1 / 11
MODEL
CM7164EK / CK
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
Philips
Screwdriver
(Not Included)
2 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7164EK-CK
Summary of Contents for Furniture of America CM7164EK-CK
- Page 1 MODEL CM7164EK / CK Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED Philips Screwdriver (Not Included) 2 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 11...
- Page 5 EASTERN KING BED CALIFORNIA KING BED MODEL CM7164EK / CK Please keep instructions for future reference. Check the quantity and irregularity of parts and hardware before you start. PARTS 2pcs 2pcs Headboard Headboard Leg Support Ear Panel (L & R) 2pcs 5pcs 2pcs...
- Page 6 HARDWARE #A 1pc #C 22pcs #B 4pcs Allen Key M4 with ball JCBC Bolt M6 x 30mm JCBC Bolt M6 x 45mm #D 6pcs #E 2pcs #F 10pcs CSK Screw M4 x 32mm CSK Screw M4 x 20mm JCBC Bolt M6 x 60mm #G 4pcs #H 10pcs 22pcs...
- Page 7 CM7164EK & CK is packed in 3 cases Carton Designation Part Hardware Headboard CM7164EK - 1 & CM7164CK - 1 Headboard Leg Support 2pcs #A x 1pc Bed Leg #B x 4pcs 2pcs #C x 22pcs Slat #D x 6pcs 5pcs #E x 2pcs #F x 10pcs...
- Page 8 Part x1pc Part x2pc Use scissors to cut the strap off. Align HB legs (#2) to the headboard (#1), then secure by using bolts (#C) with washers (#I,K,L). Part x1pc Part x2pcs Hardware x1pc Hardware x4pcs Hardware x4pcs Hardware x4pcs Hardware x4pcs 8 / 11...
- Page 9 Align support (#4) to the ear panel (#3), then secure by using screws (#G). Part x2pcs Hardware x4pcs 2D View Marking Line Above part #4 Align ears (#3) to the headboard (#1), then secure by using bolts (#C) with washers (#I,K,L). Part x1pc Part...
- Page 10 Part x1pc Part x2pcs Hardware x1pc Hardware x2pcs Hardware x2pcs Follow Marking Hardware x2pcs Hardware x2pcs Align legs (#5) to the footboard (#8), then secure by using the following bolts with Hardware x2pcs washers in the diagram below. Hardware x2pcs Align side rails (#9) to the footboard (#8), then secure by using bolts (#B) with washers (#I,K,L).
- Page 11 Part x2pcs Part x2pcs Hardware x1pc Hardware x6pcs Hardware x6pcs Hardware x6pcs Hardware x6pcs Align side rails (#9) to the ears (#3), then secure by using bolts (#D) with washers (#I,K,L). Align slat (#6) to the side rails (#9) , then secure by using screws (#F) Part x5pcs...
