Summary of Contents for Hybertone HT-822P
- Page 1 User Manual VoIP FXS+PSTN Gateway Model: HT-822P For DC24V Only Shenzhen HyberTone Technology Co.,Ltd. Http://www.hybertone.com Support@hybertone.com Marketing@hybertone.com Date: 2007-9-17 Version: A38HS-3.11-6...
-
Page 2: Table Of Contents
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com Contents 1 Product Introduction...............4 1.1 General Information......................4 1.2 Protocol..........................4 1.3 Hardware Specification.......................5 1.4 Software Specification ......................5 1.5 List of the Package......................5 1.6 View of the Appearance ......................6 2 Installation..................6 2.1 Installation Steps .........................6 2.2 Connection Diagram ......................7 3 Basic Operations ................7... - Page 3 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.3.7 Default Connect ....................20 4.4 Call Settings ........................20 4.4.1 H.323 Phone .......................21 4.4.1.1 Single Configuration ...................21 4.4.1.2 Configuration by Line .................22 4.4.1.3 Configuration by Group ................22 4.4.1.4 Advance Settings..................23 4.4.1.5 H.323 Direct Mode ..................25 4.4.2 SIP Phone ......................25 4.4.2.1 Single Configuration ...................26...
- Page 4 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 6 Manufactory Parameter ..............47...
-
Page 5: Product Introduction
DHCP, LAN Phone System. The HT-822P IP ADAPTOR is an all-in-one VoIP integrated device, which is designed to be a total solution for network’s providing VoIP services. Its functions are available via a regular analog telephone. -
Page 6: Hardware Specification
Multiple Language Support With Accounting Function 1.5 List of the Package One HT-822P IP ADAPTOR One universal power adaptor DC24V/500mA Warning: The two different power adaptor is use in different kind’s HT-822P. Please don’t mix up it. One Ethernet cable (3m) -
Page 7: View Of The Appearance
2 Installation 2.1 Installation Steps The HT-822P IP ADAPTOR has two PHONE ports （Phone1， Phone 2） , one LINE IN port， one NETWORK port and one PC port. The PHONE ports can register to the same SIP or H.323 account or two different SIP or H.323 accounts. -
Page 8: Connection Diagram
Insert the Ethernet cable into the LAN port of HT-822P IP ADAPTOR and connect the other end of the Ethernet cable to an uplink port (a router or a modem, etc.) Connect a PC to the PC port of HT-822P IP ADAPTOR. -
Page 9: Star Commands For Phone Operation
Local setup is supported via built-in web pages. To access the web pages, the LAN or PC port IP address is required. The HT-822P IP ADAPTOR is equipped with voice prompts to read LAN port and PC port IP addresses via the Phone 1... -
Page 10: Make Phone Calls
Please refer to the table in section 3.1.1 for detailed information. While seting up, please follow the instructions as follows : When the HT-822P IP ADAPTOR fails to set the LAN Port and PC Port IP addresses, it reports 0 on *01 or *02 Star Commands. -
Page 11: Call-Transfer
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com extension. To temporarily put the present caller on hold and answer the new incoming call, press *42 and you will hold the current call. And press *42 again, you will return to the former call. -
Page 12: Send And Receive Voip Calls
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com your own PSTN Access Code) at first. Wait for the PSTN dial tone and dial the PSTN number. If the default connect of FXS MODE in the configuration web is PSTN, dial the phone number directly. - Page 13 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com up continuously. ( The LED will not light network connection unavailable ) If there is data transmitting through the ATA, the LAN LED will blink. (Example: During a VoIP call, the LED will keep blinking.) 1.
-
Page 14: Configuration Guide
The HT-822P IP ADAPTOR HTML configuration menu can be accessed via LAN or PC port: With the LAN access is enabled, get the LAN IP address of the HT-822P IP ADAPTOR as described in section 3.1.1. The HT-822P IP Adaptor’s Web Configuration page can then be accessed by entering the URI into a web browser. - Page 15 To login the Administration Configuration page, please enter “admin” in the User Name field and “admin” (default) in the Password field and then click on the OK button. The PC Browser then shows the window below and you have successfully entered the HT-822P IP ADAPTOR HTTP WEB Interface.
