What's Inside the box :
1 Front Panel, 1 Back Panel, 1 Lock Body,
1 Cylinder, 1 Strike Plate, 1 User Manual,
2 Keys, 2 RFID Cards, 1 Installation Template,
Fixing Screws, 4 AA Batteries
*Charges Extra I Visit www.yalehome.co.in for Warranty/ Term & Conditions
User's Guide
YDME 50 Pro
