Assembly Instructions
CM7131
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 5
Rev.14-12-22
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7131
Summary of Contents for Furniture of America CM7131
- Page 1 Assembly Instructions CM7131 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 10 pcs Headboard F/H Bolt 1/4”x5/8” #B x 8 pcs #2 x 2 pcs Bolt 1/4”x7/8”...
- Page 4 Align the 2 headboard legs (#2) with the pre-drilled holes on the headboard (#1). Then align the 2 brackets (#G) with the headboard (#1) and the headboard legs (#2). II. Insert 8 flat-head bolts (#A) through the brackets (#G) using the Allen wrench (#F) to lock them with the headboard (#1) and the legs (#2).
- Page 5 ASSEMBLING THE BED FRAME TO THE HEADBOARD/FOOTBOARD This is an optional step to assemble the headboard/footboard onto the bed frame (sold separately). Align the holes of the bed frame with the holes on the headboard legs (#2) of the assembled headboard. Prepare 4 bolt assemblies by inserting FIRST the lock washer (#E) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