-
Page 16: Status
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.2 Status As shown in the figure above, there are four main fields to be configured on the Status page. 4.2.1 Phone Information A. Serial Number Each ATA has a unique serial number assigned by the factory such as HT822POLDTEST09. -
Page 17: Configurations Options
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com most zones have two or more authoritative servers.) A name server retains the address and routing information for IP users. 4.3 Configurations Options Click on the “Configurations”, the web page will pop-up a subordinate options. Click on “Preference”... -
Page 18: Time Zone And Time Server
4.3.4 Remote Control This function is for remote login the HT-822P’s WEB page traverse the NAT, you not need to make a DMZ or other Port mapping when you want login to a remote device. This is the special service only. It must support by HyberTone’s Remote Control Server. It... -
Page 19: Pound(#)Key And Auto-Dial Timeout
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com The Remote Control star command is *20, this star command’s rule is: *20 + Server IP + Server Port + # For examples, if you want send a support request to the engineer and your SIP’s Remote Control Server’s IP is 222.111.222.111, the Remote Server Port is 1920. - Page 20 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com You can configure the Network Tones as Customized option: The parameters are fill-in as true digits as below format: nc, rpt, c1on, c1off, c2on, c2off, c3on, c3off, f1, f2, f3, f4, p1, p2, p3, p4...
-
Page 21: Default Connect
The user can change the switch command. But it must using “*” by front. Note: By way of differentiate the connect kinds (VoIP or PSTN). HT-822P using a different network tone. The VoIP estate network tones have a transitory intermission. -
Page 22: Phone
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.4.1 H.323 Phone H.323 is the international standard for multimedia communication over packet-switched networks, including LANs, and the Internet. There are three kinds of FXS mode to configure: 1） Single Configuration; 2） Configuration by line ; 3） Configuration by Group . -
Page 23: Configuration By Line
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com Enable Auth If you click the “Enable Authentication” field, you will have to configure the Auth ID and Password. A pair of authentication ID and password is usually needed to use the ATA 4.4.1.2 Configuration by Line In this mode, you will have more advance control over the two FXS ports. -
Page 24: Advance Settings
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.4.1.4 Advance Settings Click on “Advance Settings” in the H.323 menu, the configuration screen of advance settings will be displayed as follows. In this part, you will have more advance control over the H.323 signaling. - Page 25 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com Call Signaling Port is connected to a reliable channel used to convey the call setup and teardown messages between two H.323 endpoints. C） H.245 Port （ Media Control Ports ） Media control port is the port or port range used by the H.245 media control protocol. Note: the H.245 media control protocol uses TCP...
-
Page 26: Direct Mode
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com DTMF Payload Type is used to carry telephony tones and telephony signals. By using a distinct dynamic RTP payload type in the same RTP stream as the media, it is possible to carry DTMF tones, fax-related tones, standard subscriber line tones, country-specific tones and trunk events. -
Page 27: Single Configuration
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.4.2.1 Single Configuration In this FXS mode, you can give the two phones connected to the ATA the same configurations in the following items. A）Phone Number This field use fill in the SIP client authentication ID. It is the telephone number (or extension) you assigned to the VoIP SIP Phone such as 123456. - Page 28 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com can config it with SIP registrar server address field such as 192.168.2.197:2000 or gk.your.com:2000 (the 2000 is your SIP registrar server signaling port). D）Home Domain This field use fill in the IP address of the home domain. Although the IP address is easy to remember, the user still finds it hard to remember because it is long and has no association with its geographical position or organizational relationship.
-
Page 29: Configuration By Line
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com This is the spare VoIP system information, it offer a choice when the current system has some problem. 4.4.2.2 Configuration by Line In this mode, you will have more advance control over the two FXS ports. Firstly, phone 1 and phone 2 will refer to different service providers for related service. - Page 30 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com A） Signaling Port (SIP Local port) SIP local port is the local UDP port; the SIP proxy could have a conversation with SIP proxy server or other SIP user. B） Outbound Proxy This field shows the SIP outbound proxy IP address. In most cases, the SIP outbound proxy is placed alongside the firewall and is the way to let SIP traffic pass from the internal network to the Internet.
