Black Mobile TV Cart with Storage Shelf
Instruction Manual
SKU: STAND-TV07W-S
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-tv07w-s
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Related Manuals for Vivo STAND-TV07W-S
Summary of Contents for Vivo STAND-TV07W-S
- Page 1 Black Mobile TV Cart with Storage Shelf Instruction Manual SKU: STAND-TV07W-S Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-tv07w-s GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury. 44lbs 11lbs Phillips Wrench Screwdriver (20kg) (5kg) SHELF WARNING: CHOKING HAZARD SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED. ASSEMBLY STEPS STEP 1 Attach base (A) to feet (B) using x4 M6x65mm carriage bolts (N), x4 D6 washers (O), and x4 M6 lock... - Page 4 STEP 5 OPTION A: VESA Plate Only Use (M-A or M-B) bolts along with (M-E) washers to attach the VESA plate (D) without the adapters to the TV monitor. Make sure the “VIVO” logo on the front is right side up.
- Page 5 Use bolts (M-A-M-D) along with washers (M-E, M-F) to secure VESA plate with the adapters to the back of your television. Make sure the “VIVO” logo on the front is right side up. For a curved television, spacers (M-G) may be required.
- Page 6 STEP 6 To attach the TV to the stand, loosen the nut at the top of the VESA plate and slide into the slot on the top of the mounting plate on the pole. Install M6 flange nut (Q) to the lower screw post, and secure the top and bottom of the VESA plate to the stand by tightening both nuts using the wrench (V).
- Page 7 STEP 8 Remove clear protective film from the shelf bracket (K). Hold the shelf (J) to the pole (C). Place the mounting bracket (K) over the screw heads, then tighten with the 5mm Allen wrench (U). Adjust as Desired...
- Page 8 : 1HR 8M (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
