- Page 1 For more information contact our team: service.ec@foagroup.com...
- Page 5 1) Insert dowels (#E) and barrel nuts (#B) to each ends of the side rails (#3,4). Align Side rails (#3,4) to the holes on the top of the headboards (#1,2). Secure by screwing bolts (#A) onto the barrel nuts (#B) of the side rails (#3,4). 2) Attach dowels (#E) and barrel nuts (#B) to each ends of the guardrails (#5).
- Page 6 1) Align frames (#8,9) to the holes of the upper guardrail. Secure by using bolts (#C). 2) Align frames (#8,9) to the holes of the headboards. Secure by using bolts (#C). Insert dowels (#G) to the center hole of the window panel (#11).
- Page 7 Insert dowels (#G) to the center hole of the window side panel (#12). Attach window side panel (#12) to the side holes of the window, then secure by using bolts (#D). Insert dowels (#G) to the center hole of the window bottom panel (#13).
- Page 8 Insert dowels (#F) to the center hole of the door crossbar (#10). Attach door crossbar (#10) to the top holes of the door, then secure by using bolts (#D). Align slat kit (#6) to the top of the bunk, then secure by using screws (#H).
