Wine Cooler
Instruction Manual
CWC150SS & CWC150BK
NOTE
: Thank you for ordering your Cookology Wine Cooler.
Please read this user manual before using the appliance and keep
the instructions for future reference.
IMPORTANT:
After Delivery, allow 24 hours before plugging the
wine cooler in to allow the gases to settle.
Content
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Cookology CWC150SS
Summary of Contents for Cookology CWC150SS
- Page 1 Wine Cooler Instruction Manual CWC150SS & CWC150BK NOTE : Thank you for ordering your Cookology Wine Cooler. Please read this user manual before using the appliance and keep the instructions for future reference. IMPORTANT: After Delivery, allow 24 hours before plugging the wine cooler in to allow the gases to settle.
-
Page 2: Table Of Contents
Safety instructions & warnings………………………………..…………………………….1-2 Description of the appliance………………………………..………………………………..3-4 Installation & operation………………………………..……………………………………….5-8 Troubleshooting………………………………..…………………………………………………..9 Maintenance and cleaning………………………………..…………………………………..10 Technical parameters………………………………..…………………………………………..11... -
Page 3: Safety Instructions & Warnings
Safety instructions & warnings Your safety is of the utmost importance to our company. Please make sure that you read this instruction booklet before attempting to install or use the appliance. If you are unsure of any of the information contained in this booklet, please contact the Technical Department. - Page 4 ●Do not allow child hang on the door to Disposal of the appliacne play in case of falling of the appliance. ●Please according to local regulations ●Do not allow child reach into regarding disposal of the appliance for compressor compartment or touch its flammable refrigerant and blowing metal components at rear of the gas.
-
Page 5: Description Of The Appliance
Description of the appliance Accessories& name 2. Upper hinge 3. Display panel 1. Housing 10. Door seal 4. Cover board 9. Handle 8. Door 5. Grill 7. Lower hinge 6. Adjustable foot Note: Shelves, door frame, handle and other accessories could be different according to different models and configuration.All photos in this manual are for reference. - Page 6 screw-driver ④ Put back door seal to cover the screws. Reversing the door Our wine cooler is delivered with the door opening from left to right. To reverse the opening direction: Open the door at 90 degrees and keep it steady. ...
-
Page 7: Installation & Operation
lower hinge plate③ slowly on the left lower hinge⑧ and keep the door steady. Screw up the left lower hinge with the plate. Door reversing is finished. Installation & operation Position Do not lean the appliance over 45°when moving it to position. The appliance must be put on flat,firm &... - Page 8 Wine bottles could be stored when you feel cooling inside after the appliance operates around 1 hour. Start operation 1. Cleaning the compartment Before power on, clean inside of the appliance and check the drainage pipe in good connection.（For details, please refer to the “Maintenance and cleaning”） 2.
- Page 9 Control panel All keys would be invalid in lock mode. Please unlock first. ON/OFF 1. Keep pressing the key 3 seconds, power down, goes to stand-by mode. 2.Keep pressing the key again 3 seconds to return back to normal working. Light Press the key, turn on or turn off the LED lights inside.
- Page 10 Child Lock（Combination key） 1. Lock：Press both keys at the same time for 3 seconds to lock. 2. Unlock：Press both keys at the same time for 3 seconds to unlock. Fahrenheit/Celsius display interchange Switch temperature display between Fahrenheit and Celsius by pressing both keys. Attention 1.
-
Page 11: Troubleshooting
If the wine cooler would have no load for a long time, it is recommended to power it off, clean it carefully,andopen the door for ventilation. Below table is the recommended temperature for wine storing & drinking: Red Wine 15-18℃... -
Page 12: Maintenance And Cleaning
Maintenance and cleaning Cleaning ➢ Disconnect the appliance before cleaning. ➢ Clean the appliance with soft cloth or sponge by water. ➢ Do not use organic solvents, alkaline detergent, boiling water, washing powder or acid liquid etc. ➢ Do not flush the compartment of the appliance. The below items will damage the surface of wine cooler: Power cut Most power cuts could be resolved within a short time. -
Page 13: Technical Parameters
Technical parameters Product model CWC150SS & CWC150BK Voltage/frequency 220-240V/50Hz Refrigerant/weight R600a/12g Effective volume 20 L Loading capacity 7 bottles Net weight 17.6kg Unit dimension 150×520×870mm (WxDxH) Packing dimension 190×570×890mm (WxDxH) Remarks： 1. The Unit dimension is without handle on the door.
