Model No. NTBE05900
Serial No.
Write the serial number in the
space above for reference.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or find that
there are missing parts, we will
guarantee you complete satis-
faction through direct assis-
tance from our factory.
TO AVOID UNNECESSARY
DELAYS, PLEASE CALL
DIRECT TO OUR TOLL-FREE
CUSTOMER HOT LINE. The
trained technicians on our cus-
tomer hot line will provide
immediate assistance, free of
charge to you.
CUSTOMER HOT LINE:
1-888-825-2588
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
Serial
Number
Decal
USERÕS MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Patent
Pending
Advertisement
Related Manuals for NordicTrack NTBE05900
Summary of Contents for NordicTrack NTBE05900
- Page 1 Model No. NTBE05900 USERÕS MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or find that...
-
Page 2: Table Of Contents
Limited Warranty ............. . . Back Cover Note: A Part List/Exploded Drawing is attached in the center of this manual. Remove the Part List/Exploded Drawing before beginning assembly. NordicTrack ¨ is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Precautions
Important Precautions WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the weight rack. 1. Read all instructions in this manual before 11. Always set both safety spotters at the same using the weight rack. Use the weight rack height. -
Page 4: Before You Begin
The model number is NordicTrack ¨ GRT340 weight bench, shown in the NTBE05900. The serial number can be found on a drawing below. To order the NordicTrack ¨ GRT340, call decal attached to the weight rack (see the front cover 1-888-825-2588. -
Page 5: Part Identification Chart
Part Identification ChartÑModel No. NTBE05900 R1000A M8 x 16mm Screw (33) M8 Nylon Locknut (37) M8 x 20mm Bolt (22) Large Washer (28) M10 Nylon Locknut (7) M10 x 25mm Bolt (27) M8 Washer (35) M10 x 65mm Bolt (26) -
Page 6: Assembly
Assembly Before beginning assembly, carefully read the Note: Some small parts may be pre-assembled. following information and instructions: ¥ As you assemble the weight system, make sure all parts are oriented as shown in the drawings. Make Things Easier for Yourself! This manual is designed to ensure that the Assembly may require the following tools (not weight rack can be assembled successfully by... - Page 7 3. Slide a Brace (2) onto the bracket on one of the Uprights (1). Attach the Brace to the Upright with two M10 x 65mm Bolts (26), four M10 Washers (3), and two M10 Nylon Locknuts (7). Do not tighten the Nylon Locknuts yet.
- Page 8 5. Press a 50mm Round Cap (34) into the end of a Weight Storage Tube (13). While a second person holds the Middle Crossbar (5) in the position shown, insert two M10 x 70mm Bolts (29) through the bracket on the Weight Storage Tube (13), through the left Brace (2), and through the bracket on the Middle Crossbar.
- Page 9 8. Press a 25mm Bushing (31) into each end of the Locking Bar (20). Insert the Barbell (21) through the Locking Bar (20) until the Barbell is centered in the Locking Bar. 9. Identify the Left Weight Glider (18) by looking at the position of the round tube.
- Page 10 12. Place the right Safety Spotter (14) on the Right Base (4) and center it over the indicated hole. Note: The handle on the Right Spotter Hook (25) must point toward the center of the rack. Have a second person hold the Locking Bar (20) so that the Right Weight Glider (17) rests on top of the right Safety Spotter (14).
-
Page 11: Adjusting The Weight System
Adjusting the Weight Rack This section explains how the weight rack is adjusted. See the included exercise guide for important information about how to perform a variety of exercises and how to get the greatest benefit from your exercise program. Inspect and tighten all parts each time you use the weight rack. -
Page 12: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). To help us assist you, please be pre- pared to give the following information when calling: ¥ The MODEL NUMBER of the product (NTBE05900) ¥ The NAME of the product (NordicTrack ¨... - Page 13 REMOVE THIS PART LIST/EXPLODED DRAWING FROM THE MANUAL SAVE THIS PART LIST/EXPLODED DRAWING AND THE USERÕS MANUAL FOR FUTURE REFERENCE...
- Page 14 Part ListÑModel No. NTBE05900 R1000A Key No. Qty. Description Key No. Qty. Description Upright Barbell Brace M8 x 20mm Bolt M10 Washer Small Weight Clip Right Base Left Spotter Hook Middle Crossbar Right Spotter Hook Top Crossbar M10 x 65mm Bolt...
