Argos Betsy 404/4842 Assembly Instructions Manual

Argos Betsy 404/4842 Assembly Instructions Manual

4'6 and 5' bed

Advertisement

Quick Links

Betsy 4'6 and 5' Bed
Dimensions (4'6)
Length - 201cm
Width - 145cm
Height - 120cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
– Please keep for future reference
Dimensions (5')
Length - 211cm
Width - 160cm
Height - 120cm
404/4842
400/8792
Issue 1 - 25/03/15

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Betsy 404/4842 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Betsy 404/4842

  • Page 1 Betsy 4'6 and 5' Bed Assembly Instructions 404/4842 – Please keep for future reference 400/8792 Dimensions (4'6) Dimensions (5') Length - 201cm Length - 211cm Width - 145cm Width - 160cm Height - 120cm Height - 120cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1 - 25/03/15...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Make sure you have enough • Assemble on a soft level components and tools listed on space to layout the parts before surface to avoid damaging the pages 2 and 3.
  • Page 3 Components - Parts If you have damaged or missing components, call the Customer Helpline: 0345 6400 800 Please check you have all the parts listed below Headboard panel (145 x 80cm) (160 x 80cm) 8 Bentwood slat x 32 Headboard post x 2 Support leg x 2 (45 x Ø3.8cm) (24 x Ø2.5cm)
  • Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0345 6400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 Assembly Instructions Step 1 Assembling posts Place headboard panel face down onto a Back clean flat surface. Note: Fixing holes for posts should be facing Secure headboard posts to headboard panel using fixings Front Step 2 Step 2 Assembling side rails With help, assemble side rails to the...
  • Page 6 Assembly Instructions Step 3 Securing end supports Locate end supports into the metal brackets on the inside of side rails Note: Ensure the fixing holes are on the inside as shown. Secure using fixings Holes inside Step 4 Assembling central support Locate central support in between end...
  • Page 7 Assembly Instructions Step 5 Attaching slat caps Assemble plastic caps onto one end of bentwood slats Fit plastic caps into the slotted holes in side rails as shown . Fit bentwood slats into both sides of central plastic caps before pushing caps into central support Assembly is complete.
