Wine Cooler
Instruction Manual
CWC609SS & CWC609BK
NOTE
: Thank you for ordering your Cookology Wine Cooler.
Please read this user manual before using the appliance and keep
the instructions for future reference.
IMPORTANT:
After Delivery, allow 24 hours before plugging the
wine cooler in to allow the gases to settle.
Content
Advertisement
Related Manuals for Cookology CWC609SS
Summary of Contents for Cookology CWC609SS
- Page 1 Wine Cooler Instruction Manual CWC609SS & CWC609BK NOTE : Thank you for ordering your Cookology Wine Cooler. Please read this user manual before using the appliance and keep the instructions for future reference. IMPORTANT: After Delivery, allow 24 hours before plugging the wine cooler in to allow the gases to settle.
-
Page 2: Table Of Contents
Safety instructions & warnings………………………………..…………………………….1-2 Description of the appliance………………………………..………………………………..3-4 Installation & operation………………………………..……………………………………….5-7 Troubleshooting………………………………..…………………………………………………..8 Maintenance and cleaning………………………………..…………………………………..9 Technical parameters………………………………..…………………………………………..10... -
Page 3: Safety Instructions & Warnings
Safety instructions & warnings Your safety is of the utmost importance to our company. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Technical Department. - Page 4 ●Do not allow child reach into ●Please according to local regulations compressor compartment or touch regarding disposal of the appliance for metal components at rear of the its flammable refrigerant and blowing appliance in case of possible injury. gas. ●Before you scrap the appliance, please Keep away from water take off the doors to prevent children trapped.
-
Page 5: Description Of The Appliance
Description of the appliance Accessories & name 11. Hinge 1. Housing 2. Shelf 3. Control panel 10. Door seal 4. Cover board 9. Handle 8. Door 5. Grill 6. Adjustable foot 7. Lower hinge Note: Shelves, door frame, handle and other accessories could be different according to different models and configuration. - Page 6 Our wine cooler is delivered with the door opening from left to right. To reverse the opening direction: Open the door at 90 degrees and keep it steady. Unscrew the two screws①from the right lower hinge②[Figure 1]. Pull the door⑤ outwards slowly [follow the arrow direction in Figure 2] to get off the lower hinge②...
-
Page 7: Installation & Operation
Installation & operation Position Do not lean the appliance over 45°when moving it to position. The appliance must be put on flat,firm & dry floor or similar noncombustible pad; do not use the package foam pad. 酒柜结构及安装示意图 Do not put the appliance in the wet place. Do not use the appliance in the frozen place. - Page 8 Start operation 1. Cleaning the compartment Before power on, clean inside of the appliance and check the drainage pipe in good connection.（For details, please refer to the “Maintenance and cleaning”） 2. Put the appliance still Before power on, level the appliance on the firm & dry floor for at least 30 minutes. 3.
- Page 9 Switch temperature display between Fahrenheit and Celsius by pressing both keys at the same time. Attention ➢ The cooling temperature could be set from 5-20℃(left zone) and 5-20℃(right zone). ➢ Alarm sound: when the system malfunction occur and alarm sound, press any key on the control panel to cancel the alarm sound.
-
Page 10: Troubleshooting
Rose wine 10-11℃ Champagne & sparkling wine 5- 8℃ Troubleshooting ⚫ Please adjust the front foot, keep the appliance The appliance makes lots of noise? leveling. ⚫ Please keep the appliance a bit space from walls. ⚫ It is normal because of the refrigerant working Liquid flowing sound inside the cabinet? inside. -
Page 11: Maintenance And Cleaning
Maintenance and cleaning Cleaning ➢ Disconnect the appliance before cleaning. ➢ Clean the appliance with soft cloth or sponge by water. ➢ Do not use organic solvents, alkaline detergent, boiling water, washing powder or acid liquid etc. ➢ Do not flush the compartment of the appliance. The below items will damage the surface of wine cooler: Power cut Most power cuts could be resolved within a short time. -
Page 12: Technical Parameters
Technical parameters Product model CWC609SS & CWC609BK Voltage/frequency 220-240V/50Hz Refrigerant/weight R600a/18g Effective volume 112 L Loading capacity 40 bottles Net weight 46kg Unit dimension 595×570×825-870 mm (WxDxH) Packing dimension 660×625×880 mm (WxDxH) Remarks： 1. The Net weight includes shelves and the Unit dimension is without handle on the door.
