Wine Cooler
Instruction Manual
CWC600SS & CWC601BK
NOTE
: Thank you for ordering your Cookology Wine Cooler.
Please read this user manual before using the appliance and keep
the instructions for future reference.
IMPORTANT:
After Delivery, allow 24 hours before plugging the
wine cooler in to allow the gases to settle.
Content
Safety instructions & warnings........................................................................1-3
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cookology CWC600SS
Summary of Contents for Cookology CWC600SS
- Page 1 Wine Cooler Instruction Manual CWC600SS & CWC601BK NOTE : Thank you for ordering your Cookology Wine Cooler. Please read this user manual before using the appliance and keep the instructions for future reference. IMPORTANT: After Delivery, allow 24 hours before plugging the wine cooler in to allow the gases to settle.
-
Page 2: Table Of Contents
Description of the appliance………………………………..………………………………..3-5 Installation & operation………………………………..……………………………………….5-8 Troubleshooting………………………………..…………………………………………………..9 Maintenance and cleaning………………………………..…………………………………..9-10 Technical parameters………………………………..…………………………………………..11... - Page 3 Safety instructions & warnings Your safety is of the utmost importance to our company. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Technical Department.
- Page 4 ●Do not allow child hang on the door to Do not damage the power cord play in case of falling of the appliance. ●Do not disconnect the appliance by ●Do not allow child reach into pulling power cord rather than pulling compressor compartment or touch the plug.
-
Page 5: Description Of The Appliance
is not in contact with or drip onto other suitable for the freezing of fresh food. – If the refrigerating appliance is left food. ● empty for long periods, switch off, – Two-star frozen-food compartments defrost, clean, dry, and leave the door are suitable for storing pre-frozen food, open to prevent mould developing storing or making ice-cream and... - Page 6 The handle is delivered in a separated package with screws together inside the carton. ① Reveal two small holes on the door frame from inner side by pulling out a bit the door seal ② Aim the handle to the holes and insert the screws from inside ③...
-
Page 7: Installation & Operation
Screw top right hinge④& right lower hinge② off from the cabinet⑥and keep them in the polybag for needs if you want to change back left opening door in the future.[Figure 3] Install the top left hinge⑦& left lower hinge⑧ to the left side of the cabinet.(⑦&⑧... - Page 8 The appliance is designed to either build under the counter or stand alone on the floor. Demonstration for building under the counter: Wine bottles could be stored when you feel cooling inside after the appliance operates around 1 hour. Start operation 1.
- Page 9 Control panel All keys would be invalid in lock mode. Please unlock first. ON/OFF 1. Keep pressing the key 3 seconds, power down, goes to stand-by mode. 2. Keep pressing the key again 3 seconds to return back to normal working. Light Press the key, turn on or turn off the LED lights inside.
- Page 10 key on the control panel to cancel the alarm sound. 3. Temperature sensor failure: When the temperature sensor failures occur, error code displays. E1 for open circuit; E2 for short circuit.. Wine storage The appliance equip with sufficient independent shelf to allow your collection of wine get mature quietly and peacefully.
-
Page 11: Troubleshooting
Troubleshooting ⚫ Please adjust the front foot, keep the appliance The appliance makes lots of noise? levelling. ⚫ Please keep the appliance a bit space from walls. ⚫ It is normal because of the refrigerant working Liquid flowing sound inside the cabinet? inside. - Page 12 The below items will damage the surface of wine cooler: Power cut Most power cuts could be resolved within a short time. To protect your wines during a power cut, avoid opening the door as much as possible. During very long power cuts, take the necessary measures to protect your wine.
-
Page 13: Technical Parameters
Technical parameters Product model CWC600SS & CWC601BK Voltage/frequency 220-240V/50Hz Refrigerant/weight R600a/35g Effective volume 135 L Loading capacity 54 bottles Net weight 41kg Unit dimension 595×570×825-870 mm (WxDxH) Packing dimension 660×625×880 mm (WxDxH) Remarks： 1. The Net weight includes shelves and the Unit dimension is without handle on the door.
