ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7677F/Q-VN
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Not Included)
Rev: 19-07-08
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7677F-VN
Summary of Contents for Furniture of America CM7677F-VN
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7677F/Q-VN ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 1pc #1 x 1pc Headboard Allen Key 5mm #2 x 1pc #B x 4pcs Footboard Bolt Ø5/16"...
- Page 4 Exploded View Align HB legs (#5R/L) to the headboard (#1), then secure by using bolts (#C) with washers (#H,G). #C x 4pcs Remove legs (#5) in the compartment #H x 4pcs of the headboard (#1). #G x 4pcs Page 4 of 7...
- Page 5 Attach FB legs (#6) to the footboard (#2). Align side rails (#3) to the headboard (#1) and footboard (#2), then secure by using bolts (#D) with washers (#H,F). #B x 4pcs #D x 4pcs #H x 8pcs #F x 8pcs Page 5 of 7...
- Page 6 Align wings (#4R/L) to the headboard (#1), then secure by using bolts (#C,E) with washers (#H,G) as shown in the diagram. #C x 4pcs #E x 2pcs #G x 6pcs #H x 6pcs Align center slats (#9) to the slats (#7), then secure by using support legs (#8).
- Page 7 Align slats (#7) to the side rails (#3), then secure by using screws (#I). #I x 26pcs Page 7 of 7...
