Heavy Duty - Bunk Bed
Dimensions
Width - 205,8cm
Depth - 102,8cm
Height -159,0cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
- Please keep for future reference
557/5554
542/4825
814/8809
Issue 1 - 06/09/17

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heavy Duty Bunk Bed 557/5554 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Heavy Duty Bunk Bed 557/5554

  • Page 1 Heavy Duty - Bunk Bed Assembly Instructions - Please keep for future reference 557/5554 542/4825 814/8809 Dimensions Width - 205,8cm Depth - 102,8cm Height -159,0cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 06/09/17...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain components and tools listed on natural timber; you may recommend the notice some variation in the grain use of power pages 2 and 3.
  • Page 3 Components - Panels Please check you have all the panels listed below Short guard rail x2 (150,0 x 9,0 x 1,9 cm) Front side rail x2 (190,0 x 11,0 x 4,4 cm) Back side rail x2 (190,0 x 11,0 x 4,4 cm) Upper Right Headboard x1 (100,8 x 77,0 x 7,0 cm) Slats x 04...
  • Page 4 Components - Fittings If you have damaged or missing components, Customer Helpline: 03456 400 800 call the Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 Assembly Instructions Assembly Instructions Step 1 Step 1 Inserting wooden dowels Insert wooden dowels Insert wooden dowels wooden dowels into the indicated parts. Step 2 Step 2 Fitting top rails Insert wooden dowels into Lower headboard as shown. Fix Lower top rail to Lower headboard using bolt...
  • Page 6 Assembly Instructions Assembly Instructions Step 3 Step 3 Fitting top rails Insert wooden dowels into upper top rail , as shown. Fix upper left headboard to upper top rail using bolt and allen key , as shown. Do not over tighten screws Step 4 Step 4 Fitting top rails...
  • Page 7 Assembly Instructions Assembly Instructions Step 5 Step 5 Fixing side rails Attention From this step are, two people are required for an easier assembly. Insert half moon nuts into side rails, as shown. With help, fix front side rail and back side rail Lower headboard using bolt...
  • Page 8 Heavy Duty Bunk Product: side rails, as shown. - Use ladder for entering and leaving upper bunk. Distributed by: ARGOS LTD - Prohibit more than one person on upper bunk. 000/2016 Batch: Do not remove this label Made in Brazil With help, fix front side rail...
  • Page 9 Assembly Instructions Assembly Instructions Step 9 Fixing long guard rails Fix long guard rail upper right headboard and upper left headboard using screws allen key Step 10 Fitting upper bed Two people are required for this step Insert barrel nut connector bold into the Lower bed.
  • Page 10 Assembly Instructions Assembly Instructions Step 11 Step 11 1º Fixing slats Firstly, fix slats both ends of the rails using screws , as shown. Using Spacer , place slats working towards the middle of the bed, as shown. 1º Fix on the side first, using screws , then fix other side by pushing the rail...
  • Page 11 Assembly Instructions Assembly Instructions Step 12 MATTRESS HEIGHT MUST NOT Attaching ladder BE ABOVE THIS LINE Fit steps 5 to short ladder side rail 14 and long ladder side rail 15. Fix steps to the rail using bolt h and allen key m . Step 13 Fixing ladder Fix ladder to the side rails...
  • Page 12 Assembly Instructions Assembly Instructions Step 14 Fixing short guard rail Attach wooden dowels to the indicated holes of the ladder, as shown. Fix short guard rails upper left headboard using bolt and allen key ,and to the ladder using bolt h and allen key m. Step 15 Fixing guard rail support Fix guard rail support...
  • Page 13 Assembly Instructions Assembly Instructions Step 16 Attaching plastic caps Fit plastic caps into the indicated holes on both upper and lower beds, as shown. Step 17 Attaching plastic caps Fit plastic caps into the indicated holes on both upper and lower beds, as shown.
  • Page 14 Assembly Instructions Assembly Instructions Step 18 Turning bunk bed into two single beds Detach ladder from the bunk bed and remove the upper bed from top of the lower bed. Detach guard rails from the upper bed. Step 19 Attaching plastic caps Fit plastic caps , and into the indicated holes,...
  • Page 15 Assembly Instructions Assembly Instructions Step 20 Attaching plastic caps Fit plastic caps into the indicated holes,as shown. Step 21 Attaching plastic caps Fit plastic caps , and into the indicated holes, as shown. Assembly is complete.