-
Page 31: Media Setting
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com F） DTMF Signaling 1） DTMF TYPE DTMF TYPE is used for telephone signaling over the line in the voice frequency band to the call switching center. DTMF means that two groups of tone with different frequencies are united into 16 kinds of dial tone. -
Page 32: Codec Preference
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com A） RTP Ports RTP (Real Time Protocol) Port is the target transport address for the RTP audio stream to be sent to. B） Packet Length it means the time of single network packet sent out . The default time is 20ms. -
Page 33: Nat Traversal
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com the “Call Settings à Media Setting” configuration page, the “Codec Preference” screen will be displayed as below. Codec preference is the order of voice codec. The default one is up transmitting, which is the set mode for common users. -
Page 34: Media Nat Traversal
It includes address, ports, user name, and password. Note: This RELAY proxy is only compatible with the RELAY Server software developed by HyberTone independently. It was free software; you can come down on us. 4.4.5.2 Media NAT Traversal Click on the “Media NAT Traversal” in the “Call Settings” configuration page’s “Media Settings”, the “NAT Traversal”... -
Page 35: Billing Support
HyberTone independently. It was free software; you can come down on us. 4.4.6 Billing Support HT-822P can support two kinds billing mode. First is using HyberTone’s billing software, otherwise is using the Reverse Signal. If you using the HyberTone’s billing software, click the “Billing Support” by the “Call Setting”... -
Page 36: Basic Dial Rule
"73185700", output "075573185700" 4.4.7.2 How to limit code bit If you want to limit the bit of every telephone number in the HT-822P, you could set the dial rule as follow: "AAXXXXXX:-aa+bb" , "AAXXXXXX" is the description for the matching... -
Page 37: User Command
This rule doesn’t support the gateway of the version before A34HS-3.07-18. 4. 5 User Command The HT-822P have four User Commands, in the “Phone Setting” Web like below screen: You can change the VoIP and PSTN switch command. The other two commands: The Hold Key command:*42 The Transfer Key command;*41... -
Page 38: Start Voip Dial
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.5.1 Start VoIP dial The default number is *12. If the line is default PSTN, press *12 and you will switch to VoIP line. 4.5.2 Switch to PSTN The default number is *21. If the line default is VoIP, press *21 and you will switch to PSTN line. -
Page 39: Phonebook
Please resume or lessen the range of the Input Gain. 4.7 PhoneBook The HT-822P can storage 20 phone number. Click on the PhoneBook in the left menu the screen will display as below. -
Page 40: About Fax
User can edit the phonebook and dial up the phone number using the phone book function. 4.8 About FAX HyberTone Technology Co.,Ltd. Declare the HT-822P nonsupport FAX function. But it was build-in two type free FAX codes. Note: HyberTone Technology Co.,Ltd. Declare the HT-822P Gateway are nonsupport FAX function. -
Page 41: Lan Port Configurations
PC port configurations. 4.8.1 LAN Port configurations The HT-822P LAN port can be configured to obtain its IP address by DHCP or the IP address can be set statically (used mainly when using the ATA with a DSL line). There are three modes to configure LAN port: 1）... -
Page 42: Pc Port Configurations
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com In a typical geographically determined network, users input telephone numbers manually. If you obtain a static IP address from your ISP, you can assign it to the ATA LAN port by clicking the Static IP Address Manually, and then entering the IP Address, Subnet Mask, and Default Route. - Page 43 To Enable DHCP Service, you have to know the starting address, which is used to start the service; and the ending address, which is used to end this service. The HT-822P’s DHCP server must running by PC Port using Static IP mode.
-
Page 44: Primary Dns
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com Hardware Address is an address used to enter the MAC address in XX: XX: XX: XX: XX: XX format. Broadcast Address is an address used to communicate with the other computers connected to the PC side of the ATA. -
Page 45: Discard Changes
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.10 Discard Changes 4.11 Tools Menu Click on the “Tools”, the web page will pop-up a subordinate options and the screen will be displayed as follows: 4.11.1 Online Upgrade WARNING! Performing an online upgrade is for experienced users or administrators only! Click Online Upgrade. -
Page 46: Change Password
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com WARNING! When the terminal was updating , please don’t cut the power. It will destroy the terminal. 4.11.2 Change Password A） User Password The ATA supports multiple levels of user administration. The user password is set to allow you to configure the phonebook and other user administrative tasks. -
Page 47: Reboot The Device
HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 4.11.4 Reboot the Device Click on this field to reboot the device. 5 Products Parameter Characteristics of the Parameter Remarks hardware Type HT-822P Can be customized Processor ARM9E 133MHz VPDSP101-2 100MHz FLASH Power DC24V/500mA Consumption... - Page 48 HT-822P VoIP FXS+PSTN Gateway Http://www.hybertone.com 6 Manufactory Parameter Parameter Default DHCP Network Fixed IP : 192.168.8.1 admin dbl#admin or admin Password user 1234 Time Zone GMT＋8 The default star command please refer to the table in section 3.1.1 for detailed information.
