should be replaced before corrosion takes place as this will... -
Page 9: Care And Maintenance
OPERATING YOUR REMOTE CONTROL AND FAN OPERATING THE FAN - Use your fan during summer and winter months. 1. In summer, using the reverse switch, adjust the fan's direction in a counter-clockwise direction, so cool air is blowing down, producing a cooling breeze. -
Page 10: Troubleshooting
TROUBLESHOOTING PROBLEM CORRECTIVE ACTION The fan will not start 1. Check that the electricity has been turned on at the circuit breaker which had probably been turned off during installation. 2. Turn off the electricity. Check all connections in the wiring of the fan at the ceiling and make sure it follows the wiring instructions outlined in this manual. -
Page 11: Dimensions
DIMENSIONS Model No. VCA605LED-HEBK / VCA605LED-HEWH 15" 12.7" 6.7" 60" VCA608LED-HEBK / VCA608LED-HEWH VCA725LED-HEBK / VCA725LED-HEWH 15" 12.7" 6.7" 72" VCA728LED-HEBK / VCA728LED-HEWH PRODUCT SPECIFICATIONS Power Motor Size Number of Speed Airflow Model No. Consumption Light Type (in) Blades (RPM) -
Page 12: Warranty
WARRANTY DELTA ELECTRONICS LIMITED WARRANTY Delta Electronics Inc. (“Delta Electronics”) warrants to the original consumer purchaser in the USA that the Breez fan products will be free from defects in material or workmanship. This warranty gives you specific legal rights. Limitations and Exclusions 1.
