1 / 10
MODEL #
CM7675CK/EK
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
2 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7675EK
Summary of Contents for Furniture of America CM7675EK
- Page 1 MODEL # CM7675CK/EK Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 2 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 10...
- Page 5 CM7675CK/EK #4 2pcs(L&R ） #1 1pc #2 1pc #3 2pcs HB Leg Headboard Footboard Side Rail #6 4pcs #7 8pcs #5 2pcs Ø1/4" Support Leg FB Leg Bed Slat 190x30x30mm #C 6pcs #A 6pcs #B 6pcs #D 8pcs Bolt Thread bolt Flat Washer Lock Washer Ø5/16"...
- Page 6 #G 8pcs #E 8pcs #F 8pcs #H 1pc Curve washer Wrench Hex nut Screw #8 x 1-1/4" Ø5/16" Ø5/16" x 3/4" #I 1pc Allen Wrench M4 6 / 10...
- Page 7 CM7675CK/EK is packed in 2 cases Carton Disignation Part Hardware #A x 6pcs Headboard #B x 6pcs #C x 6pcs Footboard #D x 8pcs #E x 8pcs Support Leg (8pcs) #F x 8pcs CM7675CK/EK #G x 8pcs -HBFB Bed Slat (4pcs) #H x 1pc #I x 1pc HB Leg(L&R)
- Page 8 ASSEMBLY INSTRUCTIONS Align HB legs (#4R/L) to the Part #1 x1pc headboard (#1), then secure by Part #4 x2pcs using bolts (#A) with washers Hardware #A x6pcs (#B,C). Hardware #B x6pcs Hardware #C x6pcs #C #B Part #2 x1pc Attach FB legs (#5) to the Part #5 x2pcs footboard (#2).
- Page 9 ASSEMBLY INSTRUCTIONS Attach threaded studs (#D) to the headboard (#1) and footboard (#2). Secure by using hex nuts (#F) with washers (#E). Part #3 x2pcs Hardware #D x8pcs Hardware #E x8pcs Hardware #F x8pcs Part #6 x1pc Part #7 x1pc Attach support legs (#7) to the slats (#6).
- Page 10 ASSEMBLY INSTRUCTIONS Align slats (#6) to side rails (#3), then secure by using screws (#G). Hardware #G x8pcs 10 / 10...
