IQ WIFI 6 QUICK GUIDE
CONNECT TO INTERNET
1
Connect one end of the provided
ethernet cable into an available
port on a modem or router.
ADD ADDITIONAL IQ WIFI 6 TO EXPAND COVERAGE
2
Add up to
seven IQ WiFi 6
to cover dead
spots and
improve
performance
3 CONNECT IQ PANEL OR IQ HUB TO NETWORK
On the IQ Panel
(or IQ Hub)
Open settings tray,
touch Settings,
Advanced Settings,
type valid Dealer or
Installer code, then
touch WiFi.
CONFIGURE WIFI NETWORK
4
On IQ Panel, open settings
tray, touch Settings,
Advanced Settings, type in
valid code, touch Installation,
Devices, WiFi Devices, then
touch the IQ WiFi icon
IMPORTANT NOTE: If you would like existing devices to automatically move to the new network, name and password should be identical to the previous network
Connect the other end into
the "WAN" port on IQ WiFi 6
*PRO TIP: If you are adding additional IQ WiFi 6 (see step 2) you might use this time to unbox and power up.
Up to 2
Plug the power supply
into an additional IQ WiFi
6. The power LED will
stop flashing when
complete. (Up to 2 min)
*PRO TIP: Once the "
Locate the SSID/Network name
IQ_WiFi_XXXXXX and touch it to connect.
Select an SSID/Network name to
access the Network Settings page.
Johnson Controls proprietary.
Reproduction without permission is not permitted.
Plug the barrel jack of the power
supply into the "DC-IN" port on IQ
WiFi 6. Plug the power supply into
the wall outlet.
PRIMARY IQ WIFI 6
min
ADDITIONAL IQ WIFI 6
Press the WPS button on
the primary and then the
additional to begin pairing*
" LED on the Primary IQ WiFi 6 is solid you can repeat WPS pairing additional IQ WiFi 6
Default password is
located on the sticker on
the Primary Controller
Make edits as desired. You'll use
this information to add devices
to the network.
Up to 9
min
IQ WiFi 6 will automatically power up,
configure as the primary IQ WiFi 6,
and download any needed updates.
The LEDs will be solid green when
complete*. (Up to 9 min)
Up to 9
min
IQ WiFi 6 will automatically sync,
configure and download any updates.
The LEDs will be solid green when
complete. (Up to 9 min).
MAIN SECURITY GUEST
IQ Panel will automatically
move to IQWiFi 6's Security
Network.
IMPORTANT NOTE: When you
change one network (2.4 or 5 GHz)
it will automatically change the
other to match.
Press "SAVE" to complete.
The entire IQ WiFi 6 network will
automatically sync and reboot.
