GRIP
Lubrication system
User and
Maintenance Manual

TABLE OF CONTENTS

1.
2.
3.
4.
5.
6.
7.
8.
9.
14. CONTRAINDICATIONS
Manual drawn up in accordance with
EC Directive 06/42
Dropsa products can be purchased from Dropsa branches and authorized distributors,
www.dropsa.com/contact or contact us sales@dropsa.com
C2102IE - WK 19/07
1
visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GRIP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DROPSA GRIP

Summary of Contents for DROPSA GRIP

  • Page 1: Table Of Contents

    Manual drawn up in accordance with C2102IE - WK 19/07 http://www.dropsa.com EC Directive 06/42 Via Benedetto Croce, 1 Vimodrone, MILANO (IT) Dropsa products can be purchased from Dropsa branches and authorized distributors, visit t. +39 02 250791 www.dropsa.com/contact or contact us sales@dropsa.com...

  • Page 2: Introduction

    Dropsa SpA Sales department should be contacted without delay. Dropsa SpA declines to accept any responsibility for injuries to persons or damage to property in the event of the non- observance of the information presented in this manual.

  • Page 3: Description Of Components

    GRIP in particularly aggressive or explosive/flammable environments or on components subject to vibration. To install GRIP use the magnet at the base of the pump. For vertical installation dismount the magnet at base of the pump and replace it with the and mounting bracket you find in the package (1). On the long side of the bracket fix the magnet it was at the base and the second magnet you find in the package.
  • Page 4 6.4 HYDRAULIC CONNECTIONS The only connection to be undertaken is that of the individual pumps, provided with push-in connections, to the lubrication point. The tubing must be in Ø 4 mm (0.16 in.) nylon (obtainable from Dropsa). 6.5 PNEUMATIC CONNECTIONS Connect the air input to the push-in connector utilizing Ø...

  • Page 5: Instructions For Use

    7. INSTRUCTIONS FOR USE 7.1 STARTING THE GRIP PANEL Before using the GRIP panel, it is necessary to carry out some preliminary checks: check the integrity of the equipment check that the pneumatic connections have been effected correctly vent the residual air from the pump using the vent screw, located at the center of the securing screws, until lubricant exits (retighten the vent screw without using excessive force).

  • Page 6: Maintenance

    7.4 ADJUSTING THE PNEUMATIC TIMER (PN. 1524845) The illustration below shows how to adjust the frequency of lubrication cycles when using models that contain the Pneumatic Timer. Above Cycle frequency is based on 6 bar (90 PSI) inlet pressure. • If inlet pressure is 8 BAR (120 PSI) reduce the values by 8% •...
  • Page 7 COMPONENTS PART NUMBER DESCRIPTION 3130139 Filter, oil filling 1524845 Timer (Frequency regulator) 3103116C Mini-pump, pneumatic adjustable + 2 screws 14067 5717300 Tube, flexible Ø4 (0.16 in.) 3044403 Tank, 0,5 lt. ACCESSORIES PART NO. DESCRIPTION 3132583 A/O magnetic block kit L=180 mm (7.08 in) 3132714 A/O magnetic block kit L=400 mm (15.74 in 1524486...

  • Page 8: 11. Dimensions

    114 mm 12. HANDLING AND TRANSPORT Prior to dispatch GRIP lubrication panels are carefully packed in a cardboard carton. During transportation and storage maintain the equipment the right way up as indicated on the carton. On receipt, check that the packaging is not damaged and store the equipment in a dry place.
  • Page 9 The mixing pressure is indicatively between 1 bar (14.7 psi ) and 2.5 bar (36.7 psi). 14. CONTRAINDICATIONS The GRIP panel does not have any particular contraindications except for the following points:  The operator coming into contact with fluid due to breakage/opening of supply tubing.

Table of Contents
