VIP4ToolsPro
Minimal air/oil system lubrication
User and
Maintenance Manual
Original Text Translation

TABLE OF CONTENTS

1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
The manual has been prepared in compliance with Directive
CE 06/42
Dropsa products can be purchased from Dropsa branches and authorized distributors,
www.dropsa.com/contact or contact us sales@dropsa.com
C2121IE WK 51/15
visit

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIP4ToolsPro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DROPSA VIP4ToolsPro

  • Page 1: Table Of Contents

    The manual has been prepared in compliance with Directive C2121IE WK 51/15 Via Benedetto Croce, 1 CE 06/42 Vimodrone, MILANO (IT) Dropsa products can be purchased from Dropsa branches and authorized distributors, visit t. +39 02 250791 www.dropsa.com/contact or contact us sales@dropsa.com...
  • Page 2: Introduction

    Dropsa SpA Sales department should be contacted without delay. Dropsa SpA declines to accept any responsibility for injuries to persons or damage to property in the event of the non-observance of the information presented in this manual.
  • Page 3: Technical Characteristics

    DO NOT supply the machine with voltages or pressures other than those indicated on the specification plate. DESCRIPTION OF COMPONENTS Central VIP4ToolsPro Unit The central unit of the lubrication system is composed of the following items:  a Tank, made of transparent plastic material, compatible with lubricants on the market.
  • Page 4: Installation

    Provide adequate space for the installation, leaving a minimum room of 100 mm around the panel. Mount the VIP4ToolsPro panel at shoulder height to avoid unnatural posture or the possibility of sustaining impacts. Do not install the VIP4ToolsPro in particularly aggressive or explosive/flammable environments or on components subject to vibration.
  • Page 5 6.6 ELECTRICAL CONNECTIONS The only electrical connection required is that of the Samba level. (see paragraph 4 Technical specifications) 6.6.1 Schematic electrical connection Samba Level NC electric level in the absence of lubricant. 6.6.2 Schematic electrical solenoid connection Connector 39979- EV 24 V DC non polarized. N.B.: After all connecting up has been completed ensure the tubing and cables are protected from impacts and are suitably secured.
  • Page 6 EXAMPLE OF TUBING AND NOZZLE CONNECTION. STRAIGHT TUBING CO-AXIAL TUBING CONNECTION...
  • Page 7: Instructions For Use

    7. INSTRUCTIONS FOR USE 7.1 STARTING THE VIP4ToolsPro PANEL Before using the VIP4ToolsPro panel, it is necessary to carry out some preliminary checks: check the integrity of the equipment check that the electrical and pneumatic connections have been effected correctly vent the residual air from the pump using the vent screw, located at the center of the securing screws, until lubricant exits (retighten the vent screw without using excessive force).
  • Page 8: Maintenance

    APPROXIMATE CONSUMPTION FOR LRT OILS (3226661) USAGE Grams per lubrication nozzle in 8 hours operating time REFRACTORY ALUMINIUM LEADED STEEL ALLOY STEEL AND TITANIUM LEADED BRASS SOFT STEEL STAINLESS STEEL ALLOYS Saw cutting Turning 35-40 30-60 Shearing Cutting off Boring Drilling 30-40 Milling...
  • Page 9: Ordering Information

    10. ORDERING INFORMATION VERSIONS Code Model Reservoir Size Solenoid Voltage 3701110 1 Liter 110V AC 1 Lubrication Point with pneumatic timer 1 Liter 220V AC 3701120 2 Lubrication Points with pneumatic timer 3701122 2+2 Lubrication Points for external limit switch 1 Liter 24V DC 3701322...
  • Page 10: Dimensions

    11. DIMENSIONS 11.1 VIP4ToolsPro 1 LITER. (6 Lubrication Points with pneumatic timer ELECTRIC LEVEL FILLER PLUG AIR SUPPLY Push-in Ø8 tubing SOLENOID VALVE 24 V DC AIR FLOW REGULATOR PNEUMATIC TIMER AIR/OIL OUTLET Ø6/3 (coaxial) – Ø4 (straight) PUMP STROKE ADJUSTMENT 11.2 VIP4ToolsPro 3 LITERS.
  • Page 11: Handling And Transportation

    REGULATOR 12. HANDLING AND TRANSPORTATION Prior to dispatch VIP4ToolsPro lubrication panels are carefully packed in a cardboard carton. During transportation and storage maintain the equipment the right way up as indicated on the carton. On receipt, check that the packaging is not damaged and store the equipment in a dry place.
  • Page 12: Contraindications

    The mixing pressure is indicatively between 1 bar (14.7 psi ) and 2.5 bar (36.7 psi). 14. CONTRAINDICATIONS The VIP4ToolsPro panel does not have any particular contraindications except for the following points:  The operator coming into contact with fluid due to breakage/opening of supply tubing.
