- Page 1 WOLF Electric MTB USER MANUAL v1.0...
- Page 2 WOLF USER MANUAL Please read this manual very carefully before using the product. The manual contains important instructions for the safe use and longevity of your bike.
-
Page 3: Table Of Contents
Guide to Electric Pedal Assistance Modes ..................... 20 Your eBike Keys............................. 20 Maintenance Tyres ................................21 Cleaning Your e bike ........................... 21 Troubleshooting ............................22 F.A.Q’s ................................23 Warranty ................................ 24 Technical Support Contact information ......................25 DAXYS WOLF - USER MANUAL... -
Page 4: Riding Introduction
RIDING INTRODUCTION Do not use the product before carefully reading the instructions and understanding the performance of the product; Before cycling, check whether the brakes work. When braking, please brake rear first and then front. Pay attention to the brake tightness. If the brake is too loose, use an Allen wrench to tighten it. Pay attention to increase the braking distance when riding in rain and snow. -
Page 5: Statement Of Responsibility
Please read this manual carefully before using the product and operate in accordance with it. Otherwise, the company will not be responsible for product damage or personal and property losses caused by improper and wrong use. DAXYS WOLF - USER MANUAL... -
Page 6: Before You Ride
BEFORE YOU RIDE Perform Regular checks and maintenance as outlined below COMPONENT OR INSPECT BEFORE INSPECT CLEAND AND/OR ADJUST / REPAIR / CONDITION EVERY RIDE PERIODICALLY LUBRICATE TIGHTEN REPLACE (IF NECESSARY) Tire presure Tire wear/damage Brake pad adjustment Wheel quick release adjustment Head and tail lights Controls and... -
Page 7: Meet Your Bike
6. Handle 18. Chain 7. Handlebar 19. Rear derailleur 8. Headlights 20. Gear cassette (7 speeds/gears) 9. Shock-absorbing front fork 21. Drive motor 10. Tyres 22. Seat tube 11. Brake Disc 23. Saddle 12. Brake Caliper DAXYS WOLF - USER MANUAL... -
Page 8: Display Guide
DISPLAY GUIDE: 1. Battery level 2. Speed 3. Trip average speed 4. Error warning (Error + code error (displayed instead of current speed) - see page 23 for error descriptions) 5. Current speed in Mph / Kmh 6. Walk / PAS (gear 0-3 - see pages 20-21) 7. -
Page 9: Handlebar Guide
12. Menu / On Off button 4. Front brake lever 13. Option + (up) / Headlight button 5. Handlebar grip 14. Back brake lever 6. Stem 7. Stem cap 8. Stem rotation bolts 9. Bell DAXYS WOLF - USER MANUAL... -
Page 10: Product Specifications
PRODUCT SPECIFICATIONS: Parameter Value Appearance Dimension Body material aluminum alloy Vehicle color black Bike size Length*width*height: 1780mm*640mm*1080mm Hub form spoke wheel Hub size 26” Package size Length*width*height: 1470mm*240mm*790mm Performance Parameters Gross / net weight 30.8kgs/23.7kgs Maximum payload 120kg Top speed 25Km/h Endurance Mileage 35 - 80KM (the lower value is closer to real-life performance) - Page 11 60kg, speed of 15 ~ 25km / h, flat and hardened road surface, from full charge to complete power consumption; Driving habits, temperature, load, tyre pressure, road environment and other factors will affect the mileage. DAXYS WOLF - USER MANUAL...
-
Page 12: Assembly Instructions
ASSEMBLY INSTRUCTIONS: 1. UNBOXING & TOOLS 1. Unpack your new Daxys Wolf eBike. 2. Have the tools and parts ready. 3.Remove packing materials. 4. Remove front wheel. * Be careful not to scratch the paint *Be careful not to cut the tyre... - Page 13 4. Remove the 4 front stem bolts, then the stem cover. 5. Place handlebar in stem and screw the bolts in. * It is recommended to angle the brake handles at aprox. 45° 6. Adjust handlebar to the desired height and tighten the 4 bolts. DAXYS WOLF - USER MANUAL...
- Page 14 3. HEADLIGHT, MUDGUARDS & FRONT WHEEL 1. Attach the mudguard and head-light to the fork and suspension tube 2. Turn the bike upside-down. sockets, using an allen key to tighten the front and side bolts, and *Before flipping the bike, make sure the electronic display is in a a socket key for the back.
- Page 15 4. BRAKE ADJUSTMENT 1. Spin the wheel and listen for rubbing sounds. 2. Loosen A, B with the hex key and adjust brake pads. 3. Spin the wheel to check. 4. Tighten A, B. DAXYS WOLF - USER MANUAL...
- Page 16 5. PEDALS & SADDLE 1. Flip the bike in the normal position. 2. Identify Left & Right pedals. 3. Screw in “R” pedal in a clockwise motion then tighten with 4. Screw in “L” pedal in a clockwise motion then tighten with the the provided multi-tool.
- Page 17 4. Remove the hub screws (4 bolts, 2 on each side), then re- move the rack and back mudguard. 5. Secure and cable tie the back-light cable to the frame. 6. Remove the front mudguard. (see 3.1) DAXYS WOLF - USER MANUAL...
-
Page 18: Charging The Battery
CHARGING THE BATTERY: Using the charger and Battery guide, charging indicators, level indicators etc. 1. Connect the charger to the battery charging port first. 2. Plug in a power source 3. Check if the LED is RED. If the LED is GREEN, unplug from power source and repeat steps 1. and 2. 4. -
Page 19: Battery And Charger Information
Plug your eBike charger directly into a wall outlet instead for best results. If required to use an extension cord, use the shortest length possible, and always check the specs so ensure it can handle your charger’s requirements. DAXYS WOLF - USER MANUAL... -
Page 20: Operating Your Bike
OPERATING YOUR BIKE: Display, Buttons, Power on, gears, brakes etc. 1. Display function Speed display, Power indicator, Failure indication, Odograph, Trip distance. 2. Control and setting functions Power switch control, Wheel diameter setting, Maximum speed setting, Idle automatic sleep setting, Back-light brightness setting, Voltage rating setting etc. - Page 21 Wheel diameter(Unit: inch),Number of magnets, Liquid crystal brightness etc. (See Page 19). Note: Due to ongoing product upgrades, it is possible that some icons and menu items will be different from the above specifications, but will not affect normal usage. DAXYS WOLF - USER MANUAL...
-
Page 22: Guide To Electric Pedal Assistance Modes
GUIDE TO ELECTRIC PEDAL ASSISTANCE MODES: Walk mode - motor powered, no pedaling required, max speed 6 km/h (Long press key on the controller. To exit either squeeze the brakes, or long press again) PAS 0 - no motor assistance PAS 1 - motor assisted, max speed 15 km/h PAS 2 - motor assisted, max speed 20 km/h PAS 3 - motor assisted, max speed 25km/h... -
Page 23: Tyres
Next, take chain lube and apply a slow but steady stream to the inside of the chain as you rotate the cranks until the whole chain got lubed. DAXYS WOLF - USER MANUAL... -
Page 24: Troubleshooting
TROUBLESHOOTING: Troubleshooting information, fault codes, etc Quick troubleshooting steps: Electronic display error code guide 1. Make a note of the event description; 2. Switch off the system; Status code (decimal) Meaning 3. Visually check for any obvious cause; Battery under-voltage 4. -
Page 25: F.a.q's
The Hard-tail E-MTB features only a front suspension. The first question should always be what kind of terrain are you going to ride? The Daxys Wolf is suitable for riding smoother terrain like XC trails and dirt paths. -
Page 26: Warranty
WARRANTY: DOA: Complete replacement 12 Month Warranty*: All returns accepted excluding items that have received physical damage by the owner/end-user Warranty does not apply to any: a) Damage caused by nature or acts of God, for example, lightning strikes, tornadoes and the like; b) Negligent or incorrect use of the product;... -
Page 27: Technical Support Contact Information
TECHNICAL SUPPORT: Please contact your seller for details on authorized service centers. For further support - email support@panmi.com.au DAXYS WOLF - USER MANUAL...
